通信電臺電磁輻射2階互調低頻阻塞效應與作用機理

魏光輝; 趙凱; 任仕召

doi:10.11999/JEIT190574

通信電臺電磁輻射2階互調低頻阻塞效應與作用機理

doi: 10.11999/JEIT190574 cstr: 32379.14.JEIT190574

陸軍工程大學石家莊校區電磁環境效應國家級重點實驗室石家莊 050003

詳細信息

作者簡介:
魏光輝：男，1964年生，教授，主要研究方向?yàn)殪o電與電磁防護技術、電磁環境效應試驗評估技術

趙凱：男，1991年生，博士生，研究方向?yàn)殡姶怒h(huán)境效應試驗評估技術

任仕召：男，1988年生，碩士生，研究方向?yàn)殡姶怒h(huán)境效應試驗評估技術

通訊作者:
趙凱　 oeczhao@126.com

中圖分類號: TN924; TM937
計量
- 文章訪問數: 2203
- HTML全文瀏覽量: 1265
- PDF下載量: 45
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-30
- 修回日期: 2020-03-06
- 網絡出版日期: 2020-04-25
- 刊出日期: 2020-08-18

Second-order Intermodulation Low Frequency Blocking Effect and Mechanism for Communication Radio under Electromagnetic Radiation

National Key Laboratory on Electromagnetic Environment Effects, Army Engineering University, Shijiazhuang 050003, China

摘要

摘要:
為揭示通信電臺復雜電磁環境效應機理，該文采用全電平輻照法實驗研究了某型超短波數字通信電臺的單頻和帶外雙頻電磁輻射阻塞效應，確定了其單頻電磁輻射效應規律和敏感帶寬，實驗數據表明受試電臺對帶外雙頻3階互調阻塞較單頻電磁輻射阻塞干擾敏感9～23 dB。實驗過程中發現了一種既不能用雙頻非互調迭加機理解釋、也不能用3階交互調機理解釋的雙頻電磁輻射敏感現象。
- 通信電臺 /
- 電磁輻射 /
- 2階互調 /
- 阻塞效應 /
- 機理
Abstract:
In order to reveal the complex electromagnetic environment effects mechanism of communication radio, the blocking effect of single-frequency and out-of-band dual-frequency electromagnetic radiation for the ultra-short wave digital communication radio is experimentally studied by irradiation method. The rule of single-frequency electromagnetic radiation effect and the susceptible bandwidth are determined. The experimental data show that the tested radio is 9～23 dB more susceptible to out-of-band dual-frequency third-order intermodulation blocking than single-frequency electromagnetic radiation blocking. A sensitive phenomenon of dual-frequency electromagnetic radiation which can neither be explained by the dual-frequency non-intermodulation superposition mechanism nor by the third-order intermodulation mechanism has been found in the experiment.
- Communication radio /
- Electromagnetic radiation /
- Second-order intermodulation /
- Blocking effect /
- Mechanism

