反射系數對行波調制器特性的影響
EFFECT OF REFLECTION COEFFICIENT ON THE TRAVELING WAVE MODULATOR PERFORMANCES
-
摘要: 本文分析了當電極傳輸線與終端負載阻抗不匹配時,Ti:LiNbO3行波調制器的調制特性.主要討論了反射系數對調制器半波電壓、帶寬以及對時域波形的影響。
-
關鍵詞:
- 行波調制器; 半波電壓; 沖激響應
Abstract: The characteristics of Ti: LiNbO3 traveling wave modulator have been analyzed in this paper, taking into account the reflection coefficient of the terminator. The main emphasis of the present work is placed on the description of the effect of the reflection coefficient on the bandwidth, the half-wave voltage and the time domain response. -
Sueta T, Izutsu M. Integrated optic devices for microwave applications. IEEE Trans. on MTT, 1990, MTT-38 ( 5) : 477-482.[2]speed Ti:LiNb03 and semiconductor optical modulators. IEICE Trans., 1993, E76- C(2): 183-190.[3]姚德森,毛鈞杰.導行波技術基礎.湖南長沙:國防科大出版社,1987, 19-33.[4]Alferness R C. Waveguide electro-optic modulators. IEEE Trans. on MTT, 1982, MTT-30(8): 1121-1137.[5]Erasure D, et al. Time-domain analysis of phase-reversal travelling-wave integrated modulators[J].Electron. Lett.1986, 22(19):1024-1026 -
