針對組網雷達的無人機集群航跡欺騙綜合誤差分析
doi: 10.11999/JEIT240289 cstr: 32379.14.JEIT240289
-
1.
南京航空航天大學雷達成像與微波光子技術教育部重點實驗室 南京 210016
-
2.
電磁空間認知與智能控制技術實驗室 北京 100191
Comprehensive Error in UAV Cluster Trajectory Deception for Networked Radar
-
1.
Key Laboratory of Radar Imaging and Microwave Photonics, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
-
2.
Laboratory of Electromagnetic Space Cognition and Intelligent Control, Beijing 100191, China
-
摘要: 無人機集群在對組網雷達進行航跡欺騙過程中通過延時轉發截獲的雷達信號生成虛假目標點,而雷達站址誤差、無人機抖動誤差及轉發時延誤差均會造成虛假目標點偏離預設位置,進而使航跡欺騙效果惡化。針對上述問題,該文在雷達量測位置、無人機預設位置和欺騙距離已知以及組網雷達空間分辨單元(SRC)一定的情況下,分析了雷達站址誤差、無人機抖動誤差及轉發時延誤差同時存在時無人機集群成功欺騙組網雷達的邊界條件,并總結了上述誤差對航跡欺騙效果的影響規律。數值仿真結果表明,當3種誤差同時存在時,推導結果可以有效評估無人機集群對組網雷達的欺騙能力。
-
關鍵詞:
- 航跡欺騙 /
- 組網雷達 /
- 無人機集群 /
- 誤差分析
Abstract: In the process of trajectory deception against the networked radar using an Unmanned Aerial Vehicle (UAV) cluster, false target points are generated by delaying and forwarding intercepted radar signals. Errors such as radar station location errors, UAV jitter errors, and forwarding delay errors can all cause these false target points to deviate from their intended positions, thereby degrading the effectiveness of the deception. Considering known radar measurement positions, UAV preset positions, deception distances, and a specific Space Resolution Cell (SRC) of the networked radar, the boundary condition of successfully deceiving networked radar by a UAV cluster is analyzed in this paper. The impact patterns of these errors on deception effectiveness are also summarized in the paper. The numerical simulation results show that when all three kinds of errors are present, the derived results can effectively evaluate the deception ability of the UAV cluster to the networked radar.-
Key words:
- Trajectory deception /
- Networked radar /
- UAV cluster /
- Error analysis
-
表 1 坐標參數設置
名稱 位置 雷達R1 (0.00,0.00,0.00) 雷達R2 (8.00,6.00,0.00) 雷達R3 (14.00,20.00,0.00) 無人機A1 (4.25,10.20,17.00) 無人機A2 (5.75,10.50,15.00) 無人機A3 (8.15,14.80,13.00) 虛假目標點C (5.00,12.00,20.00) 下載: 導出CSV
表 2 組網雷達誤差和最小分辨率計算表
雷達站址誤差 無人機抖動誤差 轉發時延誤差(μs) 最小分辨率 $ {e_{r1}} \le 4\;250.0 $ $ {e_{j1}} = 0.0 $ $ {e_{t1}} = 0.0 $ $ {\delta _{\min }} = 1\;500.0 $ $ {e_{r2}} \le 2\;250.0 $ $ {e_{j2}} = 0.0 $ $ {e_{t2}} = 0.0 $ $ {e_{r3}} \le 1\;392.9 $ $ {e_{j3}} = 0.0 $ $ {e_{t3}} = 0.0 $ $ {e_{r1}} = 0.0 $ $ {e_{j1}} \le 637.5 $ $ {e_{t1}} = 0.0 $ $ {\delta _{\min }} = 1\;500.0 $ $ {e_{r2}} = 0.0 $ $ {e_{j2}} \le 562.5 $ $ {e_{t2}} = 0.0 $ $ {e_{r3}} = 0.0 $ $ {e_{j3}} \le 487.5 $ $ {e_{t3}} = 0.0 $ $ {e_{r1}} = 0.0 $ $ {e_{j1}} = 0.0 $ $ {e_{t1}} \le 5.0 $ $ {\delta _{\min }} = 1\;500.0 $ $ {e_{r2}} = 0.0 $ $ {e_{j2}} = 0.0 $ $ {e_{t2}} \le 5.0 $ $ {e_{r3}} = 0.0 $ $ {e_{j3}} = 0.0 $ $ {e_{t3}} \le 5.0 $ $ {e_{r1}} \le 700.0 $ $ {e_{j1}} = 150.0 $ $ {e_{t1}} = 3.0 $ $ {\delta _{\min }} = 1\;500.0 $ $ {e_{r2}} \le 725.0 $ $ {e_{j2}} = 100.0 $ $ {e_{t2}} = 2.5 $ $ {e_{r3}} \le 692.9 $ $ {e_{j3}} = 50.0 $ $ {e_{t3}} = 2.0 $ $ {e_{r1}} = 1\;200.0 $ $ {e_{j1}} \le 75.0 $ $ {e_{t1}} = 3.0 $ $ {\delta _{\min }} = 1\;500.0 $ $ {e_{r2}} = 800.0 $ $ {e_{j2}} \le 81.3 $ $ {e_{t2}} = 2.5 $ $ {e_{r3}} = 600.0 $ $ {e_{j3}} \le 82.5 $ $ {e_{t3}} = 2.0 $ $ {e_{r1}} = 1\;200.0 $ $ {e_{j1}} = 150.0 $ $ {e_{t1}} \le 2.4 $ $ {\delta _{\min }} = 1\;500.0 $ $ {e_{r2}} = 800.0 $ $ {e_{j2}} = 100.0 $ $ {e_{t2}} \le 2.3 $ $ {e_{r3}} = 600.0 $ $ {e_{j3}} = 50.0 $ $ {e_{t3}} \le 2.3 $ $ {e_{r1}} = 1\;200.0 $ $ {e_{j1}} = 150.0 $ $ {e_{t1}} = 3.0 $ $ {\delta _{\min }} \ge 1\;400.0 $ $ {e_{r2}} = 800.0 $ $ {e_{j2}} = 100.0 $ $ {e_{t2}} = 2.5 $ $ {e_{r3}} = 600.0 $ $ {e_{j3}} = 50.0 $ $ {e_{t3}} = 2.0 $ 下載: 導出CSV
-
[1] 蘭俊杰, 陳蓓, 徐廷新. 組網雷達發展現狀及其干擾技術[J]. 飛航導彈, 2009(12): 39–41. doi: 10.16338/j.issn.1009-1319.2009.12.019.LAN Junjie, CHEN Bei, and XU Tingxin. Development status and interference techniques of netted radar[J]. Aerodynamic Missile Journal, 2009(12): 39–41. doi: 10.16338/j.issn.1009-1319.2009.12.019. [2] 張養瑞. 對雷達網的多機伴隨式協同干擾技術研究[D]. [博士論文], 北京理工大學, 2015.ZHANG Yangrui. Research on key technologies of cooperative ECM in multi-syndrome jammers for countering radar net[D]. [Ph. D. dissertation], Beijing Institute of Technology, 2015. [3] 任鑫. 基于多無人機的組網雷達欺騙干擾技術研究[D]. [碩士論文], 電子科技大學, 2023. doi: 10.27005/d.cnki.gdzku.2023.001268.REN Xin. Research on deception of radar network using multiple electronic combat air vehicles[D]. [Master dissertation], University of Electronic Science and Technology of China, 2023. doi: 10.27005/d.cnki.gdzku.2023.001268. [4] 呂炫. 面向雷達網的無人載體協同干擾策略與技術研究[D]. [碩士論文], 電子科技大學, 2023. doi: 10.27005/d.cnki.gdzku.2023.002594.LV Xuan. Research on unmanned carrier cooperative jamming strategy and technology for radar network[D]. [Master dissertation], University of Electronic Science and Technology of China, 2023. doi: 10.27005/d.cnki.gdzku.2023.002594. [5] 郭文元. 針對組網雷達的協同干擾技術研究[D]. [碩士論文], 哈爾濱工程大學, 2021. doi: 10.27060/d.cnki.ghbcu.2021.000764.GUO Wenyuan. Research on cooperative jamming technology for netted radar[D]. [Master dissertation], Harbin Engineering University, 2021. doi: 10.27060/d.cnki.ghbcu.2021.000764. [6] 陳保亮. 多無人機對組網雷達系統的航跡欺騙干擾研究[J]. 艦船電子工程, 2019, 39(11): 89–92,166. doi: 10.3969/j.issn.1672-9730.2019.11.022.CHEN Baoliang. Research on multi-UAVs track deception jamming against network radar system[J]. Ship Electronic Engineering, 2019, 39(11): 89–92,166. doi: 10.3969/j.issn.1672-9730.2019.11.022. [7] FAN Zhe, GAO Xiaojing, JIN Yi, et al. Research on route planning of group UAV cooperation for deception jamming to radar network[C]. 2020 IEEE 4th Information Technology, Networking, Electronic and Automation Control Conference (ITNEC), Chongqing, China, 2020: 1966–1969. doi: 10.1109/ITNEC48623.2020.9085199. [8] 丁宸聰, 葉紫晴. 