基于密集殘差和質量評估引導的頻率分離生成對抗超分辨率重構網絡

韓玉蘭; 崔玉杰; 羅軼宏; 蘭朝鳳

doi:10.11999/JEIT240388

基于密集殘差和質量評估引導的頻率分離生成對抗超分辨率重構網絡

doi: 10.11999/JEIT240388 cstr: 32379.14.JEIT240388

1.
哈爾濱理工大學測控技術與通信工程學院哈爾濱 150080
2.
哈爾濱理工大學模式識別與信息感知黑龍江省重點實驗室哈爾濱 150080

基金項目: 國家自然科學基金(11804068)，黑龍江省省屬高等學?；究蒲袠I(yè)務(2020-KYYWF-0342)

詳細信息

作者簡介:
韓玉蘭：女，講師，研究方向?yàn)槿斯ぶ悄芘c計算機視覺、大數據分析與預測等

崔玉杰：女，碩士，研究方向?yàn)閳D像重構

羅軼宏：女，碩士，研究方向?yàn)閳D像重構

蘭朝鳳：女，副教授，研究方向?yàn)檎Z(yǔ)音信號處理與分析、水下信號分析與處理等

通訊作者:
韓玉蘭　hanyulan@hrbust.edu.cn

中圖分類號: TN911.73; TP391
計量
- 文章訪問數: 217
- HTML全文瀏覽量: 125
- PDF下載量: 38
- 被引次數: 0
出版歷程
- 收稿日期: 2024-05-16
- 修回日期: 2024-11-09
- 網絡出版日期: 2024-11-18
- 刊出日期: 2024-12-01

Frequency Separation Generative Adversarial Super-resolution Reconstruction Network Based on Dense Residual and Quality Assessment

1.
School of Measurement and Control Technology and Communication Engineering, Harbin University of Science and Technology, Harbin 150080, China
2.
Heilongjiang Province Key Laboratory of Pattern Recognition and Information Perception, Harbin University of Science and Technology, Harbin 150080, China

Funds: The National Natural Science Foundation of China (11804068), The Fundamental Research Funds for the Provincial Universities (2020-KYYWF-0342)

摘要

摘要: 生成對抗網絡因其為盲超分辨率重構提供了新的思路而備受關注。針對現有方法未充分考慮圖像退化過程中的低頻保留特性而對高低頻成分采用相同的處理方式，缺乏對頻率細節有效利用，難以獲得較好重構效果的問題，該文提出一種基于密集殘差和質量評估引導的頻率分離生成對抗超分辨率重構網絡。該網絡采用頻率分離思想，對圖像的高頻和低頻信息分開處理，從而提高高頻信息捕捉能力，簡化低頻特征處理。該文對生成器中的基礎塊進行設計，將空間特征變換層融入密集寬激活殘差中，增強深層特征表征能力的同時對局部信息差異化處理。此外，利用視覺幾何組網絡(VGG)設計了專門針對超分辨率重構圖像的無參考質量評估網絡，為重構網絡提供全新的質量評估損失，進一步提高重構圖像的視覺效果。實驗結果表明，同當前先進的同類方法比，該方法在多個數據集上具有更佳的重構效果。由此表明，采用頻率分離思想的生成對抗網絡進行超分辨率重構，可以有效利用圖像頻率成分，提高重構效果。
- 超分辨率 /
- 生成對抗網絡 /
- 頻率分離 /
- 質量評估 /
- 密集殘差
Abstract: With generative adversarial networks have attracted much attention because they provide new ideas for blind super-resolution reconstruction. Considering the problem that the existing methods do not fully consider the low-frequency retention characteristics during image degradation, but use the same processing method for high and low-frequency components, which lacks the effective use of frequency details and is difficult to obtain better reconstruction result, a frequency separation generative adversarial super-resolution reconstruction network based on dense residual and quality assessment is proposed. The idea of frequency separation is adopted by the network to process the high-frequency and low-frequency information of the image separately, so as to improve the ability of capturing high-frequency information and simplify the processing of low-frequency features. The base block in the generator is designed to integrate the spatial feature transformation layer into the dense wide activation residuals, which enhances the ability of deep feature representation while differentiating the local information. In addition, no-reference quality assessment network is designed specifically for super-resolution reconstructed images using Visual Geometry Group (VGG), which provides a new quality assessment loss for the reconstruction network and further improves the visual effect of reconstructed images. The experimental results show that the method has better reconstruction effect on multiple datasets than the current state-of-the-art similar methods. It is thus shown that super-resolution reconstruction using generative adversarial networks with the idea of frequency separation can effectively utilize the image frequency components and improve the reconstruction effect.
- Super-resolution /
- Generative adversarial network /
- Frequency separation /
- Quality assessment /
- Dense residual

