無人機輔助邊緣計算網絡的任務卸載與資源分配聯合優化

周曉天; 楊瀟輝; 張海霞; 鄧伊琴

doi:10.11999/JEIT240411

無人機輔助邊緣計算網絡的任務卸載與資源分配聯合優化

doi: 10.11999/JEIT240411 cstr: 32379.14.JEIT240411

1.
山東大學控制科學與工程學院濟南 250061
2.
山東省智能通信與感算融合重點實驗室濟南 250061

基金項目: 國家自然科學基金聯合基金項目(U22A2003)，山東省自然科學基金重大基礎研究項目(ZR2022ZD02)

詳細信息

作者簡介:
周曉天：男，教授，研究方向?yàn)闊o(wú)線通信與網絡、邊緣計算與智能通信等

楊瀟輝：男，碩士生，研究方向?yàn)闊o(wú)人機、邊緣計算等

張海霞：女，教授，研究方向?yàn)闊o(wú)線通信與網絡、無線資源管理、智能通信技術等

鄧伊琴：女，博士后，研究方向?yàn)檫吘売?jì)算、車聯網、無線資源優化等

通訊作者:
張海霞　haixia.zhang@sdu.edu.cn

中圖分類號: TN929.5; TP18
計量
- 文章訪問數: 748
- HTML全文瀏覽量: 238
- PDF下載量: 137
- 被引次數: 0
出版歷程
- 收稿日期: 2024-05-25
- 修回日期: 2024-11-07
- 網絡出版日期: 2024-11-13
- 刊出日期: 2024-12-01

Joint Optimization of Task Offloading and Resource Allocation for Unmanned Aerial Vehicle-assisted Edge Computing Network

1.
School of Control Science and Engineering, Shandong University, Jinan 250061, China
2.
Shandong Key Laboratory of Intelligent Communications and Sensing-Computation Integration, Shandong University, Jinan 250061, China

Funds: The Joint Funds of the National Natural Science Foundation of China (U22A2003), The Major Fundamental Research Project of Shandong Provincial Natural Science Foundation (ZR2022ZD02)

摘要

摘要: 利用無人機(UAV)作為空中中繼節點，構建空地一體化的邊緣計算網絡，可以有效克服地面環境局限，拓展網絡覆蓋范圍，為用戶提供便利計算服務。該文面向無人機中繼輔助的多用戶、多服務器邊緣計算網絡場景，以最大化任務完成量為目標，研究了無人機部署位置、用戶-服務器關聯策略、無人機帶寬分配的聯合優化問題。由于該問題包含連續與離散變量，故該文綜合運用差分進化、粒子群優化等工具，提出了一種基于塊坐標下降(BCD)的次優算法進行求解。所提算法將原問題解耦為3個子問題獨立求解，并通過迭代逼近原始問題最優解。仿真實驗表明，所提算法可在滿足用戶任務時延需求的前提下，最大化系統總?cè)蝿?wù)完成量，優于其他對比算法。
- 無人機通信 /
- 多接入邊緣計算 /
- 任務卸載 /
- 資源分配
Abstract: It can effectively overcome the limitations of the ground environment, expand the network coverage and provide users with convenient computing services, through constructing the air-ground integrated edge computing network with Unmanned Aerial Vehicle (UAV) as the relay. In this paper, with the objective of maximizing the task completion amount, the joint optimization problem of UAV deployment, user-server association and bandwidth allocation is investigated in the context of the UAV assisted multi-user and multi-server edge computing network. The formulated joint optimization problem contains both continuous and discrete variables, which makes itself hard to solve. To this end, a Block Coordinated Descent (BCD) based iterative algorithm is proposed in this paper, involving the optimization tools such as differential evolution and particle swarm optimization. The original problem is decomposed into three sub-problems with the proposed algorithm, which can be solved independently. The optimal solution of the original problem can be approached through the iteration among these three subproblems. Simulation results show that the proposed algorithm can greatly increase the amount of completed tasks, which outperforms other benchmark algorithms.
- Unmanned Aerial Vehicle (UAV) communication /
- Multi-access edge computing /
- Task offloading /
- Resource allocation

