弧形邊界在伴隨變量法下的電磁靈敏度分析

張玉賢; 朱海鴿; 馮曉麗; 楊利霞; 黃志祥

doi:10.11999/JEIT240432

弧形邊界在伴隨變量法下的電磁靈敏度分析

doi: 10.11999/JEIT240432 cstr: 32379.14.JEIT240432

張玉賢^{1, 2},
朱海鴿¹,
馮曉麗³,
楊利霞^{1, 2, ,},
黃志祥^{1, 2, 3}

1.
安徽大學電子信息工程學院合肥 230601
2.
安徽大學信息材料與智能感知安徽省實驗室合肥 230601
3.
安徽大學集成電路先進材料與技術產教研融合研究院合肥 230601

基金項目: 國家自然科學基金(62101333, 62071003, U21A20457)，安徽省高校優秀科研創新團隊項目(2022AH010002)

詳細信息

作者簡介:
張玉賢：男，副教授，研究方向為計算電磁學、電磁逆時偏移成像技術

朱海鴿：男，碩士生，研究方向為計算電磁學、靈敏度分析

馮曉麗：女，助理工程師，研究方向為集成電路工藝設計

楊利霞：男，教授，研究方向為等離子體物理、時域有限差分方法

黃志祥：男，教授，研究方向為計算電磁學、多物理場

通訊作者:
楊利霞　lixiayang@yeah.net

中圖分類號: TN011; O441.4
計量
- 文章訪問數: 332
- HTML全文瀏覽量: 167
- PDF下載量: 21
- 被引次數: 0
出版歷程
- 收稿日期: 2024-05-30
- 修回日期: 2024-09-20
- 網絡出版日期: 2024-09-28
- 刊出日期: 2024-12-01

Electromagnetic Sensitivity Analysis of Curved Boundaries under the Method of Accompanying Variables

ZHANG Yuxian^{1, 2},
ZHU Haige¹,
FENG Xiaoli³,
YANG Lixia^{1, 2
, ,},
HUANG Zhixiang^{1, 2, 3}

1.
School of Electronic and Information Engineering, Anhui University, Hefei 230601, China
2.
Anhui Provincial Laboratory of Information Materials and Intelligent Perception at Anhui University, Hefei 230601, China
3.
Anhui University Integrated Circuit Advanced Materials and Technology Industry Education Research Integration Research Institute, Hefei 230601, China

Funds: The National Natural Science Foundation of China (62101333, 62071003, U21A20457), The Project of Excellent Scientific Research and Innovation Team of Universities in Anhui Province (2022AH010002)

摘要

摘要: 電磁靈敏度分析是評估設計參數變化對電磁性能影響的一種方法，它通過計算靈敏度信息指導結構模型分析，以滿足設計規范。商業軟件在進行電磁結構優化設計時，常通過調整幾何結構并使用傳統算法，但這種方法計算耗時且資源占用大。為了提高模型設計的效率，該文提出一種穩定高效的處理方案，即伴隨變量法(AVM)，利用僅有2次算法模擬條件下，實現在參數變換上進行1～2階靈敏度估計。當前AVM的絕大多數應用局限在矩形邊界參數的靈敏度分析，該文首次開拓性地將AVM拓展到弧形邊界參數的靈敏度分析?；诠潭ǖ谋緲?gòu)參數、頻率依賴性目標函數以及瞬態脈沖函數的3種不同情形設計的條件，實現了對弧形結構的電磁靈敏度的高效分析。與有限差分方法(FDM)相比，該方法在計算效率上得到了顯著的提高。該方法有效實施顯著拓寬了AVM在弧形邊界上的應用范圍，可應用于等離子體模型的電磁結構、復雜天線模型的邊緣結構等優化問題上。當計算資源較少的情況下，可滿足電磁結構優化的可靠性和穩定性。
- 電磁靈敏度分析 /
- 有限差分法 /
- 伴隨變量法
Abstract: Sensitivity analysis an evaluation method for the influence with variations of the design parameters on electromagnetic performance, which is utilized to calculate sensitivity information. This information guides the analysis of structural models to ensure compliance with design specifications. In the optimization design of electromagnetic structures by commercial software, traditional algorithms are often employed, involving adjustments to the geometry. However, this approach is known to be extensive in terms of computational time and resource consumption. In order to enhance the efficiency of model design, a stable and efficient processing scheme is proposed in the paper, known as the Adjoint Variable Method (AVM). This method achieves estimation of 1st～2nd order sensitivity on parameter transformations with only two algorithmic simulation conditions required. The application of AVM has predominantly been confined to the sensitivity analysis of rectangular boundary parameters, with this paper making the first extension of AVM to the sensitivity analysis of arc boundary parameters. Efficient analysis of the electromagnetic sensitivity of curved structures is accomplished based on the conditions designed for three distinct scenarios: fixed intrinsic parameters, frequency-dependent objective functions, and transient impulse functions. Compared to the Finite-Difference Method (FDM), a significant enhancement in computational efficiency is achieved by the proposed method. The effective implementation of the method substantially expands the application scope of AVM to curved boundaries, which can be utilized in optimization problems such as the electromagnetic structures of plasma models and the edge structures of complex antenna models. When computational resources are limited, the reliability and stability of electromagnetic structure optimization can be ensured by the application of the proposed method.
- Electromagnetic sensitivity analysis /
- Finite Difference Method(FDM) /
- Adjoint Variable Method(AVM)

