面向任務驅動的動態可伸縮空間信息網絡架構設計與優化

何立軍; 賈子曄; 李世銀; 汪彥婷; 王麗; 劉磊

doi:10.11999/JEIT240505

面向任務驅動的動態可伸縮空間信息網絡架構設計與優化

doi: 10.11999/JEIT240505 cstr: 32379.14.JEIT240505

1.
中國礦業大學信息與控制工程學院徐州 221116
2.
南京航天航空大學電子信息工程學院南京 210024
3.
西北工業大學軟件學院西安 710072
4.
西安郵電大學通信與信息工程學院西安 710121

基金項目: 國家自然科學基金(62201463, 61901388)，江蘇省自然科學基金(BK20220883)

詳細信息

作者簡介:
何立軍：男，副教授，博士，研究方向?yàn)榭仗斓匾惑w化網絡、無人機組網、無線通信

賈子曄：女，副教授，博士，研究方向?yàn)榈涂罩锹?lián)網、無人機、空天地一體化網絡

李世銀：男，教授，博士，研究方向?yàn)闊o線通信、可見光通信定位一體化、智能感知與精確定位、礦山互聯網、語義通信

汪彥婷：女，講師，博士，研究方向?yàn)檫吘売?jì)算、邊緣計算、群智網絡、模型剪枝

王麗：女，講師，博士，研究方向?yàn)橐苿?dòng)通信網絡、物聯網軟件技術、多源異構信息融合

劉磊：男，講師，博士，研究方向?yàn)闊o線網絡性能分析、非正交多址接入、干擾管理技術

通訊作者:
李世銀　lishiyin@cumt.edu.cn

中圖分類號: TN929.5
計量
- 文章訪問數: 259
- HTML全文瀏覽量: 151
- PDF下載量: 34
- 被引次數: 0
出版歷程
- 收稿日期: 2024-06-19
- 修回日期: 2024-11-17
- 網絡出版日期: 2024-11-29
- 刊出日期: 2024-12-01

Design and Optimization of Task-driven Dynamic Scalable Network Architecture in Spatial Information Networks

HE Lijun¹,
JIA Ziye²,
LI Shiyin^{1
, ,},
WANG Yanting³,
WANG Li³,
LIU Lei⁴

1.
School of Information and Control Engineering, China University of Mining and Technology, Xuzhou 221116, China
2.
School of Electronic and Information Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210024, China
3.
School of Software, Northwestern Polytechnical University, Xi’an 710072, China
4.
School of Electronic and Communication Engineering, Xi’an University of Posts and Telecommunications, Xi’an 710121, China

Funds: The National Natural Science Foundation of China (62201463, 61901388), The Natural Science Foundation of Jiangsu Province of China (BK20220883)

摘要

摘要: 現階段空間信息網絡中各衛星子系統各成體系且相互割裂，使得網絡呈現封閉、分裂態勢，形成嚴峻資源壁壘，造成空間資源協同應用能力弱以及網絡擴展能力低等難題。傳統架構設計采用對現階段空間網絡架構的“完全顛覆”的思路，大大增加了實際部署的難度。為此，該文立足于衛星網絡現狀，采取“按步驟分階段升級”的思路，促進現有網絡架構的演進，從任務驅動角度開展動態可伸縮空間信息網絡架構模型研究，實現空間資源在各衛星子系統間高效動態共享，促進空間資源根據任務需求變化而動態高效匯聚。首先，提出分階段實現的網絡架構模型，旨在兼容和升級現有網絡架構。隨后，介紹核心部件網絡資源協調器的詳細設計，包括網絡結構與工作協議、超幀結構以及高效的網絡資源動態分配策略，實現空間數據的高效傳輸。仿真結果表明，所提網絡架構實現了網絡資源高效共享，大大提升空間信息網絡的網絡性能。
- 空間信息網絡 /
- 網絡架構 /
- 資源分配 /
- 數據傳輸
Abstract: At the present stage, the satellite subsystems in Space Information Networks (SINs) have their own systems and are separated from each other, which makes the network appear closed and fragmented, forming a severe resource barrier and resulting in weak collaborative application ability of space resources and low network expansion ability. The traditional architecture design adopts the “completely subversive” idea of the current space networks, which greatly increases the difficulty of actual deployment. Therefore, based on the current status of satellite networks, the idea of “upgrading step by step” is adopted to promote the evolution of the existing network architecture, and a dynamic and scalable architecture model is proposed in SINs from the perspective of mission drive, so as to realize the efficient and dynamic sharing of space resources among subsystems and promote the dynamic and efficient aggregation of space resources according to the changes in mission requirements. Firstly, a phased network architecture model is proposed, aiming at compatibility and upgrading of the existing network architecture. Then, the design of the core component coordinator is introduced, including network structure and working protocol, superframe structure, and efficient network resource allocation strategy, to realize the efficient transmission of spatial data. The simulation results show that the proposed network architecture realizes the efficient sharing of network resources and greatly improves the utilization rate of network resources.
- Spatial information networks /
- Network architecture /
- Resource allocation /
- Data transmission

