基于能量誤差的人體有限元模型網格剖分優化研究

魏宏安,  吳小清,  張昂

魏宏安, 吳小清, 張昂. 基于能量誤差的人體有限元模型網格剖分優化研究[J]. 電子與信息學報, 2020, 42(11): 2615-2620. doi: 10.11999/JEIT190765
引用本文: 魏宏安, 吳小清, 張昂. 基于能量誤差的人體有限元模型網格剖分優化研究[J]. 電子與信息學報, 2020, 42(11): 2615-2620. doi: 10.11999/JEIT190765
Hong’an WEI, Xiaoqing WU, Ang ZHANG. Research on Mesh Generation Optimization of Finite Element Model of Human Body Based on Energy Error[J]. Journal of Electronics & Information Technology, 2020, 42(11): 2615-2620. doi: 10.11999/JEIT190765
Citation: Hong’an WEI, Xiaoqing WU, Ang ZHANG. Research on Mesh Generation Optimization of Finite Element Model of Human Body Based on Energy Error[J]. Journal of Electronics & Information Technology, 2020, 42(11): 2615-2620. doi: 10.11999/JEIT190765

基于能量誤差的人體有限元模型網格剖分優化研究

doi: 10.11999/JEIT190765 cstr: 32379.14.JEIT190765
  • 1.

    福州大學物理與信息工程學院　福州　350116

  • 2.

    福建省媒體信息智能處理與無線傳輸重點實驗室　福州　350116

詳細信息
    作者簡介:

    魏宏安：男，1978年生，高級實驗師，研究方向為通信與信息系統

    吳小清：女，1994年生，碩士生，研究方向為電子與通信工程

    張昂：男，1984年生，實驗師，研究方向為電子與通信工程

    通訊作者:

    張昂　2774977803@qq.com

  • 中圖分類號: TM154

Research on Mesh Generation Optimization of Finite Element Model of Human Body Based on Energy Error

  • 1.

    College of Physics and Information Engineering, Fuzhou University, Fuzhou 350116, China

  • 2.

    Key Laboratory of Media Intelligence and Communication, Fujian Province, Fuzhou 350116, China

  • 摘要: 網格剖分是有限元建模分析過程中最重要，也是工作量最大的環節，直接影響有限元分析的精度和時間。該文在研究網格自適應剖分及有限元離散誤差的基礎上，在高壓輸電場環境中建立不同復雜度的3維人體模型。通過對人體模型自適應網格剖分和手動網格剖分電場仿真結果的對比，分析能量誤差變化的趨勢，從而指導人體模型的建立及最佳剖分尺寸的設置。該文的研究成果，對其它有限元剖分方案的優化研究具有一定參考意義。
    Abstract: Meshing is the most important part of the finite element modeling and analysis process, and it also has the largest workload, which directly affects the accuracy and time of the finite element analysis. Based on the research of adaptive meshing and finite element discrete errors, three-dimensional human body models of different complexity are established in the environment of high-voltage power transmission fields. By comparing the results of the electric field simulation between the adaptive meshing of the human body model and the manual meshing, the trend of energy error changes is analyzed, so as to guide the establishment of the human body model and the setting of the optimal mesh size.The research results have certain reference significance to the optimization research of other finite element splitting schemes.
    • HTML全文

  • 圖  1  自適應網絡剖分流程

    圖  2  三相輸電線路布局圖

    圖  3  無人情況下空間中電位仿真結果分布圖

    圖  4  簡化3D人體模型

    圖  5  有人情況下空間電場強度仿真結果分布圖

    圖  6  不同人體模型的能量誤差的變化

    圖  7  3種人體模型的不同網格單元大小的能量誤差的變化

    表  1  人體模型尺寸

    人體模型I人體模型II人體模型III
    腳身體脖子頭腳身體手臂脖子頭
    半徑0.280.190.240.100.170.050.120.030.040.20
    高度1.710.700.650.08無0.800.700.750.08無
    下載: 導出CSV

    表  2  不同人體模型的方差和自適應網格剖分能量誤差

    人體模型類型人體模型I人體模型II人體模型III
    能量誤差(%)21.073522.424426.8348
    方差(m2)00.0360.050
    下載: 導出CSV

    表  3  網格尺寸0.2 m和0.5 m的模型網格數變化

    人體模型I人體模型II人體模型III
    全局網格數網格尺寸0.2 m281086282154285858
    網格尺寸0.5 m277204280179283806
    網格數差全局網格數差388219752052
    人體網格數網格尺寸0.2 m264627694987
    網格尺寸0.5 m56615793615
    網格數差人體網格數差208011901372
    下載: 導出CSV
  • 沈丹丹, 胡萬曉, 茍進勝. 木托盤有限元分析精度的影響因素[J]. 包裝工程, 2018, 39(17): 12–18. doi: 10.19554/j.cnki.1001-3563.2018.17.003

    SHEN Dandan, HU Wanxiao, and GOU Jinsheng. Factors affecting the precision of finite element analysis of wooden pallet[J]. Packaging Engineering, 2018, 39(17): 12–18. doi: 10.19554/j.cnki.1001-3563.2018.17.003
    葉志紅, 周海京, 劉強. 屏蔽腔內任意高度線纜端接TVS管電路的電磁耦合時域分析[J]. 電子與信息學報, 2018, 40(4): 1007–1011. doi: 10.11999/JEIT170615

