不完美信道狀態信息下的多輸入單輸出共生無線電系統資源分配算法

徐勇軍; 王名揚; 田秦語; 張海波; 薛青

doi:10.11999/JEIT231366

不完美信道狀態信息下的多輸入單輸出共生無線電系統資源分配算法

doi: 10.11999/JEIT231366 cstr: 32379.14.JEIT231366

重慶郵電大學通信與信息工程學院重慶 400065

基金項目: 國家自然科學基金(U23A20279, 62271094)，重慶市自然科學基金重點項目(CSTB2022NSCQ-LZX0009, CSTB2023NSCQ-LZX0079)，重慶市教委科技重點項目(KJZD-K202200601)，重慶郵電大學高等科學研究院項目(E011A2022324)

詳細信息

作者簡介:
徐勇軍：男，教授，博士生導師，研究方向?yàn)榉聪蛏⑸渫ㄐ拧⒅悄芊瓷涿?、資源分配等

王名揚：女，碩士生，研究方向?yàn)楣采鸁o(wú)線電、資源分配等

田秦語：男，碩士生，研究方向?yàn)橹悄芊瓷涿?、共生無線電等

張海波：男，副教授，研究方向?yàn)闊o(wú)線資源管理等

薛青：女，講師，研究方向?yàn)楹撩撞ㄍㄐ诺?/p>

通訊作者:
徐勇軍　xuyj@cqupt.edu.cn

1¹⁾ 在不完美CSI下，由于共生系統的優化，主次系統中都存在優化變量和不完美CSI，同時需要保證每類用戶的最低速率，因此問題求解難度較大。
中圖分類號: TN929.5
計量
- 文章訪問數: 346
- HTML全文瀏覽量: 128
- PDF下載量: 83
- 被引次數: 0
出版歷程
- 收稿日期: 2023-12-11
- 修回日期: 2024-11-22
- 網絡出版日期: 2024-11-28
- 刊出日期: 2024-12-01

Resource Allocation Algorithm for Multiple-Input Single-Output Symbiotic Radio with Imperfect Channel State Information

School of Communications and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (U23A20279, 62271094), The Key Fund of Natural Science Foundation of Chongqing (CSTB2022NSCQ-LZX0009, CSTB2023NSCQ-LZX0079), The Scientific and Technological Research Program of Chongqing Municipal Education Commission (KJZD-K202200601), The Institute for Advanced Sciences, Chongqing University of Posts and Telecommunication (E011A2022324)

摘要

摘要: 針對信道估計誤差會導致傳統最優資源分配算法失效的問題，該文提出一種基于不完美信道狀態信息(CSI)的多輸入單輸出(MISO)共生無線電系統魯棒資源分配算法。考慮每個用戶最小吞吐量約束、傳輸時間約束、基站最大發射功率約束和用戶反射系數約束，基于有界信道不確定性模型，建立了一個傳輸時間、波束成形向量和反射系數聯合優化的魯棒吞吐量最大化資源分配問題。利用拉格朗日對偶、變量替換和交替優化方法將原問題轉換成凸優化問題求解。仿真結果表明，與傳統非共生資源分配算法相比，所提算法的吞吐量提升11.7%，中斷概率減小5.31%。
- 共生無線電 /
- 魯棒資源分配 /
- 吞吐量最大化
Abstract: To overcome the effect of channel estimation errors on the ineffectiveness of conventional optimal resource allocation algorithms, a robust resource allocation algorithm with imperfect Channel State Information(CSI) is proposed in Multiple-Input Single-Output(MISO) symbiotic radio systems. Considering the constraints of the minimum throughput of users, transmission time, maximum transmit power of the base station, and the reflection coefficients of users, based on bounded channel uncertainties, a robust throughput-maximization resource allocation problem is formulated by jointly optimizing transmission time, beamforming vectors, and reflection coefficients. The original problem is transformed into a convex problem by applying the Lagrange dual theory, the variable substitution, and the alternating optimizing methods. Simulation results verified that the throughput of the proposed algorithm is improved by 11.7% and the outage probability is reduced by 5.31% by comparing it with the non-robust resource allocation algorithm.
- Symbiotic Radio(SR) /
- Robust resource allocation /
- Throughput maximization

