分析非線性電路的諧波平衡法的改進
AN IMPROVEMENT TO THE HARMONIC-BALANCE TECHNIQUE FOR ANALYZING NONLINEAR CIRCUITS
-
摘要: 本文根據分析微波非線性電路的基本方法之一諧波平衡法,提出了一種加速收斂過程的改進方法,并且將其應用于微波混頻器的非線性分析。在分析過程中引入了混頻二極管非線性特性由時域到頻域的簡化變換技術,大大加快了計算速度。分析結果與已發表的結果相比較,一致性較好。這種改進的分析方法也可以推廣應用于包含多個非線性器件的非線性電路的計算機輔助分析。
-
關鍵詞:
- 非線性電路; 諧波平衡法; 微波混頻器; 計算機輔助分析
Abstract: An improved method, which is based on the harmonic-balance technique, for speeding up the convergence of iteration procedure is presented. As example, it is applied to the nonlinear analysis of microwave mixer, in which a simple time domain to frequency domain transformation technique for the mixer diode is introducel. The use of this technique saves computing time dramatically. And the analyzing results are in good agreement with the results published. The improved method can also be extended to the CAA of nonlinear circuits with multi-devices. -
A. R. Kerr, IEEE Trans. on MTT, MTT-23(1975), 828-831.[2]M. S. Nakhla, IEEE Trans. on CAS, CAS-23(1976), 85-81.[3]R. G. Hicks, IEEE Trans. on MTT, MTT-30(1982), 251-259.[4]C. C.-Penalosa, IEEE Trans. on MTT, MTT-31(1983), 724-730.[5]B. Schppert, IEEE Trans. on MTT, MTT-34(1986), 110-119. -
