基于紅外注意力提升機制的熱成像測溫區域?qū)嵗指?/h2>
doi: 10.11999/JEIT200862
cstr: 32379.14.JEIT200862
-
1.
成都理工大學信息科學與技術學院(網絡安全學院、牛津布魯克斯學院) 成都 610059
-
2.
工業物聯網與網絡化控制教育部重點實驗室 重慶 400065
-
3.
太赫茲科學技術四川省重點實驗室 成都 610054
基金項目: 國家自然科學基金(61771096)，工業物聯網與網絡化控制教育部重點實驗室開放基金(2020FF06)，太赫茲科學技術四川省重點實驗室開放基金(THZSC202001)
詳細信息
成都理工大學信息科學與技術學院(網絡安全學院、牛津布魯克斯學院) 成都 610059
工業物聯網與網絡化控制教育部重點實驗室 重慶 400065
太赫茲科學技術四川省重點實驗室 成都 610054
基金項目: 國家自然科學基金(61771096)，工業物聯網與網絡化控制教育部重點實驗室開放基金(2020FF06)，太赫茲科學技術四川省重點實驗室開放基金(THZSC202001)
Instance Segmentation of Thermal Imaging Temperature Measurement Region Based on Infrared Attention Enhancement Mechanism
-
1.
College of Information Science and Technology(College of Cyber Security, College of Oxford Brookes), Chengdu University of Technology, Chengdu 610059, China
-
2.
Key Laboratory of Industrial Internet of Things & Networked Control, Ministry of Education, Chongqing 400065, China
-
3.
Terahertz Science and Technology Key Laboratory of Sichuan Province, Chengdu 610054, China
Funds: The National Natural Science Foundation of China (61771096), The Key Laboratory of Industrial Internet of Things & Networked Control Foundation, Ministry of Education (2020FF06), The Terahertz Science and Technology Key Laboratory Foundation of Sichuan Province (THZSC202001)
-
摘要: AI+熱成像人體溫度監測系統被廣泛用于人群密集的人體實時溫度測量。此類系統檢測人的頭部區域進行溫度測量，由于各類遮擋，溫度測量區域可能太小而無法正確測量。為了解決這個問題，該文提出一種融合紅外注意力提升機制的無錨點實例分割網絡，用于實時紅外熱成像溫度測量區域?qū)嵗指?。該文所提出的?shí)例分割網絡在檢測階段和分割階段融合紅外空間注意力模塊(ISAM)，旨在準確分割紅外圖像中的頭部裸露區域，以進行準確實時的溫度測量。結合公共熱成像面部數據集和采集的紅外熱成像數據集，制作了“熱成像溫度測量區域分割數據集”用于網絡訓練。實驗結果表明：該方法對紅外熱成像圖像中頭部裸露測溫區域的平均檢測精度達到88.6%，平均分割精度達到86.5%，平均處理速度達到33.5 fps，在評價指標上優于大多數先進的實例分割方法。Abstract: AI+thermal imaging human body temperature monitoring system is widely used for real-time temperature measurement of human body in dense crowds. The artificial intelligence method used in such systems detects the human head region for temperature measurement. The temperature measurement area may be too small to measure correctly due to occlusion. To tackle this problem, an anchor-free instance segmentation network incorporating infrared attention enhancement mechanism is proposed for real-time infrared thermal imaging temperature measurement area segmentation. The instance segmentation network proposed in this paper integrates the Infrared Spatial Attention Module (ISAM) in the detection stage and the segmentation stage, aiming to accurately segment the bare head area in the infrared image. Combined with the public thermal imaging facial dataset and the collected infrared thermal imaging dataset, the "thermal imaging temperature measurement area segmentation dataset" is produced. Experimental results demonstrate that this method reached an average detection precision of 88.6%, average mask precision of 86.5%, average processing speed of 33.5 fps. This network is superior to most state of the art instance segmentation methods in objective evaluation metrics.