HTML全文

圖 1 天地協同網絡架構示意圖

下載: 全尺寸圖片幻燈片

圖 2 網絡架構分階段演進

下載: 全尺寸圖片幻燈片

圖 3 網絡資源協調器網絡結構與工作流程設計

下載: 全尺寸圖片幻燈片

圖 4 基于任務驅動的超幀結構

下載: 全尺寸圖片幻燈片

圖 5 網絡模型結構示意圖

下載: 全尺寸圖片幻燈片

圖 6 網絡卸載數據量隨控制變量$ V $的收斂過程

下載: 全尺寸圖片幻燈片

圖 7 網絡性能隨時隙的變化趨勢

下載: 全尺寸圖片幻燈片

圖 8 網絡卸載數量隨衛星天線發射功率的變化趨勢

下載: 全尺寸圖片幻燈片

圖 9 不同方案下的網絡性能比較

下載: 全尺寸圖片幻燈片

1 基于任務驅動的動態可伸縮空間信息網絡架構

(1)信息輸入：初始化隊列$ {\boldsymbol{Q}}(t) = \{ {Q_n}(t)\} $
(2)資源感知：資源協調器在超幀$ t $內的時隙0：(1)收集物理網絡信息計算衛星與數傳站之間的時間窗口信息；(2)收集卸載任務請求，結合　時間窗口信息，構建卸載任務信息;
(3)算法執行：在超幀$ t $的時隙1內:
(a)構建優化問題$ {\text{P6}} $，調用Kuhn-Munkres 算法求解最優變量值$ {{\boldsymbol{x}}^{\rm{opt}}} $；
(b)基于最優變量值$ {{\boldsymbol{x}}^{\rm{opt}}} $，構建優化問題$ {\text{P8}} $，并執行如下流程求解最優變量值$ ({{\boldsymbol{y}}}^{\text{opt}},{{\boldsymbol{f}}}^{\text{opt}}) $，其中$ {{\boldsymbol{y}}}^{\text{opt}}=\left\{({{\boldsymbol{y}}}_{s,n}^{t}{)}^{\text{opt}}\right\} $和$ {{\boldsymbol{f}}}^{\text{opt}}=\left\{({f}_{s}^{t}{)}^{\text{opt}}\right\} $；
For $ s = 1:S $
根據式(14)求出 $ ({y}_{s,n}^{t}{)}^{\text{opt}} $;
$ ({f}_{s}^{t}{)}^{\text{opt}}={{\displaystyle \sum _{h\in \mathcal{H}}({x}_{s,h}^{t})}}^{\text{opt}}{C}_{s,h}^{t} $
End
(4)策略分發：資源協調器將$ {{\boldsymbol{x}}^{\rm{opt}}} $和$ ({{\boldsymbol{y}}}^{\text{opt}},{{\boldsymbol{f}}}^{\text{opt}}) $轉化為指令，推送到實際衛星子系統，進而構建虛擬數傳站；
(5)數據卸載：虛擬衛星子系統根據其網絡資源和任務信息執行數據卸載；
(6)超幀索引更新：檢測超幀$ t $的時長是否執行結束，若結束則更新超幀索引：$ t = t + 1 $，根據式(5)更新隊列$ {\boldsymbol{Q}}(t) $，并返回步驟(2).
