借助語音和面部圖像的雙模態情感識別

薛珮蕓; 戴書濤; 白靜; 高翔

doi:10.11999/JEIT240087

借助語音和面部圖像的雙模態情感識別

doi: 10.11999/JEIT240087 cstr: 32379.14.JEIT240087

薛珮蕓^{1, 2, ,},
戴書濤¹,
白靜¹,
高翔¹

1.
太原理工大學電子信息與光學工程學院太原 030024
2.
山西省高等創新研究院博士后工作站太原 030032

基金項目: 山西省青年基金 (20210302124544)，山西省應用基礎研究計劃(201901D111094)

詳細信息

作者簡介:
薛珮蕓：女，講師，研究方向為信號處理

戴書濤：男，碩士生，研究方向為信號處理

白靜：女，教授，研究方向為信號處理

高翔：男，碩士生，研究方向為信號處理

通訊作者:
薛珮蕓　xuepeiyun@tyut.edu.cn

中圖分類號: TN911.7; TP391.41
計量
- 文章訪問數: 388
- HTML全文瀏覽量: 210
- PDF下載量: 77
- 被引次數: 0
出版歷程
- 收稿日期: 2024-02-05
- 修回日期: 2024-11-06
- 網絡出版日期: 2024-11-08
- 刊出日期: 2024-12-01

Emotion Recognition with Speech and Facial Images

XUE Peiyun^{1, 2
, ,},
DAI Shutao¹,
BAI Jing¹,
GAO Xiang¹

1.
Taiyuan University of Technology, College of Electronic Information and Optical Engineering, Taiyuan 030024, China
2.
Shanxi Advanced Innovation Research Institute, Postdoctoral orkstation, Taiyuan 030032, China

Funds: Shanxi Youth Fundation (20210302124544), The Applied Basic Research Program of Shanxi Province (201901D111094)

摘要

摘要: 為提升情感識別模型的準確率，解決情感特征提取不充分的問題，對語音和面部圖像的雙模態情感識別進行研究。語音模態提出一種結合通道-空間注意力機制的多分支卷積神經網絡(Multi-branch Convolutional Neural Networks, MCNN)的特征提取模型，在時間、空間和局部特征維度對語音頻譜圖提取情感特征；面部圖像模態提出一種殘差混合卷積神經網絡(Residual Hybrid Convolutional Neural Network, RHCNN)的特征提取模型，進一步建立并行注意力機制關注全局情感特征，提高識別準確率；將提取到的語音和面部圖像特征分別通過分類層進行分類識別，并使用決策融合對識別結果進行最終的融合分類。實驗結果表明，所提雙模態融合模型在RAVDESS, eNTERFACE’05, RML三個數據集上的識別準確率分別達到了97.22%, 94.78%和96.96%，比語音單模態的識別準確率分別提升了11.02%, 4.24%, 8.83%，比面部圖像單模態的識別準確率分別提升了4.60%, 6.74%, 4.10%，且與近年來對應數據集上的相關方法相比均有所提升。說明了所提的雙模態融合模型能有效聚焦情感信息，從而提升情感識別的準確率。
- 情感識別 /
- 注意力機制 /
- 多分支卷積 /
- 殘差混合 /
- 決策融合
Abstract: In order to improve the accuracy of emotion recognition models and solve the problem of insufficient emotional feature extraction, this paper conducts research on bimodal emotion recognition involving audio and facial imagery. In the audio modality, a feature extraction model of a Multi-branch Convolutional Neural Network (MCNN) incorporating a channel-space attention mechanism is proposed, which extracts emotional features from speech spectrograms across time, space, and local feature dimensions. For the facial image modality, a feature extraction model using a Residual Hybrid Convolutional Neural Network (RHCNN) is introduced, which further establishes a parallel attention mechanism that concentrates on global emotional features to enhance recognition accuracy. The emotional features extracted from audio and facial imagery are then classified through separate classification layers, and a decision fusion technique is utilized to amalgamate the classification results. The experimental results indicate that the proposed bimodal fusion model has achieved recognition accuracies of 97.22%, 94.78%, and 96.96% on the RAVDESS, eNTERFACE’05, and RML datasets, respectively. These accuracies signify improvements over single-modality audio recognition by 11.02%, 4.24%, and 8.83%, and single-modality facial image recognition by 4.60%, 6.74%, and 4.10%, respectively. Moreover, the proposed model outperforms related methodologies applied to these datasets in recent years. This illustrates that the advanced bimodal fusion model can effectively focus on emotional information, thereby enhancing the overall accuracy of emotion recognition.
- Emotion recognition /
- Attention mechanism /
- Multi-branch convolution /
- Residual mixing /
- Decision fusion

HTML全文

圖 1 雙模態情感識別模型總體結構

下載: 全尺寸圖片幻燈片

圖 2 對數梅爾頻譜圖提取流程

下載: 全尺寸圖片幻燈片

圖 3 MCNN結構

下載: 全尺寸圖片幻燈片

圖 4 RHCNN網絡結構

下載: 全尺寸圖片幻燈片

圖 5 并行注意力機制

下載: 全尺寸圖片幻燈片

圖 6 決策融合算法

下載: 全尺寸圖片幻燈片

圖 7 語音模型混淆矩陣

下載: 全尺寸圖片幻燈片

圖 8 面部圖像模型混淆矩陣

下載: 全尺寸圖片幻燈片

圖 9 雙模態混淆矩陣

下載: 全尺寸圖片幻燈片

圖 10 不同模塊對模型性能的有效性驗證

下載: 全尺寸圖片幻燈片

圖 11 不同數據量對模型性能的影響

下載: 全尺寸圖片幻燈片

表 1 語音模型各類情感識別結果(%)