HTML全文

圖 1 DR-QA-FSGAN網絡總體結構

下載: 全尺寸圖片幻燈片

圖 2 生成器

下載: 全尺寸圖片幻燈片

圖 3 帶SFT層的密集寬激活殘差塊DWRB

下載: 全尺寸圖片幻燈片

圖 4 質量評估網絡

下載: 全尺寸圖片幻燈片

圖 5 不同方法在BSDS100數據集“69015”圖像4倍超分辨率重構比較

下載: 全尺寸圖片幻燈片

圖 6 不同方法在自制數據集“02”圖像4倍超分辨率重構比較

下載: 全尺寸圖片幻燈片

圖 7 不同濾波器在Set5數據集“baby”圖像4倍超分辨率重構比較

下載: 全尺寸圖片幻燈片

圖 8 不同模塊在Set5數據集“butterfly”圖像4倍超分辨率重構比較

下載: 全尺寸圖片幻燈片

圖 9 不同損失函數在Set5數據集“bird”圖像4倍超分辨率重構比較

下載: 全尺寸圖片幻燈片

表 1 不同方法各數據集的PSNR (dB)和SSIM均值比較(×4)

算法	Set5		Set14		BSDS100		Manga109
算法	PSNR↑	SSIM↑	PSNR↑	SSIM↑	PSNR↑	SSIM↑	PSNR↑	SSIM↑
SRGAN^[11]	28.574	0.818	25.674	0.692	25.156	0.654	26.488	0.828
ESRGAN^[12]	30.438	0.852	26.278	0.699	25.323	0.651	28.245	0.859
SFTGAN^[14]	27.578	0.809	26.968	0.729	25.501	0.653	28.182	0.858
DSGAN^[17]	30.392	0.854	26.644	0.714	25.447	0.655	27.965	0.853
SRCGAN^[13]	28.068	0.789	26.071	0.696	25.659	0.657	25.295	0.796
FxSR^[15]	30.637	0.849	26.708	0.719	26.144	0.684	27.647	0.844
SROOE^[16]	30.862	0.866	27.231	0.731	26.195	0.687	27.852	0.849
WGSR^[19]	30.373	0.851	27.023	0.727	26.372	0.684	28.287	0.861
本文	30.904	0.872	27.715	0.749	26.838	0.701	28.312	0.867

下載: 導出CSV

表 2 自制數據集不同方法NIQE和FVSD平均值比較(×4)

算法	NIQE↓	FVSD↑
SRGAN^[11]	12.84	3.84
ESRGAN^[12]	8.62	6.46
SFTGAN^[14]	8.46	6.35
DSGAN^[17]	8.41	6.51
SRCGAN^[13]	10.21	4.25
FxSR^[15]	8.37	6.48
SROOE^[16]	8.19	6.49
WGSR^[19]	8.14	6.52
本文	8.11	6.54

下載: 導出CSV

表 3 不同濾波器重構效果的影響

濾波器	PSNR(dB)↑	SSIM↑
無	28.831	0.835
鄰域平均	28.941	0.833
高斯差分	29.015	0.837

下載: 導出CSV

表 4 含有不同模塊對應的PSNR (dB)和SSIM均值

分支結構	SFT層	質量評估網絡	PSNR (dB)↑	SSIM↑
$\surd $	$ \times $	$ \times $	28.772	0.828
$ \times $	$\surd $	$ \times $	28.402	0.821
$ \times $	$ \times $	$\surd $	28.642	0.823
$\surd $	$\surd $	$\surd $	29.015	0.837

下載: 導出CSV

表 5 不同損失函數的影響

損失組合	顏色損失		多層感知損失	對抗損失		FVSD損失	PSNR (dB)↑	SSIM↑
損失組合	Lcol	Lcol-1	多層感知損失	Ladv	Ladv-1	FVSD損失	PSNR (dB)↑	SSIM↑
組合1	$ \times $	$\surd $	$\surd $	$ \times $	$\surd $	$ \times $	28.352	0.818
組合2	$ \times $	$\surd $	$\surd $	$ \times $	$\surd $	$\surd $	28.831	0.835
組合3	$\surd $	$ \times $	$\surd $	$\surd $	$ \times $	$ \times $	28.437	0.821
本文	$\surd $	$ \times $	$\surd $	$\surd $	$ \times $	$\surd $	29.015	0.837

下載: 導出CSV

表 6 重構時間與參數量的比較

算法	重構時間	參數量(MB)
SRGAN^[11]	0.0401	1.51
ESRGAN^[12]	0.1603	16.69
SFTGAN^[14]	0.0664	1.83
DSGAN^[17]	0.1723	16.69
SRCGAN^[13]	0.0096	0.38
FxSR^[15]	0.3541	18.30
SROOE^[16]	0.3880	70.20
WGSR^[19]	0.1806	16.69
本文	0.1568	9.62

下載: 導出CSV
