一種目標區域特征增強的SAR圖像飛機目標檢測與識別網絡

韓萍; 趙涵; 廖大鈺; 彭彥文; 程爭

doi:10.11999/JEIT240491

一種目標區域特征增強的SAR圖像飛機目標檢測與識別網絡

doi: 10.11999/JEIT240491 cstr: 32379.14.JEIT240491

中國民航大學智能信號與圖像處理天津市重點實驗室天津 300300

基金項目: 中央高?；?3122020043)

詳細信息

作者簡介:
韓萍：女，教授，研究方向?yàn)镾AR圖像處理與目標檢測

趙涵：男，碩士生，研究方向?yàn)镾AR圖像飛目標檢測

廖大鈺：男，碩士生，研究方向?yàn)镾AR圖像飛機目標檢測

彭彥文：男，碩士生，研究方向?yàn)镻oLSAR圖像飛機場跑道檢測

程爭：男，實驗師，研究方向?yàn)闃O化SAR圖像處理與目標檢測

通訊作者:
韓萍　hanpingcauc@163.com

中圖分類號: TN958
計量
- 文章訪問數: 545
- HTML全文瀏覽量: 239
- PDF下載量: 92
- 被引次數: 0
出版歷程
- 收稿日期: 2024-06-14
- 修回日期: 2024-11-21
- 網絡出版日期: 2024-11-25
- 刊出日期: 2024-12-01

A SAR Image Aircraft Target Detection and Recognition Network with Target Region Feature Enhancement

Tianjin Key Laboratory of Intelligent Signal and Image Processing, Civil Aviation University of China, Tianjin 300300, China

Funds: The Central University Fund (3122020043)

摘要

摘要: 在合成孔徑雷達(SAR)圖像飛機目標檢測識別中，飛機目標圖像呈現離散特性以及結構之間的相似性會降低飛機檢測與識別的準確率。為此該文設計了一種目標區域特征增強的SAR圖像飛機目標檢測與識別網絡。網絡由3部分組成：保護飛機特征的跨階段部分網絡(FP-CSPDarnet)、自適應特征融合的特征金字塔(FPN-A)以及目標區域散射特征提取與增強的檢測頭(D-Head)。FP-CSPDarnet在提取特征的同時可以有效保護SAR圖像飛機特征；FPN-A采用多層次特征自適應融合、細化，來增強飛機特征；D-Head在檢測前有效增強飛機可辨別特征，提升飛機檢測與識別精度。利用SAR-ADRD數據集的實驗結果證明了該文所提方法有效性，其平均精度相對與基線網絡YOLOv5s提升了2.0%。
- 合成孔徑雷達 /
- 飛機目標檢測與識別 /
- YOLOv5s /
- 飛機特征保護 /
- 特征增強
Abstract: In Synthetic Aperture Radar (SAR) image aircraft target detection and recognition, the discrete characteristics of aircraft target images and the similarity between structures can reduce the accuracy of aircraft detection and recognition. A SAR image aircraft target detection and recognition network with enhanced target area features is proposed in this paper. The network consists of three parts: Feature Protecting Cross Stage Partial Darknet (FP-CSPDarnet) for protecting aircraft features, Feature Pyramid Net with Adaptive fusion (FPN-A) for adaptive feature fusion, and Detection Head for target area scattering feature extraction and enhancement (D-Head). FP-CSPDarnet can effectively protect the aircraft features in SAR images while extracting features; FPN-A adopts multi-level feature adaptive fusion and refinement to enhance aircraft features; D-Head effectively enhances the identifiable features of the aircraft before detection, improving the accuracy of aircraft detection and recognition. The experimental results using the SAR-ADRD dataset have demonstrated the effectiveness of the proposed method, with an average accuracy improvement of 2.0% compared to the baseline network YOLOv5s.
- Synthetic Aperture Radar(SAR) /
- Aircraft target detection and recognition /
- YOLOv5s /
- Aircraft feature protection /
- Target area feature enhancement

