微波四端口電路的計算機輔助設計
COMPUTER-AIDED DESIGN OF MICROWAVE FOUR-PORT CIRCUITS
-
摘要: 本文介紹用傳遞矩陣分析微波四端口線性電路的基本方法,并給出若干基本電路元件的數學模型和四端口電路網絡函數的表達式。此外,還介紹一個小型通用程序,它能對一些定向耦合器、平衡晶體管放大器以及電調衰減器等進行分析和優化設計。
-
關鍵詞:
Abstract: An analysis method of microwave four-port circuits by using the transfer matrix is presented. The mathematical models of several basic circuit elements and expressions of net-work functions for microwave four-port circuits are given. Furthermore a small general program is also presented which is capable of analysing and optimizing a group of directional couplers, balanced transistor amplifiers and electrically tuned attenuators. -
J. C. Field and D. L. Herrick, IEEE Trans. on ED, ED-17(1974), 198.[3]P. E. Green, IEEE Trans. on MTT, MTT-17 (1969), 506.[4]沈楚王,南工學報,1983年,第1期,第56頁.[5]W. N. Parker, IEEE Trans. on MTT, MTT-17 (1969), 495.[9]林守遠, 電子學報,11(1983), 73.[10]V. G. Gelnovatch and T. E. Burke, IEEE Trans, on MTT, MTT-16 (1968), 429. -
