強稀疏低副瓣近場聚焦稀疏陣列三維成像

楊磊; 宋昊; 申瑞陽; 陳英杰; 胡仲偉; 霍鑫; 邢孟道

doi:10.11999/JEIT231278

強稀疏低副瓣近場聚焦稀疏陣列三維成像

doi: 10.11999/JEIT231278 cstr: 32379.14.JEIT231278

1.
中國民航大學電子信息與自動化學院天津 300300
2.
西安電子科技大學雷達信號處理國家重點實驗室西安 710071

基金項目: 國家自然科學基金(62271487)

詳細信息

作者簡介:
楊磊：男，教授，研究方向為高分辨SAR成像及機器學習理論應用

宋昊：男，碩士生，研究方向為毫米波成像與稀疏陣列構型設計

申瑞陽：男，碩士生，研究方向為毫米波成像與稀疏陣列構型設計

陳英杰：男，碩士生，研究方向為毫米波成像與稀疏陣列構型設計

胡仲偉：男，講師，研究方向為高分辨SAR成像及優化學習理論

霍鑫：男，碩士生，研究方向為毫米波成像與稀疏陣列構型設計

邢孟道：男，教授，研究方向為雷達成像、動目標檢測

通訊作者:
楊磊 email:　yanglei840626@163.com

中圖分類號: TN957
計量
- 文章訪問數: 243
- HTML全文瀏覽量: 133
- PDF下載量: 45
- 被引次數: 0
出版歷程
- 收稿日期: 2023-11-20
- 修回日期: 2024-11-10
- 網絡出版日期: 2024-11-19
- 刊出日期: 2024-12-01

High Sparsity and Low Sidelobe Near-field Focused Sparse Array for Three-Dimensional Imagery

1.
College of Electronic Information and Automation, Civil Aviation University of China, Tianjin 300300, China
2.
National Laboratory of Radar Signal Processing, Xidian University, Xi’an 710071, China

Funds: The National Natural Science Foundation of China (62271487)

摘要

摘要: 在主動式電掃描毫米波安檢成像中，均勻陣列天線存在成本受限以及復雜度高等瓶頸問題，難以在實際工程中大規模運用。由此，該文提出一種強稀疏低副瓣的近場聚焦稀疏陣列設計方法，并進一步利用改進3維時域成像算法實現高精度3維重建。首先，以近場聚焦位置以及峰值旁瓣電平為約束，以權向量的$ {\ell _p} $(0<p<1)范數正則化為目標函數，構建近場聚焦稀疏陣列天線優化模型。然后，通過引入輔助變量，建立旁瓣及聚焦位置約束與輔助變量間的等價代換模型，解決陣列權向量目標函數與復雜約束耦合帶來的求解難題，通過等價代換思想對模型化簡并求解。接著，采用復數求導結合啟發式近似方法對陣列激勵以及位置進行優化選擇。最后，利用交替方向多乘子法(ADMM)實現聚焦位置、峰值旁瓣約束以及陣列激勵協同求解，通過改進3維時域成像算法實現稀疏陣列3維成像。仿真模擬實驗結果顯示，該方法可以在滿足陣列天線輻射特性以及近場聚焦條件下，以更少的陣元數目獲得更低的旁瓣電平。此外，采用實測數據驗證稀疏陣列改進3維時域成像算法高精度、高效率的優勢。
- 近場成像 /
- 稀疏陣列 /
- 3維成像 /
- 交替方向多乘子法
Abstract: In active electrical scanning millimeter-wave security imaging, the uniform array antenna has the bottleneck of uncontrolled cost and high complexity, which is difficult to be widely applied in practices. To this end, a near-field focused sparse array design algorithm for high sparsity and low sidelobes is proposed in this paper. It applies an improved three dimensional (3D) time-domain imaging algorithm to achieve high-accuracy 3D reconstruction. Firstly, the near-field focusing sparse array antenna model is constructed by taking the near-field focusing position and peak sidelobe level as constraints, where the $ {\ell _p} $(0<p<1) norm of the weight vector regularization is established as the objective function. Secondly, by introducing auxiliary variables and establishing equivalent substitution models between sidelobe and focus position constraints and auxiliary variables, the problem of solving the array weight vector in the coupling of the objective function and complex constraints is developed. The model is simplified and solved through the idea of equivalent substitution. Then, the array excitation and position are optimized using a combination of complex number differentiation and heuristic approximation methods. Finally, the Alternating Direction Method of Multipliers (ADMM) is employed to achieve the focus position, peak sidelobe constraint, and array excitation in a cooperative manner. The sparse array 3D imaging is realized by improving the 3D time-domain imaging algorithm. The experimental results show that the proposed method is capable of obtaining lower sidelobe level with fewer array elements under the condition of satisfying the radiation characteristics of array antenna and near-field focusing. Applying raw millimeter-wave data, the advantages of sparse array 3D time-domain imaging algorithm are verified in terms of high accuracy and high efficiency.
- Near field imaging /
- Sparse array /
- Three-dimensional imaging /
- Alternating Direction Method of Multipliers (ADMM)

