矩形反射柱體近旁天線輻射特性的計算應用幾何繞射理論
CALCULATION OF THE RADIATION CHARACTERISTICS OF ANTENNAS ADJACENT TO A RECTANGULAR CYLINDER REFELECTOR BY GTD
-
摘要: 本文用幾何繞射理論分析計算了矩形反射柱體近旁偶極子和雙環天線的水平輻射特性。研究了到達場點的直達波、反射波和柱體稜邊各次繞射波之間的量值關系。分析了柱體邊長、天線與柱體之間的相對位置和天線的饋電方式對合成場強方向圖的影響。計算結果表明,需要對天線系統的有關參數進行優化設計,以得到最佳的全向輻射特性,本文的分析方法和結果為這類天線系統的優化設計提供了手段和依據。
-
關鍵詞:
Abstract: In this paper, the horizontal radiation characteristics of dipole and loop antennas adjaeent to a rectangular cylinder reflector are calculated by the application of GTD. The magnitudes of the direct field, the reflected field and the diffracted field from the edges of the cylinder at the field point are calculated and compared. The effects of the dimension of the cylinder, of the relative position of the antennas with respect to the cylinder and of the method of feeding to the resultant field pattern are analyzed. Using the method described, optimum design can be carried out to obtain the optimum omnidireetional radiation charqacteristics of antennas with reflector of this kind. -
逺藤敬二等,アンテナエ學,日刊工業新聞社,東京,1969.[2]G. L. James, Geometrical Theory of Diffraction for Electromagnetic Waves, Peter Peregrinus Ltd.,Stevenage, UK and New York, 1977, pp. 115-159.[3]R. G. Kouyoumjian, The Geometrical Theory of Diffraction and Its Application, in Numerical and Asymptotic Techniques Electromagnetics, ed. by R. Mittra, Springer-Verlag Berlin, Heidelberg, New York, 1975, pp. 166-217.[4]R. G. Kouyoumjian and P. H. Pathak, Proc. IEEE, 62(1974), 1448.[5]H. Bach, Engineering Application of the Geometrical Theory of Diffraction, in Modern Topics in Electromagnetics and Antennas, ed. by E. J. Maanders and R. Mittra, Peter Peregrinus Ltd., Stevenage, England, 1977, pp. 5.1-5.87. -