HTML全文

圖 1 有損介質不連續面的不同節點分類

下載: 全尺寸圖片幻燈片

圖 2 2維TMz的平面波入射結構

下載: 全尺寸圖片幻燈片

圖 3 2維示例對介質相對介電常數、電導率和半徑掃描的靈敏度

下載: 全尺寸圖片幻燈片

圖 4 頻譜實部與虛部對所有參數的靈敏度

下載: 全尺寸圖片幻燈片

圖 5 探測點場值在整個時間步中有限差分法與伴隨變量法靈敏度對比

下載: 全尺寸圖片幻燈片

表 1 本構無關目標函數下AVM和FDM之間的范數誤差

誤差類型	$ {\varepsilon _{\mathrm{r}}} $	$ {\sigma ^{\mathrm{e}}} $	$ r $
AVM和CFD	2.0255×10^–3	5.1667×10^–4	6.2553×10^–2
AVM和FFD	2.7232×10^–3	5.5774×10^–4	7.3643×10^–3
AVM和BFD	1.3269×10^–3	4.7567×10^–4	1.4296×10^–1

下載: 導出CSV

表 2 頻率相關目標函數下AVM和FDM之間的范數誤差

誤差類型	$ {\varepsilon _{\mathrm{r}}} $		$ {\sigma ^{\mathrm{e}}} $		r
誤差類型	實部	虛部	實部	虛部	實部	虛部
AVM和CFD	0.0099	0.0459	0.0551	0.0101	0.1178	0.1132
AVM和FFD	0.0137	0.0594	0.0573	0.0101	0.1145	0.2525
AVM和BFD	0.0013	0.0820	0.0533	0.0104	0.1287	0.1842

下載: 導出CSV

表 3 瞬態函數下AVM和FDM之間的范數誤差

誤差類型	$ {\varepsilon _{\mathrm{r}}} $ (×10^–2)	$ {\sigma ^{\mathrm{e}}} $ (×10^–3)	r (×10^–1)
AVM和CFD	0.3689	4.0714	1.1738
AVM和FFD	1.3879	4.9260	1.3187
AVM和BFD	1.9305	4.1873	1.3244

下載: 導出CSV

參考文獻(19)