HTML全文

圖 1 系統模型

下載: 全尺寸圖片幻燈片

圖 2 算法流程圖

下載: 全尺寸圖片幻燈片

圖 3 本文算法的收斂性能

下載: 全尺寸圖片幻燈片

圖 4 不同算法系統總吞吐量與天線數量的關系

下載: 全尺寸圖片幻燈片

圖 5 不同算法系統總吞吐量與反向散射設備數量的關系

下載: 全尺寸圖片幻燈片

圖 6 不同算法下系統總吞吐量與估計誤差上界的關系

下載: 全尺寸圖片幻燈片

圖 7 不同算法下系統總吞吐量與最大發射功率門限的關系

下載: 全尺寸圖片幻燈片

圖 8 不同算法下的中斷概率性能對比

下載: 全尺寸圖片幻燈片

表 1 相關工作總結

文獻	網絡類型	用戶數	CSI	優化變量			目標函數
文獻	網絡類型	用戶數	CSI	傳輸時間	反射系數	波束成形	目標函數
[5]	SISO SR	單用戶	完美	×	√	×	Max:加權和速率
[6]	MISO SR	單用戶	完美	×	×	√	Min:傳輸功率,Max:能效
[7]	MISO SR	多用戶	完美	√	√	×	Max:能效
[8]	MISO NOMA-TDMA SR	多用戶	完美	√	√	×	Max:最小吞吐量
[9]	MISO 全雙工+NOMA-TDMA SR	多用戶	完美	√	√	×	Max:最小吞吐量
[10]	SISO RIS+SR	多用戶	完美	×	√	×	Max:能效
[11]	MISO RIS+SR	單用戶	完美	×	√	√	Max:能效
[12]	MISO RIS+SR+NOMA	多用戶	完美	√	×	×	Max:資源效率
[13]	SISO RIS+UAV+SR	單用戶	完美	×	×	×	Min:加權和誤碼率
[14]	MISO SR	多用戶	完美	×	√	×	Min: SNR
[15]	MISO SR+竊聽者	單用戶	完美	×	√	×	Max:保密速率
[16]	MIMO RIS+SR	單用戶	完美	×	√	×	Min:傳輸功率
[17]	MISO RIS+SR	單用戶	不完美	×	×	√	Min:傳輸功率
[18]	MISO RIS+SR	單用戶	不完美	×	√	√	Min:傳輸功率
本文	MISO SR	多用戶	不完美	√	√	√	Max:吞吐量

下載: 導出CSV

1 基于迭代的魯棒吞吐量最大化算法

初始化系統參數：$K$, ${\delta ^2}$, $N$, $B$, $T$；初始化迭代次數$l = 0$；　定義最大迭代次數${L_{\max }}$和收斂精度$\varpi $；
(1) WHILE 　　$ \left\| {\displaystyle\sum\nolimits_{k = 1}^K {{{\left( {R_k^{\text{u}} + R_k^{\text}} \right)}^{(l)}}} - \displaystyle\sum\nolimits_{k = 1}^K {{{\left( {R_k^{\text{u}} + R_k^{\text}} \right)}^{(l - 1)}}} } \right\| \ge \varpi $ 或　　$l \le {L_{\max }}$ DO
(2) 設置迭代次數$l = l + 1$；
(3) 固定$t_k^{(l - 1)}$和$\theta _k^{(l - 1)}$，根據式(26)計算${{{\boldsymbol{W}}}^{(l)}}$；若${{{\boldsymbol{W}}}^{(l)}}$的秩　　為1，則使用特征值分解法得到最優解；若${{{\boldsymbol{W}}}^{(l)}}$的秩大于1，　　采用高斯隨機化方法得到近似解；
(4) 固定${{{\boldsymbol{W}}}^{(l)}}$，根據式(32)求解$t_k^{(l)}$和$\theta _k^{(l)}$；
(5) 更新吞吐量$ \displaystyle\sum\nolimits_{k = 1}^K {\left( {R_k^{\text{u}} + R_k^{\text}} \right)} $。
(6) END WHILE

下載: 導出CSV

參考文獻(22)

