一種提升汽車?yán)走_(dá)方位角分辨率的成像處理方法

王同軍,  吳鋒,  徐偉

王同軍, 吳鋒, 徐偉. 一種提升汽車?yán)走_(dá)方位角分辨率的成像處理方法[J]. 電子與信息學報, 2020, 42(8): 2037-2044. doi: 10.11999/JEIT190618
引用本文: 王同軍, 吳鋒, 徐偉. 一種提升汽車?yán)走_(dá)方位角分辨率的成像處理方法[J]. 電子與信息學報, 2020, 42(8): 2037-2044. doi: 10.11999/JEIT190618
Tongjun WANG, Feng WU, Wei XU. A Novel Imaging Approach for Improving Azimuth Angular Resolution of Automotive Radars[J]. Journal of Electronics & Information Technology, 2020, 42(8): 2037-2044. doi: 10.11999/JEIT190618
Citation: Tongjun WANG, Feng WU, Wei XU. A Novel Imaging Approach for Improving Azimuth Angular Resolution of Automotive Radars[J]. Journal of Electronics & Information Technology, 2020, 42(8): 2037-2044. doi: 10.11999/JEIT190618

一種提升汽車?yán)走_(dá)方位角分辨率的成像處理方法

doi: 10.11999/JEIT190618 cstr: 32379.14.JEIT190618
  • 1.

    信陽農林學院信息工程學院 信陽 464000

  • 2.

    內蒙古工業大學信息工程學院 呼和浩特 010051

基金項目: 河南省科技攻關項目(172102210450, 182102210533, 182102110160)，河南省高等學校重點科研項目(18B520035)
詳細信息
    作者簡介:

    王同軍：男，1985年生，講師，研究方向?yàn)榻煌ōh(huán)境智能感知、高速信息處理、物聯網應用

    吳鋒：男，1981年生，講師，研究方向?yàn)樾盘?hào)處理、無線數據通信、物聯網技術

    徐偉：男，1983年生，教授，研究方向?yàn)樾麦w制雷達系統、微波遙感應用

    通訊作者:

    王同軍　xy_wangtj@126.com

  • 中圖分類號: TN951

A Novel Imaging Approach for Improving Azimuth Angular Resolution of Automotive Radars

  • 1.

    College of Information Engineering, Xinyang Agriculture and Forestry University, Xinyang 464000, China

  • 2.

    College of Information Engineering, Inner Mongolia University of Technology, Hohhot 010051, China

Funds: The Scientific and Technological Project in Henan Province (172102210450, 182102210533, 182102110160), The Key Scientific Research Projects in Institutions of Henan Higher Learning (18B520035)
  • 摘要:

    針對汽車?yán)走_(dá)方位角分辨率受方位向天線長度限制的問題，該文提出一種基于多波束實孔徑雷達圖像融合來提升汽車?yán)走_(dá)方位角分辨率的成像方法。該方法首先利用相控陣天線波束電掃描來獲取前視實孔徑雷達圖像，然后根據汽車?yán)走_(dá)成像幾何關系通過多張多角度實孔徑雷達圖像相參累加來提升雷達方位角分辨率。計算機仿真結果驗證了該方法在提升汽車?yán)走_(dá)方位角分辨率的有效性。

    Abstract:

    As the azimuth angular resolution is limited by the antenna length in automotive radars, a novel imaging approach for improving azimuth angular resolution of automotive radars is proposed based on multi-beam real-aperture radar images combination processing. Firstly, the antenna beam of the phased array antenna is electronically scanned to obtain forward-looking real-aperture radar images. Afterwards, multiple real-aperture radar images are coherent accumulated according to the imaging geometry of automotive radar to improve azimuth angular resolution. Simulation results validate the proposed imaging approach to improve the azimuth angular resolution of automotive radar.

    • HTML全文

  • 圖  1  提升方位分辨率的前視成像雷達工作方式示意圖

    圖  2  提升方位分辨率的前視成像雷達工作方式示意圖

    圖  3  成像處理流程圖

    圖  4  成像區域打網格處理示意圖

    圖  5  方位角分辨率仿真結果

    圖  6  點陣目標場景設置

    圖  7  點陣目標場景設置

    圖  8  前視成像雷達實孔徑點目標插值處理后的等高線(10 m合成孔徑)

    圖  9  前視成像雷達高分辨合成孔徑點目標插值處理后的等高線(15 m合成孔徑)

    圖  10  前視成像雷達高分辨合成孔徑點目標插值處理后的等高線(5 m合成孔徑)

    表  1  車載前視成像雷達仿真參數

    參數數值
    雷達載頻96 GHz
    方位向天線長度0.3 m
    系統PRF4000 Hz
    脈沖寬度80 μs
    信號帶寬1 GHz
    去斜接收后雷達信號采樣率150 MHz
    AD量化位數12位
    方位波束掃描角度范圍±15°
    雷達作用距離20～300 m
    波束躍度0.3°
    合成孔徑長度10 m
    汽車速度15 m/s
    下載: 導出CSV