HTML全文

圖 1 系統模型

下載: 全尺寸圖片幻燈片

圖 2 算法整體流程圖

下載: 全尺寸圖片幻燈片

圖 3 算法收斂性能分析與UAV部署位置示意圖

下載: 全尺寸圖片幻燈片

圖 4 不同方案及帶寬資源對任務完成量的影響

下載: 全尺寸圖片幻燈片

1 聯合UAV位置、帶寬分配、用戶-邊緣服務器關聯算法

(1) 初始化$ {{\boldsymbol{\varOmega}} ^0} $, $ {{\boldsymbol{B}}^0} $, $ {{\boldsymbol{A}}^0} $，置$ k $=0;
(2) While 目標函數的增長值低于閾值$ \varepsilon $：
(3) 　　給定{$ {{\boldsymbol{B}}^k},{{\boldsymbol{A}}^k} $}，輸入算法2，輸出結果$ {{\boldsymbol{\varOmega}} ^{k + 1}} $;
(4) 　　給定{$ {{\boldsymbol{\varOmega}} ^{k + 1}},{{\boldsymbol{A}}^k} $}，輸入算法3，輸出結果$ {{\boldsymbol{B}}^{k + 1}} $;
(5) 　　給定{$ {{\boldsymbol{\varOmega}} ^{k + 1}},{{\boldsymbol{B}}^{k + 1}} $}，輸入算法4，輸出結果$ {{\boldsymbol{A}}^{k + 1}} $;
(6) 　　更新$ k = k + 1 $;
(7) End While
(8) 得到最終$ {\boldsymbol{\varOmega}} $, $ {\boldsymbol{A}} $, $ {\boldsymbol{B}} $

下載: 導出CSV

2 基于PSO的UAV 3維位置優化算法

輸入：用戶位置$ ({\boldsymbol{w}}_m^{\text{T}},0) $、邊緣服務器位置$ ({\boldsymbol{w}}_s^{\text{T}},0) $、任務參數 　$ ({l_i},{c_i},{\tau _i}) $；其他基本參數$ {A_1},{A_2},{\beta _0},N,\gamma ,{c_1},{c_2},{r_1},{r_2},{k_{{\text{max}}}} $;
輸出：無人機3維位置$ {\boldsymbol{\varOmega}} $
(1) 初始化迭代次數$ k $=1;
(2) For 每個粒子$ i $:
(3) 　For 每個維度$ d $:
(4) 　　在允許范圍內隨機初始化粒子位置$ {{\boldsymbol{X}}_{id}} $;
(5) 　　在允許范圍內隨機初始化粒子速度$ {{\boldsymbol{V}}_{id}} $;
(6) 　End For
(7) End For
(9) While $ k \le {k_{{\text{max}}}} $:
(10) 　 For 每個粒子$ i $:
(11) 　　計算每個粒子能夠完成的系統任務量;
(12) 　　 If $ f({\boldsymbol{X}}_{id}^k) < f({\bf{pbest}}_{id}^{k - 1}) $
(13) 　　　選擇當前粒子位置作為該粒子的最優位置$ {\bf{pbest}}_{id}^k $;
(14) 　　 End If
(15) End For
(16) For 每個粒子$ i $:
(17) 　 For 每個維度$ d $:
(18) 　　根據式(6)計算粒子新速度;
(19) 　　根據$ {\boldsymbol{X}}_{id}^{k + 1} = {\boldsymbol{X}}_{id}^k + {\mkern 1mu} {\mkern 1mu} {\boldsymbol{V}}_{id}^{k + 1} $更新粒子新位置;
(20) 　 End For
(21) End For
(22) $ k = k + 1 $;
(23) End While

下載: 導出CSV

3 基于DE的帶寬分配優化算法

輸入：用戶位置$ ({\boldsymbol{w}}_m^{\text{T}},0) $、邊緣服務器位置$ ({\boldsymbol{w}}_s^{\text{T}},0) $、任務參數 　$ ({l_i},{c_i},{\tau _i}) $；其他基本參數$ {A_1},{A_2},{\beta _0},N,{\text{CR}},{k_{{\text{max}}}} $;
輸出：帶寬分配比例$ {\boldsymbol{B}} $
(1) 初始化迭代次數$ k $=1;
(2) For 每個個體$ i $：
(3) 　For 每個維度$ d $：
(4) 　　在允許范圍內隨機初始化個體位置$ {{\boldsymbol{x}}_{n,1}} $;
(5) 　　計算每個個體能完成的系統任務量;
(6) 　End For
(7) End For
(8) While $ k \le {k_{{\text{max}}}} $：
(9) 　For 每個個體$ i $：
(10) 　從當前$ {{\boldsymbol{x}}_{n,k}} $中選擇3個不同個體 $ {{\boldsymbol{x}}_{r1,k}} $, $ {{\boldsymbol{x}}_{r2,k}} $, $ {{\boldsymbol{x}}_{r3,k}} $;
(11) 　計算得到變異個體;
(12) End For
(13) For 每個個體$ i $：
(14) 　生成當前個體的交叉概率$ {\text{CR}} $;
(15) 　根據式(8)計算得到試驗個體;
(16) End For
(17) For 每個個體$ i $：
(18) 　根據式(9)擇優選出最優個體;
(19) End For
(20) $ k = k + 1 $;
(21) End While