HTML全文

圖 1 圓柱體掃描毫米波安檢成像幾何示意圖

下載: 全尺寸圖片幻燈片

圖 2 笛卡爾坐標系下近場線性陣列天線模型

下載: 全尺寸圖片幻燈片

圖 3 距離-高度維局部極坐標網格

下載: 全尺寸圖片幻燈片

圖 4 3維場景成像切片劃分

下載: 全尺寸圖片幻燈片

圖 5 不同算法下天線方向圖對比

下載: 全尺寸圖片幻燈片

圖 6 陣元位置分布及其對應激勵值

下載: 全尺寸圖片幻燈片

圖 7 輔助變量收斂曲線

下載: 全尺寸圖片幻燈片

圖 8 均勻陣列與稀疏陣列成像結果對比

下載: 全尺寸圖片幻燈片

圖 9 均勻陣列與稀疏陣列點目標成像結果剖面圖

下載: 全尺寸圖片幻燈片

1 稀疏陣列優化算法

(1)初始化：$ {{\boldsymbol{\gamma}} ^{\mathrm{r}}}(0) $, $ {{\boldsymbol{\gamma}} ^{\mathrm{i}}}(0) $, $ {{\boldsymbol{\varsigma}} ^{\mathrm{r}}}(0) $, $ {{\boldsymbol{\varsigma}} ^{\mathrm{i}}}(0) $, $ {\boldsymbol{w}}(0) $，給定循環的迭代　次數$ K $, $ N $
(2) for $ i = 0,1, \cdots ,K $
步驟1　得到$ {q_0}(i + 1) $和$ {g_s}(i + 1) $通過式(12)–式(16)
步驟2　求解$ {\boldsymbol{w}}(i + 1) $
for $ k = 0,1, \cdots ,N $
(1)得到關于$ {\boldsymbol{w}} $非線性方程通過式(17)–式(21)
(2)確定$ {{\boldsymbol{w}}^{(k)}}(i + 1) $通過式(22)
End for $ k = N $
步驟3　通過式(23)更新$ {{\boldsymbol{\gamma}} ^{\mathrm{r}}}(i + 1) $, $ {{\boldsymbol{\gamma}} ^{\mathrm{i}}}(i + 1) $, $ {{\boldsymbol{\varsigma}} ^{\mathrm{r}}}(i + 1) $, $ {{\boldsymbol{\varsigma}} ^{\mathrm{i}}}(i + 1) $
end for $ i = K $
得到最終陣列權值向量的結果$ {\boldsymbol{w}} $

下載: 導出CSV

表 1 圓周柱面陣列天線實測數據參數

雷達參數	數值	雷達參數	數值	雷達參數	數值
系統工作帶寬	6.5 GHz	方位/俯仰波束角	55°/55°	旋轉次數	314
工作頻率	27 GHz	單脈沖采樣點數	64	單次旋轉角度	0.2867°
目標距離	0.4～0.8 m	陣元間距	0.0052 m	旋轉半徑	0.628 m

下載: 導出CSV

表 2 均勻陣列與稀疏陣列點目標成像結果剖面圖定量分析

點目標高度向成像結果	峰值旁瓣比(dB)	高度向分辨率
均勻陣列成像	–24.27	7.76
稀疏陣列RMA成像	–16.82	7.76
稀疏陣列改進3維時域成像	–20.32	7.76

下載: 導出CSV