-
表 2 數據集中標簽對應的標注色
分割類別 溫度測量區域 頭發 帽子 眼鏡 口罩 R 0 139 0 255 255 G 100 0 255 105 255 B 0 139 127 180 210
下載: 導出CSV
表 3 ISAM模塊目標檢測階段有效性驗證實驗結果
結構 AP(%) AMP(%) fps 無注意力提升機制 83.7 80.0 38.0 融合CBAM模塊 85.6 81.5 33.5 融合BAM模塊 84.8 81.0 34.5 融合ISAM模塊 88.6 84.5 35.5
下載: 導出CSV
表 4 ISAM模塊目標分割階段有效性實驗結果
結構 AP(%) AMP(%) fps 無注意力提升機制 88.6 84.5 35.5 融合CBAM模塊 88.6 84.3 31.2 融合BAM模塊 88.6 84.1 32.5 融合ISAM模塊 88.6 86.5 33.5
下載: 導出CSV
表 5 熱成像測溫區域?qū)嵗指罘椒▽?duì)比實驗結果
實例分割方法 AP(%) AMP(%) fps Mask R-CNN 83.8 80.3 11.5 YOLACT 75.6 70.1 38.0 CenterMask 82.8 78.1 33.0 PolarMask 83.6 79.0 30.5 本文方法 88.6 86.5 33.5
下載: 導出CSV
-
[1] USAMENTIAGA R, VENEGAS P, GUEREDIAGA J, et al. Infrared thermography for temperature measurement and non-destructive testing[J]. Sensors, 2014, 14(7): 12305–12348. doi: 10.3390/s140712305 [2] KAMMERSGAARD T S, MALMKVIST J, and PEDERSEN L J. Infrared thermography–a non-invasive tool to evaluate thermal status of neonatal pigs based on surface temperature[J]. Animal, 2013, 7(12): 2026–2034. doi: 10.1017/S1751731113001778 [3] ARORA N, MARTINS D, RUGGERIO D, et al. Effectiveness of a noninvasive digital infrared thermal imaging system in the detection of breast cancer[J]. The American Journal of Surgery, 2008, 196(4): 523–526. doi: 10.1016/j.amjsurg.2008.06.015 [4] KONTOS M, WILSON R, and FENTIMAN I. Digital Infrared Thermal Imaging (DITI) of breast lesions: Sensitivity and specificity of detection of primary breast cancers[J]. Clinical Radiology, 2011, 66(6): 536–539. doi: 10.1016/j.crad.2011.01.009 [5] CLARK R P and STOTHERS J K. Neonatal skin temperature distribution using infra-red colour thermography[J]. The Journal of Physiology, 1980, 302: 323–333. doi: 10.1113/jphysiol.1980.sp013245 [6] RASOR J S, ZLOTTA A R, EDWARDS S D, et al. TransUrethral Needle Ablation (TUNA): Thermal gradient mapping and comparison of lesion size in a tissue model and in patients with benign prostatic hyperplasia[J]. European Urology, 1993, 24(3): 411–414. doi: 10.1159/000474339 [7] BAGAVATHIAPPAN S, SARAVANAN T, PHILIP J, et al. Investigation of peripheral vascular disorders using thermal imaging[J]. The British Journal of Diabetes & Vascular Disease, 2008, 8(2): 102–104. [8] BAGAVATHIAPPAN S, SARAVANAN T, PHILIP J, et al. Infrared thermal imaging for detection of peripheral vascular disorders[J]. Journal of Medical Physics, 2009, 34(1): 43–47. doi: 10.4103/0971-6203.48720 [9] HE Kaiming, GKIOXARI G, DOLLáR P, et al. Mask R-CNN[C]. IEEE International Conference on Computer Vision, Shenzhen, China, 2017: 2961–2969. doi: 10.1109/TPAMI.2018.2844175. [10] BOLYA D, ZHOU Chong, XIAO Fanyi, et al. YOLACT++: Better real-time instance segmentation[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, To be published. doi: 10.1109/TPAMI.2020.3014297 [11] LEE Y and PARK J. CenterMask: Real-time anchor-free instance segmentation[C]. 2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Seattle, USA, 2020: 13903–13912. [12] XIE Enze, SUN Peize, SONG Xiaoge, et al. PolarMask: Single shot instance segmentation with polar representation[C]. 2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Seattle, USA, 2020: 12190–12199. [13] BENINI S, KHAN K, LEONARDI R, et al. Face analysis through semantic face segmentation[J]. Signal Processing: Image Communication, 2019, 74: 21–31. doi: 10.1016/j.image.2019.01.005 [14] GHIASS R S, ARANDJELOVI? O, BENDADA A, et al. Infrared face recognition: A comprehensive review of methodologies and databases[J]. Pattern Recognition, 2014, 47(9): 2807–2824. doi: 10.1016/j.patcog.2014.03.015 [15] YANG Changcai, ZHOU Huabing, SUN Sheng, et al. Good match exploration for infrared face recognition[J]. Infrared Physics & Technology, 2014, 67: 111–115. [16] BUDZAN S and WY?GOLIK R. Face and eyes localization algorithm in thermal images for temperature measurement of the inner canthus of the eyes[J]. Infrared Physics & Technology, 2013, 60: 225–234. [17] HE Kaiming, ZHANG Xiangyu, REN Shaoqing, et al. Deep residual learning for image recognition[C]. 2016 IEEE Conference on Computer Vision and Pattern Recognition, Las Vegas, USA, 2016: 770–778. [18] ZHOU Xingyi, WANG Dequan, and KR?HENBüHL P. Objects as points[C]. IEEE Conference on Computer Vision and Pattern Recognition, Los Angeles, 2019: 2678–2689. [19] WOO S, PARK J, LEE J Y, et al. CBAM: Convolutional block attention module[C]. 15th European Conference on Computer Vision, Munich, Germany, 2018: 3–19. [20] PARK J, WOO S, LEE J Y, et al. BAM: Bottleneck attention module[C]. European Conference on Computer Vision, Munich, Germany, 2018: 68–86. -