下載: 導出CSV

4 基于交換的用戶-邊緣服務器關聯矩陣優化算法

輸入：用戶位置$ ({\boldsymbol{w}}_m^{\text{T}},0) $、邊緣服務器位置$ ({\boldsymbol{w}}_s^{\text{T}},0) $、任務參數 　$ ({l_i},{c_i},{\tau _i}) $；其他基本參數$ \mathcal{H},\mathcal{F},{A_1},{A_2},{\beta _0} $；
輸出：用戶-邊緣服務器關聯矩陣$ {\boldsymbol{A}} $
(1) 初始化迭代次數$ k $=1；
(2) 根據式(10)計算得到當前系統完成任務量$ \varPhi $；
(3) 根據用戶集合計算得到用戶組合個數$ {\rm{C}}_M^2 $；
(4) While $ k \le {\rm{C}}_M^2 $：
(5) 　計算此連接方式下系統完成任務量$ {\varPhi ^ * } $；
(6) 　If $ {\varPhi ^ * } > \varPhi $：
(7) 　　交換此用戶組合的連接方式，更新$ {{{a}}_{{{m}},{{s}}}} $；
(8) 　End If
(9) 　$ k = k + 1 $；
(10) End While

下載: 導出CSV

表 1 仿真參數設置

參數名	參數值	參數名	參數值
邊緣服務器計算能力f_s	[1, 9] GHz	無人機傳輸功率$ {P_{\mathrm{u}}} $	2 W
邊緣服務器最大用戶服務數$ {\eta _s} $	3	噪聲功率譜密度$ {N_0} $	–169 dBm/Hz
任務的數據量$ {l_i} $	[100, 900] kB	路徑損耗系數$ \alpha $	2.5
用戶-UAV上行鏈路帶寬W	6 MHz	平均信道功率增益$ {\beta _0} $	–60 dB
UAV-服務器下行鏈路帶寬W	6 MHz	Rice因子最小值$ {K_{{\text{min}}}} $	0 dB
用戶設備傳輸功率$ {P_m} $	15 dBm	Rice因子最大值$ {K_{{\text{max}}}} $	30 dB

下載: 導出CSV

表 2 PSO, DE子算法參數設置

算法	參數名	參數值	算法	參數名	參數值
PSO	種群規模大小	40	DE	種群規模大小	60
	粒子維度	3		粒子維度	14
	最大迭代次數	300		最大迭代次數	300
	個體學習因子	2		縮放因子	0.5
	群體學習因子	2		交叉因子	0.4

下載: 導出CSV

表 3 仿真對比算法

算法類型	算法序號	算法簡介
隨機分配	對比算法1	隨機給定UAV位置、用戶-服務器關聯矩陣、帶寬分配比例。
隨機分配	對比算法2	隨機給定UAV位置、用戶-服務器關聯矩陣，平均分配帶寬比例。
1維資源獨立優化	對比算法3	單獨優化用戶-服務器關聯矩陣；隨機給定UAV位置、帶寬分配比例。
	對比算法4	單獨優化UAV位置；隨機給定帶寬分配比例、用戶-服務器關聯矩陣。
	對比算法5	單獨優化帶寬分配比例；隨機給定UAV位置、用戶-服務器關聯矩陣。
2維資源聯合優化	對比算法6	聯合優化用戶-服務器關聯矩陣、UAV位置；隨機給定帶寬分配比例。
	對比算法7	聯合優化UAV位置、帶寬分配比例，隨機給定用戶-服務器關聯矩陣。
	對比算法8	聯合優化用戶-服務器關聯矩陣、帶寬分配比例，隨機給定UAV位置。

下載: 導出CSV

參考文獻(17)