    YE Zhihong, ZHOU Haijing, and LIU Qiang. Time domain coupling analysis for the arbitrary height cable terminated with TVS circuit in shield cavity[J]. Journal of Electronics &Information Technology, 2018, 40(4): 1007–1011. doi: 10.11999/JEIT170615
    JIN Gefei, WEI Hai, CHEN Danlei, et al. Finite element meshing of complex tailings dam based on Hypermesh software[J]. China Water Transport (The Second Half) , 2019, 19(8): 96–97.
    王世杰, 常延貞. 一類拋物最優控制問題的有限元誤差估計[J]. 北京化工大學學報: 自然科學版, 2018, 45(6): 106–110. doi: 10.13543/j.bhxbzr.2018.06.017

    WANG Shijie and CHANG Yanzhen. Error estimates of the finite element method for a class of parabolic optimal control problems[J]. Journal of Beijing University of Chemical Technology:Natural Science Edition, 2018, 45(6): 106–110. doi: 10.13543/j.bhxbzr.2018.06.017
    TURCKE D J and MCNEICE G M. Guidelines for selecting finite element grids based on an optimization study[J]. Computers & Structures, 1974, 4(3): 499–519.
    BABU?KA I and RHEINBOLDT W C. A-Posteriori error estimates for the finite element method[J]. International Journal for Numerical Methods in Engineering, 1978, 12(10): 1597–1615. doi: 10.1002/nme.1620121010
    ZIENKIEWICZ O C and ZHU J Z. The superconvergent patch recovery and a posteriori error estimates. Part 1: The recovery technique[J]. International Journal for Numerical Methods in Engineering, 1992, 33(7): 1331–1364. doi: 10.1002/nme.1620330702
    AINSWORTH M, ZHU J Z, CRAIG A W, et al. Analysis of the Zienkiewicz-Zhu a-posteriori error estimator in the finite element method[J]. International Journal for Numerical Methods in Engineering, 1989, 28(9): 2161–2174. doi: 10.1002/nme.1620280912
    FENG Kang. Finite element method[J]. Mathematics in Practice and Theory, 1974(4): 54–61.
    LI Xiangrong, ZHANG Weiwei, and NIE Yufeng. Superconvergence analysis of adaptive finite element method based on the bubble-type mesh generation[J]. Applied Mathematics Letters, 2019, 98: 322–328. doi: 10.1016/j.aml.2019.06.034
    朱月風, 張洪亮, 張乘源, 等. 簡化擴展有限元法精度的驗證及在DCT試驗中的應用[J]. 武漢大學學報: 工學版, 2019, 52(3): 216–222. doi: 10.14188/j.1671-8844.2019-03-005

    ZHU Yuefeng, ZHANG Hongliang, ZHANG Chengyuan, et al. Accuracy verification of simplified XFEM and its application to DCT test[J]. Engineering Journal of Wuhan University, 2019, 52(3): 216–222. doi: 10.14188/j.1671-8844.2019-03-005
    蘇志敏, 閆毅志, 董衛, 等. 特高拱壩有限元網格尺寸與離散誤差分析[C]. 第九屆南方計算力學學術交流會, 合肥, 2013: 246–250. doi: 10.19636/j.cnki.cjsm42-1250/o3.2014.s1.042.

    SU Zhimin, YAN Yizhi, DONG Wei, et al. Analysis on finite element mesh size and discretization error for super-high arch dam[C]. The 9th South Computational Mechanics Academic Exchange Conference, Hefei, China, 2013: 246–250. doi: 10.19636/j.cnki.cjsm42-1250/o3.2014.s1.042.
    劉建濤, 杜平安, 黃明鏡, 等. 曲面薄殼有限元離散誤差分析和修正方法研究[J]. 系統仿真學報, 2010, 22(10): 2281–2286. doi: 10.16182/j.cnki.joss.2010.10.006

    LIU Jiantao, DU Ping’an, HUANG Mingjing, et al. Discrete error analysis and correction method of finite element for curved thin-walled structures[J]. Journal of System Simulation, 2010, 22(10): 2281–2286. doi: 10.16182/j.cnki.joss.2010.10.006
    宣楊, 王旭, 劉承安, 等. 不完全喬列斯基分解共軛梯度法在磁感應成像三維有限元正問題中的應用[J]. 電子與信息學報, 2016, 38(1): 187–194. doi: 10.11999/JEIT150437

    XUAN Yang, WANG Xu, LIU Cheng’an, et al. Incomplete Cholesky conjugate gradient method for the three-dimensional forward problem in magnetic induction tomography using finite element method[J]. Journal of Electronics &Information Technology, 2016, 38(1): 187–194. doi: 10.11999/JEIT150437
    魏宏安, 吳小清. 基于Maxwell有限元分析的高壓輸電線路安全距離研究[J]. 電氣開關, 2018, 56(5): 86–90. doi: 10.3969/j.issn.1004-289X.2018.05.020

    WEI Hong’an and WU Xiaoqing. Research on safety distance of high voltage transmission lines based on Maxwell’s finite element analysis[J]. Electric Switcher, 2018, 56(5): 86–90. doi: 10.3969/j.issn.1004-289X.2018.05.020
