邊緣計算中面向緩存的遷移決策和資源分配

楊守義; 韓昊錦; 郝萬明; 陳怡航

doi:10.11999/JEIT240427

邊緣計算中面向緩存的遷移決策和資源分配

doi: 10.11999/JEIT240427 cstr: 32379.14.JEIT240427

鄭州大學電氣與信息工程學院鄭州 450001

基金項目: 國家自然科學基金(U1604159)

詳細信息

作者簡介:
楊守義：男，教授，研究方向?yàn)闊o(wú)線移動通信，毫米波通信，移動云計算等

韓昊錦：男，碩士生，研究方向?yàn)橐苿?dòng)邊緣計算、無線通信等

郝萬明：男，副教授，研究方向?yàn)楹撩撞ㄍㄐ?，太赫茲通信，大?guī)模MIMO技術，物理層安全技術，智能超表面技術等

陳怡航：女，碩士生，研究方向?yàn)橐苿?dòng)邊緣計算

通訊作者:
楊守義　iesyyang@zzu.edu.cn

中圖分類號: TN92
計量
- 文章訪問數: 448
- HTML全文瀏覽量: 162
- PDF下載量: 66
- 被引次數: 0
出版歷程
- 收稿日期: 2024-05-29
- 修回日期: 2024-11-07
- 網絡出版日期: 2024-11-12
- 刊出日期: 2024-12-01

Cache Oriented Migration Decision and Resource Allocation in Edge Computing

School of Information Engineering, Zhengzhou University, Zhengzhou 450001, China

Funds: The National Natural Science Foundation of China (U1604159)

摘要

摘要: 邊緣計算通過在網絡邊緣側為用戶提供計算資源和緩存服務,可以有效降低執行時延和能耗。由于用戶的移動性和網絡的隨機性，緩存服務和用戶任務會頻繁地在邊緣服務器之間遷移，增加了系統成本。該文構建了一種基于預緩存的遷移計算模型，研究了資源分配、服務緩存和遷移決策的聯合優化問題。針對這一混合整數非線性規劃問題，通過分解原問題，分別采用庫恩塔克條件和二分搜索法對資源分配進行優化，并提出一種基于貪婪策略的遷移決策和服務緩存聯合優化算法(JMSGS)獲得最優遷移決策和緩存決策。仿真結果驗證了所提算法的有效性，實現系統能耗和時延加權和最小。
- 邊緣計算 /
- 遷移策略 /
- 服務緩存 /
- 資源分配
Abstract: Edge computing provides computing resources and caching services at the network edge, effectively reducing execution latency and energy consumption. However, due to user mobility and network randomness, caching services and user tasks frequently migrate between edge servers, increasing system costs. The migration computation model based on pre-caching is constructed and the joint optimization problem of resource allocation, service caching and migration decision-making is investigated. To address this mixed-integer nonlinear programming problem, the original problem is decomposed to optimize the resource allocation using Karush-Kuhn-Tucker condition and bisection search iterative method. Additionally, a Joint optimization algorithm for Migration decision-making and Service caching based on a Greedy Strategy (JMSGS) is proposed to obtain the optimal migration and caching decisions. Simulation results show the effectiveness of the proposed algorithm in minimizing the weighted sum of system energy consumption and latency.
- Edge computing /
- Migrate strategy /
- Service cache /
- Resource allocation

HTML全文

圖 1 系統模型

下載: 全尺寸圖片幻燈片

圖 2 用戶偏好影響

下載: 全尺寸圖片幻燈片

圖 3 帶寬對系統成本影響

下載: 全尺寸圖片幻燈片

圖 4 應用程序?qū)ο到y(tǒng)成本影響

下載: 全尺寸圖片幻燈片

圖 5 服務器數量對系統成本影響

下載: 全尺寸圖片幻燈片

圖 6 任務量大小對系統成本影響

下載: 全尺寸圖片幻燈片

1 二分搜索的上行傳輸功率分配算法

初始化：傳輸功率$ {p_i} $范圍，收斂閾值$r$
(1) 根據式(21)計算得出$ \phi (p_i^{{\text{max}}}) $
(2) if $ \phi (p_i^{{\text{max}}}) \lt 0 $ then
(3) 　$ p_i^* = p_i^{{\text{max}}} $
(4) else
(5) 初始化參數$ {p_l} = p_i^{{\text{min}}} $, $ {p_h} = p_i^{{\text{max}}} $
(6) 　end if
(7) 　if $ \phi ({p_m}) < 0 $ then
(8) 　${p_l} = {p_m}$
(9) 　else
(10) $ {p_h} = {p_m} $
(11) end if
(12) until $({p_h} - {p_l}) \le r$
(13) $ p_i^* = ({p_l} + {p_h})/2 $

下載: 導出CSV

2 基于貪婪決策的遷移緩存聯合優化算法

初始化：${N_{{\text{local}}}}{\text{ = }}{N_{\text{0}}}$, ${N_{{\text{mec}}}} = \phi $
(1) for $i{\text{ = 1:}}N$
(2) 　for $m{\text{ = 1:}}M_i^{{\text{sort}}}$
(3) 　計算用戶的代價增益函數$\Delta C(m)$
(4) end for
(5) 將每個用戶的代價增益函數倒序排列，加入序列$N_i^{{\text{sort}}}$
(6) for $ i{\text{ = 1:}}N_i^{{\text{sort}}} $ 計算目標函數值
(7) 　if ${\text{ET}}{{\text{C}}_{o + i}}{\text{ \lt ET}}{{\text{C}}_o}$
(8) 　　$ \alpha = 1 $, $ \vartheta = 1 $ or $ \varpi $=1
(9) 　else
(10) 保持原有模式
(11) end if
(12) if $ \varpi = 1 $, $ C_m^{\text} + C_m^{\text{a}} \le C_m^{\max } $
(13) 將應用程序緩存至服務器
(14) else if $ X_m^{\min } < {X_i} $
(15) 　更新服務器狀態
(16) else
(17) 　本地執行
(18) end if

下載: 導出CSV

表 1 仿真參數

參數	數值
任務大小$\lambda $(Mb)	10～20
應用程序大小$b$(Gb)	1～5
本地計算能力${f_{{\text{loc}}}}$(GHz)	0.5～1.5
邊緣服務器數目(個)	5～20
噪聲功率譜密度${N_{\text{0}}}$(dBm/Hz)	–174
系統帶寬B(MHz)	1～2
服務器計算能力${f_{{\text{es}}}}$(GHz)	15～25
服務器緩存容量(Gb)	20～30

下載: 導出CSV
