一種新的集成電路互連線串?dāng)_模型和估計公式
A new kind of interconnect crosstalk model and estimation formula for high-speed integrated circuits
-
摘要: 建立了一個考慮分布電阻，分布電容的互連線混П模型，在這個模型的基礎上，分析了終端在最壞條件下的串?dāng)_響應，并推導了三階S域系數的精確表達式，最終，獲得了一個新的互連線串?dāng)_響應的估計公式，通過與SPICE模擬的結果相比較，該文的模擬結果非常接近實際電路的串?dāng)_響應，與相關文獻所發表的結果相比較，該模型更符合實際情況，結果也更精確。Abstract: In this paper, an interconnect delay estimation model is built up, including the effect of distributed resistance, capacitance and even inductance. Then, on the basis of this model, the respondence of the terminal on the worst condition is analyzed and three-order precise formula to estimate the crosstalk respondence is presented. In the end, a new estimation formula for interconnect crosstalk respondence is derived. Moreover, experimental result is excellent enough to the simulation result of SPICE for practical circuit.
-
Y. Eo, W. R. Eisenstadt, J. Y. Jeong, O. Kwon, A new on-chip interconnect crosstalk model and experimental verification for CMOS VLSI circuit design, IEEE Trans. on Electron Devices, 2000,47(1), 129-140.[2]T. Sakurai, Closed-form expressions for interconnection delay, coupling and crosstalk in VLSIs,IEEE Trans. on Electron Devices, 1993, 40(1), 118-124.[3]J. Cong , Z. Pan, Interconnect delay estimation models for synthesis and design planning, in Proc. Asia and South Pacific Design Automation Conf., Jan. 1999, 97-100.[4]Y.I. Ismail, E. G. Friedman, J. L. Neves, Figures of merit to characterized the important of on-chip inductance, IEEE Trans. on VLSI Syst. 1999, 7(4), 442-449.[5]Semiconductor Industry Association, National Technology Roadmap for Semiconductor, USA,1997. -