    表  2  點目標聚焦性能指標

    模式目標距離向方位向
    分辨率PSLR(dB)ISLR(dB)分辨率(°)PSLR(dB)ISLR(dB)
    實孔徑圖像P10.09–13.26–9.980.390–26.40–22.24
    P20.09–13.26–9.980.380–26.52–22.47
    P30.09–13.26–9.980.390–26.40–22.24
    實孔徑理論值P10.09–13.26–9.800.380–26.60–22.30
    P20.09–13.26–9.800.380–26.60–22.30
    P30.09–13.26–9.800.380–26.60–22.30
    合成處理圖像(10 m合成孔徑)P10.09–13.26–9.980.010–13.18–9.74
    P20.09–13.26–9.980.390–26.52–22.29
    P30.09–13.26–9.980.010–13.18–9.74
    合成處理理論值(10 m合成孔徑)P10.09–13.26–9.800.010–13.26–9.80
    P20.09–13.26–9.80 0.390–26.60–22.30
    P30.09–13.26–9.800.010–13.26–9.80
    合成處理圖像(15 m合成孔徑)P10.09–13.06–9.720.007–13.08–9.44
    P20.09–13.26–9.980.390–26.52–22.29
    P30.09–13.06–9.720.007–13.07–9.40
    合成處理理論值(15 m合成孔徑)P10.09–13.26–9.800.007–13.26–9.80
    P20.09–13.26–9.800.390–26.60–22.30
    P30.09–13.26–9.800.007–13.26–9.80
    下載: 導出CSV
  • XU Zhihuo, SHI Quan, SUN Ling, et al. Novel orthogonal random phase-coded pulsed radar for automotive application[J]. Journal of Radars, 2018, 7(3): 364–375. doi: 10.12000/JR17083
    PATOLE S M, TORLAK M, WANG Dan, et al. Automotive radars: A review of signal processing techniques[J]. IEEE Signal Processing Magazine, 2017, 34(2): 22–35. doi: 10.1109/MSP.2016.2628914
    KRONAUGE M and ROHLING H. New chirp sequence radar waveform[J]. IEEE Transactions on Aerospace and Electronic Systems, 2014, 50(4): 2870–2877. doi: 10.1109/TAES.2014.120813
    TAK J, JEONG E, and CHOI J. Metamaterial absorbers for 24-GHz automotive radar applications[J]. Journal of Electromagnetic Waves and Applications, 2017, 31(6): 577–593. doi: 10.1080/09205071.2017.1297257
    GUO Kunyi, HOARE E G, JASTEH D, et al. Road edge recognition using the stripe hough transform from millimeter-wave radar images[J]. IEEE Transactions on Intelligent Transportation Systems, 2015, 16(2): 825–833. doi: 10.1109/TITS.2014.2342875
    MAO Xuesong, INOUE D, MATSUBARA H, et al. Demonstration of in-car doppler laser radar at 1.55 μm for range and speed measurement[J]. IEEE Transactions on Intelligent Transportation Systems, 2013, 14(2): 599–607. doi: 10.1109/TITS.2012.2230325
    LEE J E, LIM H S, JEONG S H, et al. Enhanced iron-tunnel recognition for automotive radars[J]. IEEE Transactions on Vehicular Technology, 2016, 65(6): 4412–4418. doi: 10.1109/TVT.2015.2460992
    KELLNER D, BARJENBRUCH M, KLAPPSTEIN J, et al. Tracking of extended objects with high-resolution Doppler radar[J]. IEEE Transactions on Intelligent Transportation Systems, 2016, 17(5): 1341–1353. doi: 10.1109/TITS.2015.2501759
    WANG Xiao, XU Linhai, SUN Hongbin, et al. On-road vehicle detection and tracking using MMW radar and monovision fusion[J]. IEEE Transactions on Intelligent Transportation Systems, 2016, 17(7): 2075–2084. doi: 10.1109/TITS.2016.2533542
    WANG H N, HUANG Yingwei, and CHUN S J. Spatial diversity 24-GHz FMCW radar with ground effect compensation for automotive applications[J]. IEEE Transactions on Vehicular Technology, 2017, 66(2): 965–973. doi: 10.1109/TVT.2016.2565608
    ASKELAND S A and EKMAN T. Tracking with a high-resolution 2D spectral estimation based automotive radar[J]. IEEE Transactions on Intelligent Transportation Systems, 2015, 16(5): 2418–2423. doi: 10.1109/TITS.2015.2407571
    LEE M S and KIM Y H. Design and performance of a 24-GHz switch-antenna array FMCW radar system for automotive applications[J]. IEEE Transactions on Vehicular Technology, 2010, 59(5): 2290–2297. doi: 10.1109/TVT.2010.2045665
    HU Chenxi, LIU Yimin, MENG Huadong, et al. Randomized switched antenna array FMCW radar for automotive applications[J]. IEEE Transactions on Vehicular Technology, 2014, 63(8): 3624–3641. doi: 10.1109/TVT.2014.2308895
    保錚, 邢孟道, 王彤. 雷達成像技術[M]. 北京: 電子工業出版社, 2005: 169–170.

    BAO Zheng, XING Mengdao, and WANG Tong. Radar Imaging Technology[M]. Beijing: Publishing House of Electronics Industry, 2005: 169–170.
    DEVADITHYA S, PEDROSS-ENGEL A, WATTS C M, et al. GPU-accelerated enhanced resolution 3-D SAR imaging with dynamic metamaterial antennas[J]. IEEE Transactions on Microwave Theory and Techniques, 2017, 65(12): 5096–5103. doi: 10.1109/TMTT.2017.2766060
    CHANG W Y, WU Mengche, CHANG Yanglang, et al. GPU acceleration of adaptive local kriging applied to retrieving slant-range surface motion maps[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2018, 11(11): 4317–4325. doi: 10.1109/JSTARS.2018.2871877
    WIJAYASIRI A, BANERJEE T, RANKA S, et al. Dynamic data-driven SAR image reconstruction using multiple GPUs[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2018, 11(11): 4326–4338. doi: 10.1109/JSTARS.2018.2873198
