介質損耗對頻率選擇表面?zhèn)鬏斕匦缘挠绊?/h2>
INFLUENCE OF DIELECTRIC LOSS ON THE TRANSMISSION PROPERTIES OF FREQUENCY SELECTIVE SURFACES
-
摘要: 應用模匹配技術,研究了Y形縫隙平面周期陣列夾嵌于均勻有耗介質層中心的夾心頻率選擇表面(FSS)結構對平面波的傳輸特性。討論了介質層對結構中心諧振頻率、傳輸帶寬、以及傳輸損耗的影響規律。相同介電常數的介質材料在有耗和無耗情況下的模擬分析結果清楚表明介質本身的損耗是影響FSS結構損耗特性的主要因素。
-
關鍵詞:
- 介質損耗; 頻率選擇表面; 傳輸特性
Abstract: The influences of supporting dielectric layers on the transmission properties of FSS with Y slot array embeded in the dielectric are studied in this paper. The frequency properties (resonance frequency, transmission bandwidth and transmission loss are included) of the FSS with different dielectric thickness are discussed. Calculated results show that dielectric losses are main sources of the base of FSS structure. -
Hamdy S M A,Parker E A.Influence of lattice geomitry on transmission of electro-magnetic waves through array of crossed dipoles.IEE Proc.-H,1982,129(1):7-10.[2]Mittra R,Chan C H,Cwik T.Techniques for analyzing frequency selective surfacesA review[J].Proc.IEEE.1988,76(12):1593-1615[3]Luebbers R J,Munk B A.Some effect of dielectric loading on periodic slot arrays.IEEE Trans.on AP,1978,AP-26(4):536-542.[4]Orta R,Tascone R,Zich R.Multiple dielectric loaded perforated screens as frequency selective surfaces.IEE Proc.-H,1988,135(1):75-82.[5]Cwik T,Mittra R.The cascade connection of planar periodic surfaces and lossy dielectric layers to form an arbitrary periodic screen.IEEE Trans.on AP,1987,AP-35(12):1397-1405.[6]Parker E A,Vardaxoglou J C.Influence of single and multiple-layer dielectric substrates on the band spacing available from a concentric ring frequency selective surface[J].Int.J.Electron.1986,61(3):291-297[7]Callaghan P,Parker E A,Langley R J.Influence of supporting dielectric layers on the transmission properties of frequency selective surfaces.IEE Proc,-H,1991,138(5):448-454.[8]Callaghan P,Parker E A.Experimental investigation of closely packed spiral element FSS yields narrowband designeds.Electron.Lett.,1992,28(4):365. -
