徑向耦合多腔輸出系統數值模擬分析
The numerical simulation of the radial coupling multi-cavity resonators
-
摘要: 寬帶速調管放大器是雷達、通訊系統核心部件,速調管輸出系統的寬帶特性對速調管帶寬有至關重要的作用,該文論述了借助于三維電磁場計算程序《ISFEL 3D》對徑向耦合多腔諧振輸出系統的一對諧振腔(主腔和副腔)做了數值模擬分析,得到了不同于普遍使用的軸向耦合雙間隙腔系統的場結構、模式類別和調諧帶寬特性。據此結果設計了冷測實驗?zāi)Ｐ?達到了離散(頻率)工作點帶寬7％的要求。
-
關鍵詞:
- 速調管; 諧振腔; 數值模擬
Abstract: Broadband klystron is one of key devices in radar and communication system. The broadband performances of microwave output circuit play an important role for extending klystrons bandwidth. This paper describes the numerical results of a broadband output circuit-radial coupling multicavity circuit by using 3D electromagnetic field computation program, IS-FEL 3D, which includes the resonance performance, field distribution, mode construction and difference of radial with axial coupling multicavity circuit. The radial coupling multicavity circuit has been designed and manufactured, and the cold measurement shows that 7% bandwidth has been obtained. -
C.A. Silaev, ISFEL 3D, Electrical Engineering University, St. Petersburg, Russia, 1997.[2]E. Lien, D. Robinson, Study and investigation leading to the design of broadband high-power klystron amplifiers AD813227, 1981. -