[1]	RAO S S. Engineering Optimization Theory and Practice[M]. 4th ed. Hoboken: John Wiley & Sons, 2009.
[2]	ANTONIOU A and LU Wusheng. Practical Optimization Algorithms and Engineering Applications[M]. New York: Springer, 2007.
[3]	WU J C, WANG S P, WANG Y H, et al. Sensitivity analysis of design parameters in transverse flux induction heating device[J]. IEEE Transactions on Applied Superconductivity, 2020, 30(4): 0600406. doi: 10.1109/TASC.2020.2973604.
[4]	DU Guanghui, HUANG Na, ZHAO Yanyun, et al. Comprehensive sensitivity analysis and multiphysics optimization of the rotor for a high speed permanent magnet machine[J]. IEEE Transactions on Energy Conversion, 2021, 36(1): 358–367. doi: 10.1109/TEC.2020.3005568.
[5]	BAKER R D. A methodology for sensitivity analysis of models fitted to data using statistical methods[J]. IMA Journal of Management Mathematics, 2001, 12(1): 23–39. doi: 10.1093/imaman/12.1.23.
[6]	CABANA K, CANDELO J E, and CASTILLO R. Statistical analysis of voltage sensitivity in distribution systems integrating DG[J]. IEEE Latin America Transactions, 2016, 14(10): 4304–4309. doi: 10.1109/TLA.2016.7786309.
[7]	LI Hui, DU Yuanbo, YANG Xian, et al. Optimization of operation parameters in a cesium atomic fountain clock using Monte Carlo method[J]. IEEE Access, 2021, 9: 132140–132149. doi: 10.1109/ACCESS.2021.3113161.
[8]	KIM H, LEE J, LEE J, et al. Topology optimization of a magnetic resonator using finite-difference time-domain method for wireless energy transfer[J]. IEEE Transactions on Magnetics, 2016, 52(3): 7003304. doi: 10.1109/TMAG.2015.2478444.
[9]	ZHONG Shuangying, RAN Chongxi, and LIU Song. The optimal force-gradient symplectic finite-difference time-domain scheme for electromagnetic wave propagation[J]. IEEE Transactions on Antennas and Propagation, 2016, 64(12): 5450–5454. doi: 10.1109/TAP.2016.2606543.
[10]	MORI T, MURAKAMI R, SATO Y, et al. Shape optimization of wideband antennas for microwave energy harvesters using FDTD[J]. IEEE Transactions on Magnetics, 2015, 51(3): 8000804. doi: 10.1109/TMAG.2014.2359677.
[11]	FENG Feng, XUE Jianguo, ZHANG Jianan, et al. Concise and compatible MOR-based self-adjoint EM sensitivity analysis for fast frequency sweep[J]. IEEE Transactions on Microwave Theory and Techniques, 2023, 71(9): 3829–3840. doi: 10.1109/TMTT.2023.3248167.
[12]	NA Weicong, LIU Ke, ZHANG Wanrong, et al. Advanced EM optimization using adjoint-sensitivity-based multifeature surrogate for microwave filter design[J]. IEEE Microwave and Wireless Technology Letters, 2024, 34(1): 1–4. doi: 10.1109/LMWT.2023.3329783.
[13]	NIKOLOVA N K, BANDLER J W, and BAKR M H. Adjoint techniques for sensitivity analysis in high-frequency structure CAD[J]. IEEE Transactions on Microwave Theory and Techniques, 2004, 52(1): 403–419. doi: 10.1109/TMTT.2003.820905.
[14]	ZHANG Yu, AHMED O S, and BAKR M H. Adjoint sensitivity analysis of plasmonic structures using the FDTD method[J]. Optics Letters, 2014, 39(10): 3002–3005. doi: 10.1364/OL.39.003002.
[15]	HARMON J J, KEY C, ESTEP D, et al. Adjoint-based accelerated adaptive refinement in frequency domain 3-D finite element method scattering problems[J]. IEEE Transactions on Antennas and Propagation, 2021, 69(2): 940–949. doi: 10.1109/TAP.2020.3016162.
[16]	HUANG Zhengyu, JIANG Feng, CHEN Zian, et al. A 3-D total-field/scattered-field plane-wave source for the unconditionally stable associated hermite FDTD method[J]. IEEE Antennas and Wireless Propagation Letters, 2024, 23(2): 628–632. doi: 10.1109/LAWP.2023.3331381.
[17]	葉志紅, 張玉, 魯唱唱. 端接復雜電路傳輸線網絡的電磁耦合時域并行計算方法[J]. 電子與信息學報, 2024, 46(2): 713–719. doi: 10.11999/JEIT230098. YE Zhihong, ZHANG Yu, and LU Changchang. Time domain parallel calculation method for the coupling of transmission line network terminated with complex circuits[J]. Journal of Electronics & Information Technology, 2024, 46(2): 713–719. doi: 10.11999/JEIT230098.
[18]	ZHU Guocui, NIU Kaikun, LI Minquan, et al. High-order ME-CFS-PML implementations for terminating the FDTD domain composed of arbitrary media[J]. IEEE Transactions on Microwave Theory and Techniques, 2024, 72(4): 2414–2426. doi: 10.1109/TMTT.2023.33158373.
[19]	ZHAO Sihan, WEI Bing, HE Xinbo, et al. 2-D hybrid cylindrical FDTD method with unconditional stability[J]. IEEE Microwave and Wireless Technology Letters, 2023, 33(7): 955–958. doi: 10.1109/LMWT.2023.3261918.