[1]	ZHANG Qianqian, LIANG Yingchang, YANG Hongchuan, et al. Mutualistic mechanism in symbiotic radios: When can the primary and secondary transmissions be mutually beneficial?[J]. IEEE Transactions on Wireless Communications, 2022, 21(10): 8036–8050. doi: 10.1109/TWC.2022.3163735.
[2]	HU Jinlin, LIANG Yingchang, and PEI Yiyang. Reconfigurable intelligent surface enhanced multi-user MISO symbiotic radio system[J]. IEEE Transactions on Communications, 2021, 69(4): 2359–2371. doi: 10.1109/TCOMM.2020.3047444.
[3]	未來移動通信論壇. 未來IMT通信系統頻譜研究白皮書(2024年)[R]. 2024.
[4]	LIANG Yingchang, ZHANG Qianqian, LARSSON E G, et al. Symbiotic radio: Cognitive backscattering communications for future wireless networks[J]. IEEE Transactions on Cognitive Communications and Networking, 2020, 6(4): 1242–1255. doi: 10.1109/TCCN.2020.3023139.
[5]	GUO Huayan, LIANG Yingchang, LONG Ruizhe, et al. Resource allocation for symbiotic radio system with fading channels[J]. IEEE Access, 2019, 7: 34333–34347. doi: 10.1109/ACCESS.2019.2904612.
[6]	CHU Zheng, HAO Wanming, XIAO Pei, et al. Resource allocations for symbiotic radio with finite blocklength backscatter link[J]. IEEE Internet of Things Journal, 2020, 7(9): 8192–8207. doi: 10.1109/JIOT.2020.2980928.
[7]	YANG Haohang, YE Yinghui, LIANG Kai, et al. Energy efficiency maximization for symbiotic radio networks with multiple backscatter devices[J]. IEEE Open Journal of the Communications Society, 2021, 2: 1431–1444. doi: 10.1109/OJCOMS.2021.3090836.
[8]	ZHANG Ronghaixiang, KANG Xin, and LIANG Yingchang. Minimum throughput maximization for peer-assisted NOMA-plus-TDMA symbiotic radio networks[J]. IEEE Wireless Communications Letters, 2021, 10(9): 1847–1851. doi: 10.1109/LWC.2021.3083841.
[9]	LIAO Yating, YANG Gang, and LIANG Yingchang. Resource allocation in NOMA-enhanced full-duplex symbiotic radio networks[J]. IEEE Access, 2020, 8: 22709–22720. doi: 10.1109/ACCESS.2020.2967153.
[10]	LI Jing, LI Xin, BI Yanjun, et al. Energy-efficient joint resource allocation with reconfigurable intelligent surfaces in symbiotic radio networks[J]. IEEE Transactions on Cognitive Communications and Networking, 2022, 8(4): 1816–1827. doi: 10.1109/TCCN.2022.3188986.
[11]	ZHOU Chunyu, XU Yongjun, LI Dong, et al. Energy-efficient maximization for RIS-aided MISO symbiotic radio systems[J]. IEEE Transactions on Vehicular Technology, 2023, 72(10): 13689–13694. doi: 10.1109/TVT.2023.3274796.
[12]	WU Mingjiang, LEI Xianfu, ZHOU Xiangyun, et al. RIS-assisted energy- and spectrum-efficient symbiotic transmission in NOMA systems[J]. IEEE Transactions on Communications, 2023, 71(5): 2801–2815. doi: 10.1109/TCOMM.2023.3241355.
[13]	HUA Meng, YANG Luxi, WU Qingqing, et al. UAV-assisted intelligent reflecting surface symbiotic radio system[J]. IEEE Transactions on Wireless Communications, 2021, 20(9): 5769–5785. doi: 10.1109/TWC.2021.3070014.
[14]	HAN Shiying, LIANG Yingchang, and SUN Guiling. The design and optimization of random code assisted Multi-BD symbiotic radio system[J]. IEEE Transactions on Wireless Communications, 2021, 20(8): 5159–5170. doi: 10.1109/TWC.2021.3065941.
[15]	AL-NAHARI A, J?NTTI R, ZHENG Gan, et al. Ergodic secrecy rate analysis and optimal power allocation for symbiotic radio networks[J]. IEEE Access, 2023, 11: 82327–82337. doi: 10.1109/ACCESS.2023.3301186.
[16]	ZHANG Qianqian, LIANG Yingchang, and POOR H V. Reconfigurable intelligent surface assisted MIMO symbiotic radio networks[J]. IEEE Transactions on Communications, 2021, 69(7): 4832–4846. doi: 10.1109/TCOMM.2021.3070043.
[17]	ZHOU Hu, KANG Xin, LIANG Yingchang, et al. Cooperative beamforming for reconfigurable intelligent surface-assisted symbiotic radios[J]. IEEE Transactions on Vehicular Technology, 2022, 71(11): 11677–11692. doi: 10.1109/TVT.2022.3190515.
[18]	吳翠先, 周春宇, 徐勇軍, 等. 智能反射面輔助的多入單出共生無線電魯棒安全資源分配算法[J]. 電子與信息學報, 2024, 46(4): 1203–1211. doi: 10.11999/JEIT230426. WU Cuixian, ZHOU Chunyu, XU Yongjun, et al. Robust secure resource allocation algorithm for multiple input single output symbiotic radio with reconfigurable intelligent surface assistance[J]. Journal of Electronics & Information Technology, 2024, 46(4): 1203–1211. doi: 10.11999/JEIT230426.
[19]	徐勇軍, 姜思巧, 王公仆, 等. 基于不完美CSI的認知反向散射通信吞吐量最大化算法[J]. 電子與信息學報, 2023, 45(7): 2325–2333. doi: 10.11999/JEIT221483. XU Yongjun, JIANG Siqiao, WANG Gongpu, et al. Throughput maximization algorithm for cognitive backscatter communication with imperfect CSI[J]. Journal of Electronics & Information Technology, 2023, 45(7): 2325–2333. doi: 10.11999/JEIT221483.
[20]	BOYD S and VANDENBERGHE L. Convex Optimization[M]. Cambridge: Cambridge University Press, 2004.
[21]	WU Tuo, JIANG Miao, ZHANG Qi, et al. Beamforming design in multiple-input-multiple-output symbiotic radio backscatter systems[J]. IEEE Communications Letters, 2021, 25(6): 1949–1953. doi: 10.1109/LCOMM.2021.3060468.
[22]	HEIDARPOUR A R, ARDAKANI M, TELLAMBURA C, et al. Network-coded cooperative systems in cognitive radio networks[J]. IEEE Transactions on Wireless Communications, 2022, 21(12): 11011–11023. doi: 10.1109/TWC.2022.3188729.
