基于自適應交互式多卡爾曼濾波模型的組合導航算法研究

陳光武; 王思琪; 司涌波; 周鑫

doi:10.11999/JEIT240426

基于自適應交互式多卡爾曼濾波模型的組合導航算法研究

doi: 10.11999/JEIT240426 cstr: 32379.14.JEIT240426

1.
蘭州交通大學自動化與電氣工程學院蘭州 730070
2.
甘肅省高原交通信息工程及控制重點實驗室蘭州 730070

基金項目: 甘肅省科技重大專項(21ZD4WA018)，國鐵集團科技計劃(N2023G064, N2022G010)，甘肅省自然科學基金(23JRRA869)，甘肅省科技引導計劃(2020-61-14)

詳細信息

作者簡介:
陳光武：男，教授，研究方向為智能交通和電子信息

王思琪：女，碩士生，研究方向為慣性導航和組合導航

司涌波：男，工程師，研究方向為慣性導航和組合導航

周鑫：男，博士生，研究方向為慣性導航和組合導航

通訊作者:
王思琪　1491745692@qq.com

中圖分類號: TN713; TP391.9; U495
計量
- 文章訪問數: 367
- HTML全文瀏覽量: 260
- PDF下載量: 56
- 被引次數: 0
出版歷程
- 收稿日期: 2024-05-29
- 修回日期: 2024-09-09
- 網絡出版日期: 2024-09-17
- 刊出日期: 2024-12-01

Research on Combined Navigation Algorithm Based on Adaptive Interactive Multi-Kalman Filter Modeling

1.
School of Automation and Electeical Engineering, Lanzhou Jiaotong University, Lanzhou 730070, China
2.
Gansu Provincial Key Laboratory of Traffic Information Engineering and Control, Lanzhou 730070, China

Funds: Gansu Province Science and Technology Major Project (21ZD4WA018), The National Railway Group Science and Technology Program Project (N2023G064, N2022G010), Gansu Province Natural Science Foundation (23JRRA869), Gansu Province Science and Technology Guidance Program (2020-61-14)

摘要

摘要: 在組合導航系統中，信息融合和定位精度取決于慣性系統和傳感器的特性，然而在實際應用中獲取先驗知識仍然具有挑戰性。為解決車輛導航中衛星信號質量的變化及系統非線性降低組合導航系統性能的問題，該文提出一種基于多卡爾曼濾波器的模糊自適應交互式多模型算法(FAIMM-MKF)，將基于衛星信號質量的模糊控制器(Fuzzy Controller)與自適應交互多模型(AIMM)相結合，通過組合無跡卡爾曼濾波(UKF)、迭代擴展卡爾曼濾波(IEKF)和平方根容積卡爾曼濾波(SRCKF)3種不同的濾波器，適配車輛動力學模型，并通過車載半實物仿真實驗驗證該方法的性能。結果表明，在衛星信號質量發生改變的情況下，與傳統的交互式多模型算法相比，該方法顯著提高了車輛在復雜環境中的定位精度。
- 組合導航 /
- 交互式多模型 /
- 卡爾曼濾波器 /
- 模糊控制器
Abstract: Practical applications struggle to obtain prior knowledge about inertial systems and sensors, affecting information fusion and positioning accuracy in combined navigation systems. To address the degradation of integrated navigation performance due to satellite signal quality changes and system nonlinearity in vehicle navigation, a Fuzzy Adaptive Interactive Multi-Model algorithm based on Multiple Kalman Filters (FAIMM-MKF) is proposed. It integrates a Fuzzy Controller based on satellite signal quality (Fuzzy Controller) and an Adaptive Interactive Multi-Model (AIMM). Improved Kalman filters such as Unscented Kalman Filter (UKF), Iterated Extended Kalman Filter (IEKF), and Square-Root Cubature Kalman Filter (SRCKF) are designed to match vehicle dynamics models. The method’s performance is verified through in-vehicle semi-physical simulation experiments. Results show that the method significantly improves vehicle positioning accuracy in complex environments with varying satellite signal quality compared to traditional interactive multi-model algorithms.
- Intergrated navigation /
- Interacting Multiple Model(IMM) /
- Kalman Filter(KF) /
- Fuzzy controller

HTML全文

圖 1 模糊推理系統

下載: 全尺寸圖片幻燈片

圖 2 隸屬度函數

下載: 全尺寸圖片幻燈片

圖 3 FAIMM-MKF算法流程圖

下載: 全尺寸圖片幻燈片

圖 4 GNSS/SINS/ODO組合導航系統結構

下載: 全尺寸圖片幻燈片

圖 5 測試路線和實驗設備示意圖

下載: 全尺寸圖片幻燈片

圖 6 東向速度和北向速度誤差對比圖

下載: 全尺寸圖片幻燈片

圖 7 位置誤差對比圖

下載: 全尺寸圖片幻燈片

圖 8 誤差概率密度圖

下載: 全尺寸圖片幻燈片

表 1 模糊規則表

HDOP	模型權重調整因子
HDOP	衛星拒止	衛星較差	衛星良好
SP	SP	SP	EP
MP	SP	EP	SP
LP	EP	SP	SP

下載: 導出CSV

表 2 傳感器誤差參數

性能指標	陀螺儀		加速度計
性能指標	零偏	隨機游走	零偏	隨機游走	更新頻率
參數	5°/h	0.15°/$ \sqrt h $	0.2 mg	800 ug/$ \sqrt {{\mathrm{Hz}}} $	125 Hz

下載: 導出CSV

表 3 最大誤差和標準誤差對比

算法	東向速度(m/s)		北向速度(m/s)		緯度誤差		經度誤差
算法	最大誤差	標準差	最大誤差	標準差	最大誤差	標準差	最大誤差	標準差
IMM-UKF	1.080 0	0.048 5	0.347 1	0.055 2	1.151 5	0.395 6	–2.919 1	0.835 6
IMM-SRCKF	0.623 7	0.042 4	0.288 3	0.045 1	0.974 2	0.311 6	–2.439 4	0.705 3
IMM-MKF	0.483 5	0.038 6	0.280 6	0.043 8	0.941 0	0.291 5	–2.193 6	0.678 7
FAIMM-MKF	0.467 1	0.028 4	0.205 3	0.040 2	0.760 8	0.220 1	–1.962 5	0.589 3

下載: 導出CSV

表 4 平均絕對誤差和均方根誤差對比

算法	東向速度(m/s)		北向速度(m/s)		緯度		經度
算法	MAE	RMSE	MAE	RMSE	MAE	RMSE	MAE	RMSE
IMM-UKF	0.030 2	0.055 0	0.038 1	0.059 6	0.309 3	0.397 1	0.568 3	0.873 6
IMM-SRCKF	0.024 9	0.043 0	0.027 9	0.048 8	0.235 2	0.311 7	0.481 5	0.743 3
IMM-MKF	0.024 6	0.039 9	0.026 1	0.047 6	0.190 4	0.303 4	0.440 1	0.729 5
FAIMM-MKF	0.018 3	0.029 1	0.025 6	0.043 6	0.164 5	0.226 9	0.364 0	0.642 0

下載: 導出CSV