HTML全文

圖 1 SAR圖像中飛機的結構展示

下載: 全尺寸圖片幻燈片

圖 2 YOLOv5網絡架構圖

下載: 全尺寸圖片幻燈片

圖 3 FPN架構圖

下載: 全尺寸圖片幻燈片

圖 4 本文網絡架構圖

下載: 全尺寸圖片幻燈片

圖 5 CSPDarknet骨干網絡與FP-CSPDarnet結構對比圖

下載: 全尺寸圖片幻燈片

圖 6 SPD-Conv結構圖

下載: 全尺寸圖片幻燈片

圖 7 FPN-A結構圖

下載: 全尺寸圖片幻燈片

圖 8 AR模塊

下載: 全尺寸圖片幻燈片

圖 9 D-Head結構圖

下載: 全尺寸圖片幻燈片

圖 10 AF模塊

下載: 全尺寸圖片幻燈片

圖 11 數據集中飛機的類別與數量

下載: 全尺寸圖片幻燈片

圖 12 骨干網絡輸出特征圖通道可視化結果圖

下載: 全尺寸圖片幻燈片

圖 13 優化檢測頭前后的混淆矩陣

下載: 全尺寸圖片幻燈片

圖 14 各個網絡檢測結果圖1

下載: 全尺寸圖片幻燈片

圖 15 各個網絡檢測結果圖2

下載: 全尺寸圖片幻燈片

表 1 YOLOv5網絡深度消融實驗

模型	P(%)	R(%)	mAP(%)	Parameters(M)	fps
YOLOv5n	90.6	89.1	92.0	1.8	93.6
YOLOv5s	93.0	90.6	93.7	7.0	93.5
YOLOv5m	92.2	90.2	93.3	20.9	68.5
YOLOv5l	93.1	91.2	93.0	46.1	47.6
YOLOv5x	94.0	91.0	94.4	86.2	41.9

下載: 導出CSV

表 2 網絡各個模塊消融實驗

	FPN-A	FP-CSPDarnet	D-Head	P(%)	R(%)	mAP(%)	Parameters(M)	fps
Baseline	–	–	–	93.0	90.6	93.7	7.0	93.6
	√	–	–	90.2	86.5	92.4	8.5	129.9
	√	√	–	92.3	92.5	94.8	10.3	129.9
本文方法	√	√	√	92.5	92.3	95.7	12.2	108.7

下載: 導出CSV

表 3 骨干網絡P-CSPDarknet中各模塊消融實驗(%)

FPN-A	FP-CSPDarnet (骨干結構)	FP-CSPDarnet (骨干結構+SPD-Conv)	P (%)	R (%)	mAP
√	–	–	90.2	86.5	92.4
√	√	–	91.8	90.2	93.9
√	√	√	92.3	92.5	94.8

下載: 導出CSV

表 4 不同檢測網絡對比實驗

	P(%)	R(%)	mAP(%)	Parameters(M)	fps
YOLOv5s	92.6	89.9	93.7	7.0	93.5
Faster R-CNN	82.0	85.6	87.8	41.2	11.2
TOOD	84.9	81.7	85.0	31.8	12.9
YOLOX-s	80.7	83.4	89.7	8.9	41.2
YOLOv7s	91.1	87.6	93.5	9.2	75.8
本文方法	92.5	92.3	95.7	12.3	108.7

下載: 導出CSV

表 5 數據集內不同飛機類別在不同檢測網絡的精度(%)

網絡模型/飛機類別	Boeing787	A220	ARJ21	Boeing737-800	A320/321	A330	Others	mAP(%)
YOLOv5s	98.0	96.6	93.6	87.2	88.1	95.1	96.9	93.7
Yolov7s	96.8	95.5	92.2	93.0	85.8	96.2	94.2	93.5
TOOD	90.7	94.3	85.3	81.1	67.8	91.0	84.4	84.9
YOLOX-s	89.2	86.4	86.3	94.5	95.4	86.7	89.5	89.7
Faster R-CNN	91.8	94.8	87.9	85.6	74.7	91.1	89.0	87.8
本文方法	98.7	98.7	97.7	95.1	95.4	94.8	97.1	95.7

下載: 導出CSV
