保角變換FDTD算法的數值穩定性與數值色散
NUMERICAL STABILITY AND NUMERICAL DISPERSION OF CONFORMAL MAPPING FDTD ALGORITHM
-
摘要: 本文提出了新的保角變換FDTD算法，推導了保角變換FDTD算法的時間穩定性和數值色散方程。此外，本文以圓波導為例計算了不同網格下TE模數值波長的相對誤差，分析了不同傳播常數和對極點不同半徑的半圓電壁近似下數值波長的相對誤差。通過適當?shù)剡x擇網格數，可得到高精度。
-
關鍵詞:
- 保角變換;FDTD算法;數值穩定性;數值色散
Abstract: This paper proposes a new algorithm based on conformal mapping and FDTD method,and derives the numerical stability and numerical dispersion equations of conformal mapping FDTD algorithm.As an example,the relative errors of numerical wavelengths for TE modes in a circular waveguide in different cell number are calculated.The errors for different propagation constants and for different radius semicircle electric wall approaches to singularity at origin are analyzed.By selecting cell number appropriately,high accuracy can be obtained. -
林為干.符果行,鄔琳若,劉仁厚.電磁場理論.北京:人民郵電出版社,1996年2月,569-656.[2]張克潛,李德杰.微波與光電子學中的電磁理論.北京:電子工業出版社,1994年11月,112-133.[3]Kim I S,Hoefer W J R.Numerical dispersion characteristics and stability factor for the FD-TD method.Electron.Lett.,1993,26(7):485-486.[4]Cangellaris A C.Numerical stability and numerical dispersion of a compact 2-D/FDTD method used for the dispersion analysis of waveguides.IEEE Microwave and Guided Wave Letters,1993,13(1):3-5.[5]Stratton J A.Electromagnetic Theory.New York:McGraw-Hill,1941,50-51.[6]Taflove A.Computational Electrodynamics:The Finite-Difference Time-Domain Method.London:Artech House Boston,1995,82-87. -