基于改進鯨魚算法的多無人機協同欺騙干擾技術[J]. 電訊技術, 2024, 64(1): 67–73. doi: 10.20079/j.issn.1001-893x.230213002.DING Chencong and YE Ziqing. Multi-UAV cooperative deception jamming technology based on improved whale optimization algorithm[J]. Telecommunication Engineering, 2024, 64(1): 67–73. doi: 10.20079/j.issn.1001-893x.230213002. [9] 劉宇蕊, 陳云陽, 余鑫. 基于改進粒子群優化算法的多無人機協同欺騙干擾技術[J]. 艦船電子對抗, 2024, 47(1): 72–76. doi: 10.16426/j.cnki.jcdzdk.2024.01.012.LIU Yurui, CHEN Yunyang, and YU Xin. Multi-UAV cooperative deception jamming technology based on improved particle swarm optimization algorithm[J]. Shipboard Electronic Countermeasure, 2024, 47(1): 72–76. doi: 10.16426/j.cnki.jcdzdk.2024.01.012. [10] 李松, 李佳琦, 王博文, 等. 無人機輔助空中計算的軌跡和功率聯合優化方法[J]. 電子與信息學報, 2024, 46(6): 2480–2487. doi: 10.11999/JEIT230917.LI Song, LI Jiaqi, WANG Bowen, et al. A joint optimization method for trajectory and power of unmanned aerial vehicle assisted over-the-air computation[J]. Journal of Electronics & Information Technology, 2024, 46(6): 2480–2487. doi: 10.11999/JEIT230917. [11] 趙艷麗, 李宏, 杜嘉薇, 等. 對空間探測雷達網的多機協同航跡欺騙干擾方法[J]. 電子與信息學報, 2023, 45(2): 585–591. doi: 10.11999/JEIT211575.ZHAO Yanli, LI Hong, DU Jiawei, et al. Multi-jammer cooperation track deception jamming method against space detection radar network[J]. Journal of Electronics & Information Technology, 2023, 45(2): 585–591. doi: 10.11999/JEIT211575. [12] 張磊, 羅迎, 張群. 雷達組網系統對抗有源干擾方法綜述[J]. 信息對抗技術, 2023, 2(6): 1–16. doi: 10.12399/j.issn.2097-163x.2023.06.001.ZHANG Lei, LUO Ying, and ZHANG Qun. Review of countermeasures against active jamming for radar network[J]. Information Countermeasure Technology, 2023, 2(6): 1–16. doi: 10.12399/j.issn.2097-163x.2023.06.001. [13] 時晨光, 聞雯, 宋海偉, 等. 針對組網雷達的無人機集群轉發式欺騙干擾時延誤差研究[J]. 航空兵器, 2024, 31(2): 131–137. doi: 10.12132/ISSN.1673-5048.2023.0143.SHI Chenguang, WEN Wen, SONG Haiwei, et al. Research on delay error of UAV swarm repeater deception jamming against networked radar[J]. Aero Weaponry, 2024, 31(2): 131–137. doi: 10.12132/ISSN.1673-5048.2023.0143. [14] LIU Xiang and LI Dongsheng. A three-dimensional phantom track generation for radar network deception (January 2019)[J]. IEEE Access, 2019, 7: 27288–27301. doi: 10.1109/ACCESS.2019.2894409. [15] 王國宏, 楊忠, 吳健平. 雷達站站址誤差對多機協同航跡欺騙干擾的影響分析[J]. 海軍航空工程學院學報, 2015, 30(6): 501–504,510. doi: 10.7682/j.issn.1673-1522.2015.06.001.WANG Guohong, YANG Zhong, and WU Jianping. Influence analysis of radar location error on multi-aircraft cooperative track deception[J]. Journal of Naval Aeronautical and Astronautical University, 2015, 30(6): 501–504,510. doi: 10.7682/j.issn.1673-1522.2015.06.001. [16] 柏鵬, 王玉冰, 梁曉龍, 等. 無人機對雷達組網航跡欺騙綜述[J]. 航空學報, 2020, 41(10): 23912.BAI Peng, WANG Yubing, LIANG Xiaolong, et al. Phantom track deception against radar networks using UAVs: Review[J]. Acta Aeronautica et Astronautica Sinica, 2020, 41(10): 23912. -