[1]	DJIGAL H, XU Jia, LIU Linfeng, et al. Machine and deep learning for resource allocation in multi-access edge computing: A survey[J]. IEEE Communications Surveys & Tutorials, 2022, 24(4): 2449–2494. doi: 10.1109/COMST.2022.3199544.
[2]	周曉天, 孫上, 張海霞, 等. 多接入邊緣計算賦能的AI質檢系統任務實時調度策略[J]. 電子與信息學報, 2024, 46(2): 662–670. doi: 10.11999/JEIT230129. ZHOU Xiaotian, SUN Shang, ZHANG Haixia, et al. Real-time task scheduling for multi-access edge computing-enabled AI quality inspection systems[J]. Journal of Electronics & Information Technology, 2024, 46(2): 662–670. doi: 10.11999/JEIT230129.
[3]	陳新穎, 盛敏, 李博, 等. 面向6G的無人機通信綜述[J]. 電子與信息學報, 2022, 44(3): 781–789. doi: 10.11999/JEIT210789. CHEN Xinying, SHENG Min, LI Bo, et al. Survey on unmanned aerial vehicle communications for 6G[J]. Journal of Electronics & Information Technology, 2022, 44(3): 781–789. doi: 10.11999/JEIT210789.
[4]	YAN Xuezhen, FANG Xuming, DENG Cailian, et al. Joint optimization of resource allocation and trajectory control for mobile group users in fixed-wing UAV-enabled wireless network[J]. IEEE Transactions on Wireless Communications, 2024, 23(2): 1608–1621. doi: 10.1109/TWC.2023.3290748.
[5]	LI Mushu, CHENG Nan, GAO Jie, et al. Energy-efficient UAV-assisted mobile edge computing: Resource allocation and trajectory optimization[J]. IEEE Transactions on Vehicular Technology, 2020, 69(3): 3424–3438. doi: 10.1109/TVT.2020.2968343.
[6]	LUO Weiran, SHEN Yanyan, YANG Bo, et al. Joint 3-D trajectory and resource optimization in multi-UAV-enabled IoT networks with wireless power transfer[J]. IEEE Internet of Things Journal, 2021, 8(10): 7833–7848. doi: 10.1109/JIOT.2020.3041303.
[7]	NASIR A A. Latency optimization of UAV-enabled MEC system for virtual reality applications under Rician fading channels[J]. IEEE Wireless Communications Letters, 2021, 10(8): 1633–1637. doi: 10.1109/LWC.2021.3075762.
[8]	LIU Boyang, WAN Yiyao, ZHOU Fuhui, et al. Resource allocation and trajectory design for MISO UAV-assisted MEC networks[J]. IEEE Transactions on Vehicular Technology, 2022, 71(5): 4933–4948. doi: 10.1109/TVT.2022.3140833.
[9]	CHENG Kaijun, FANG Xuming, WANG Xianbin, et al. Energy efficient edge computing and data compression collaboration scheme for UAV-assisted network[J]. IEEE Transactions on Vehicular Technology, 2023, 72(12): 16395–16408. doi: 10.1109/TVT.2023.3289962.
[10]	WANG Yong, RU Zhiyang, WANG Kezhi, et al. Joint deployment and task scheduling optimization for large-scale mobile users in multi-UAV-enabled mobile edge computing[J]. IEEE Transactions on Cybernetics, 2020, 50(9): 3984–3997. doi: 10.1109/TCYB.2019.2935466.
[11]	MEI Haibo, YANG Kun, LIU Qiang, et al. Joint trajectory-resource optimization in UAV-enabled edge-cloud system with virtualized mobile clone[J]. IEEE Internet of Things Journal, 2020, 7(7): 5906–5921. doi: 10.1109/JIOT.2019.2952677.
[12]	LIU Tianyu, ZHANG Guangchi, CUI Miao, et al. Task completion time minimization for UAV-enabled data collection in Rician fading channels[J]. IEEE Internet of Things Journal, 2023, 10(2): 1134–1148. doi: 10.1109/JIOT.2022.3204658.
[13]	YOU Changsheng and ZHANG Rui. 3D trajectory optimization in Rician fading for UAV-enabled data harvesting[J]. IEEE Transactions on Wireless Communications, 2019, 18(6): 3192–3207. doi: 10.1109/TWC.2019.2911939.
[14]	MONDAL A, MISHRA D, PRASAD G, et al. Joint optimization framework for minimization of device energy consumption in transmission rate constrained UAV-assisted IoT network[J]. IEEE Internet of Things Journal, 2022, 9(12): 9591–9607. doi: 10.1109/JIOT.2021.3128883.
[15]	LI Jianyu, DU Kejing, ZHAN Zhiui, et al. Distributed differential evolution with adaptive resource allocation[J]. IEEE Transactions on Cybernetics, 2023, 53(5): 2791–2804. doi: 10.1109/TCYB.2022.3153964.
[16]	MILNER S, DAVIS C, ZHANG Haijun, et al. Nature-inspired self-organization, control, and optimization in heterogeneous wireless networks[J]. IEEE Transactions on Mobile Computing, 2012, 11(7): 1207–1222. doi: 10.1109/TMC.2011.141.
[17]	LIU Jialei, ZHOU Ao, LIU Chunhong, et al. Reliability-enhanced task offloading in mobile edge computing environments[J]. IEEE Internet of Things Journal, 2022, 9(13): 10382–10396. doi: 10.1109/JIOT.2021.3115807.