類別	RAVDESS				RML				eNTERFACE’05
類別	P	R	S	F1	P	R	S	F1	P	R	S	F1
中性	83.22	87.94	98.84	85.52	–	–	–	–	–	–	–	–
平靜	86.94	88.35	97.94	87.64	–	–	–	–	–	–	–	–
快樂	79.86	97.46	97.20	87.79	78.12	92.59	95.62	84.75	95.66	95.94	99.12	95.80
悲傷	80.46	78.64	97.04	79.56	91.95	78.82	98.47	84.88	94.59	90.27	99.01	92.38
憤怒	87.03	84.62	97.93	85.80	96.09	94.51	99.25	95.29	84.44	87.99	96.85	86.18
恐懼	85.40	91.06	97.65	88.14	83.43	82.51	96.80	82.97	85.15	88.68	96.90	87.36
厭惡	90.66	83.61	98.41	87.00	86.50	87.37	97.07	86.93	91.83	93.68	98.30	92.75
驚訝	94.31	82.30	99.19	87.89	93.30	94.27	98.60	93.78	92.15	85.67	98.47	88.79

下載: 導出CSV

表 2 語音模態已有方法與本文模型在準確率上的對比(%)

數據集	CNN-Transformer^[18]	2D Feature Extration+ SVM^[19]	CNN-BiLSTM^[20]	CNN-X^[21]	3D-CNN^[22]	DCNN-GWO^[23]	Auto-encoder+ SVM^[24]	Multi-label model^[25]	本文方法
RAVDESS	82.0	81.94	84.72	82.99	–	–	–	–	86.20
RML	–	–	–	–	–	–	74.07	84.72	88.13
eNTERFACE’05	–	–	–	–	88.47	90.40	–	–	90.54

下載: 導出CSV

表 3 面部圖像模型各類情感識別結果(%)

類別	RAVDESS				RML				eNTERFACE’05
類別	P	R	S	F1	P	R	S	F1	P	R	S	F1
中性	91.95	91.33	99.44	91.64	–	–	–	–	–	–	–	–
平靜	95.22	93.44	99.24	94.32	–	–	–	–	–	–	–	–
快樂	94.79	92.54	99.25	93.65	96.84	97.35	99.36	97.10	89.31	88.29	97.82	88.79
悲傷	94.04	92.21	99.10	93.11	93.22	88.24	98.71	90.66	86.62	84.21	97.57	85.40
憤怒	92.41	93.59	98.80	92.99	91.67	95.38	98.42	93.48	87.61	89.68	97.48	88.63
恐懼	87.27	92.13	97.95	89.63	91.35	87.56	98.27	89.42	87.04	87.78	97.29	87.41
沮喪	94.58	96.62	99.09	95.59	93.75	94.74	98.71	94.24	90.42	89.68	97.99	90.81
驚訝	90.39	87.89	98.66	89.12	90.31	94.15	97.96	92.19	87.01	86.75	97.49	86.88

下載: 導出CSV

表 4 面部圖像模態經典網絡與本文結果對比(%)

數據集	方法	A	R	S	F1
RAVDESS	ResNet-34^[26]	88.37	88.64	98.34	88.19
	ShuffleNetV2^[27]	82.03	82.06	97.43	81.60
	MobileNetV2^[28]	84.03	84.46	97.71	83.86
	本文方法	92.62	92.47	98.94	92.51
RML	ResNet-34^[26]	89.29	89.41	97.86	89.27
	ShuffleNetV2^[27]	79.55	79.82	95.95	79.24
	MobileNetV2^[28]	86.07	86.33	97.22	86.05
	本文方法	92.86	92.90	98.57	92.85
eNTERFACE’05	ResNet-34^[26]	83.30	83.57	96.67	83.28
	ShuffleNetV2^[27]	82.13	82.17	96.43	82.04
	MobileNetV2^[28]	83.50	83.68	96.70	83.49
	本文方法	88.04	87.98	97.61	87.99

下載: 導出CSV

表 5 雙模態模型各類情感識別結果(%)

類別	RAVDESS				RML				eENTERFACE’05
類別	P	R	S	F1	P	R	S	F1	P	R	S	F1
中性	98.66	96.71	99.91	97.67	–	–	–	–	–	–	–	–
平靜	100.00	98.13	100.00	99.05	–	–	–	–	–	–	–	–
快樂	97.57	96.56	99.65	97.06	96.95	98.96	99.37	97.95	96.53	96.53	99.00	96.53
悲傷	96.36	97.98	99.45	97.16	97.22	95.63	99.48	96.42	95.54	95.24	98.59	95.39
憤怒	98.10	95.38	99.70	96.72	98.91	99.45	99.79	99.18	95.18	94.83	98.41	94.96
恐懼	93.48	96.47	98.95	94.95	95.24	93.75	99.06	94.49	92.44	94.56	99.30	93.48
沮喪	96.99	98.47	99.49	97.72	98.02	95.59	99.58	97.30	93.24	93.77	99.19	93.50
驚訝	97.51	97.86	99.65	97.68	95.50	97.45	99.06	96.46	96.07	93.81	99.24	94.93

下載: 導出CSV

表 6 雙模態已有方法與本文結果對比(%)

數據集	文獻[29] 方法	文獻[30] 方法	文獻[31] 方法	文獻[32] 方法	文獻[33] 方法	文獻[34] 方法	文獻[35] 方法	文獻[36] 方法	文獻[37] 方法	本文方法
RAVDESS	86.0	86.7	87.5	87.89	82.99-	–	93.23	–	–	97.22
RML	–	–	–	–	82.47	–	–	–	96.79	96.96
eNTERFACE’05	–	–	–	–	72.27	91.62	88.11	87.2	–	94.78

下載: 導出CSV
