校準六端口反射計的新技術
A NEW CALIBRATION TECHNIQUE FOR THE SIX-PORT REFLECTOMETER
-
摘要: 作者對Hoer博士(1979)的四標準負載校準方法進行了改進,并將該方法與李世鶴博士(1982)的四短路器法結合使用,提出一種新的六端口反射計校準方法;它既有李氏法快速、簡單的優點,又兼有Hoer法精度高的長處。作為示例,本文給出了新方法在我們研制Ku波段六端口反射計中運用的效果。
-
關鍵詞:
- 六端口反射計; 微波網絡; 牛頓迭代法
Abstract: On the basis of Dr. Hoer s (1979) and Dr. Li s work, a new calibration method for the Six-port reflectometer is proposed. The new method is characterized not only by having the advantage of rapidity and simplicity of Dr. Li s method, but also by having the advantage of high precision of Dr. Hoer s method. An example for applying this method to Ku-band Six-port reflectometer is given. -
S. H. Li(李世鶴),R. G. Bosisio, IEEE Trans. on MTT, MTT-30(1982), 1085-1089.[2]C. A. Hoer, Calibrating a Six-Port Reflectometer with Four Impedance Standards, NBS Technica Note-1012,(1979).[3]馮康,數值計算方法,國防工業出版社,1978年.[4]盧榮潤,宇航計測技術,1984年,第5期,第46-54頁.[5]陳兆武,電子測量技術,1986年,第1期,第9-12頁. -