HTML全文

圖 1 通信電臺單頻電磁輻射效應試驗配置

下載: 全尺寸圖片幻燈片

圖 2 受試通信電臺單頻阻塞臨界干擾場強

下載: 全尺寸圖片幻燈片

圖 3 通信電臺雙頻電磁輻射效應試驗配置

下載: 全尺寸圖片幻燈片

圖 4 通信電臺原理結構框圖

下載: 全尺寸圖片幻燈片

圖 5 受試通信電臺低頻干擾電平隨互調頻差的變化

下載: 全尺寸圖片幻燈片

圖 6 受試通信電臺2階互調低頻阻塞干擾因子隨輻射頻偏的變化

下載: 全尺寸圖片幻燈片

表 1 通信電臺雙頻3階互調阻塞臨界干擾場強

頻率組合(kHz)	Δf₁=f₁–f₀	36	48	72	96	144
頻率組合(kHz)	Δf₂=f₂–f₀	72	96	144	192	288
臨界干擾場強比	E₁/E₁₀	–11.7	–12.3	–13.3	–17.9	–18.2
臨界干擾場強比	E₂/E₂₀	–13.2	–22.5	–24.8	–32.3	–27.1
頻率組合(kHz)	Δf₁=f₁–f₀	36	48	72	96	144
頻率組合(kHz)	Δf₂=f₂–f₀	48	86	154	212	268
臨界干擾場強比	E₁/E₁₀	–8.7	–13.3	–13.6	–19.5	–19.8
臨界干擾場強比	E₂/E₂₀	–10.8	–17.0	–24.1	–19.9	–22.9

下載: 導出CSV

表 2 通信電臺新型雙頻阻塞臨界干擾場強

頻率組合(kHz)	Δf₁=f₁–f₀	100	150	200	250	300
頻率組合(kHz)	Δf₂=f₂–f₀	150	200	250	300	350
臨界干擾場強比	E₁/E₁₀	–25.6	–26.3	–28.7	–28.4	–30.6
臨界干擾場強比	E₂/E₂₀	–26.7	–29.5	–29.2	–30.5	–28.5
頻率組合(kHz)	Δf₁=f₁–f₀	127	150	220	240	230
頻率組合(kHz)	Δf₂=f₂–f₀	177	160	330	360	390
臨界干擾場強比	E₁/E₁₀	–26.5	–17.5	–30.6	–34.4	–4.0
臨界干擾場強比	E₂/E₂₀	–27.7	–17.7	–30.5	–34.4	–4.1

下載: 導出CSV

表 3 干擾信號進入通信電臺各結構后輸出分量頻率

結構	頻率
天線接收	f₁, f₂(設f₁<f₂)
一級放大	f₁, f₂, f₂±f₁, 2f₁±f₂和2f₂±f₁, 3f₁和3f₂(忽略高階互調分量)
上變頻	F_m+f₀–f₁, F_m+f₀–f₂, F_m+f₀–f₂±f₁, F_m+f₀–2f₁±f₂, F_m+f₀–2f₂±f₁, F_m+f₀–3f₁, F_m+f₀–3f₂和 F_m+f₀+f₁, F_m+f₀+f₂, F_m+f₀+f₂±f₁, F_m+f₀+2f₁±f₂, F_m+f₀+2f₂±f₁, F_m+f₀+3f₁, F_m+f₀+3f₂
窄帶濾波	F_m+f₀–f₁, F_m+f₀–f₂, F_m+f₀–2f₁+f₂和F_m+f₀–2f₂+f₁
三級放大	F_m+f₀–f₁, F_m+f₀–f₂, F_m+f₀–2f₁+f₂, F_m+f₀–2f₂+f₁和f₂–f₁, 2(f₂–f₁), 3(f₂-f₁), 2(F_m+f₀)–f₁–f₂, 2(F_m+f₀–f₁), 2(F_m+f₀–f₂), 2(F_m+f₀)–3f_1–f₂, 2(F_m+f₀)–3f₂–f₁(忽略3階互調)
下變頻與低通(帶通)濾波	F_L+f₀–f₁, F_L+f₀–f₂, F_L+f₀–2f₁+f₂, F_L+f₀–2f₂+f₁, F_L+(f₂–f₁), F_L+2(f₂–f₁), F_L+3(f₂–f₁)

下載: 導出CSV

表 4 2階互調低頻阻塞干擾效應評估準確度

電臺工作頻率(MHz)		50	60	70	50	60	70
頻率組合(kHz)	f₁–f₀	200	200	200	200	200	230
頻率組合(kHz)	f₂–f₀	250	250	250	300	300	330
臨界干擾場強比	E₁/E₁₀	–25.0	–28.9	–29.1	–26.3	–30.2	–29.1
臨界干擾場強比	E₂/E₂₀	–23.7	–30.9	–22.0	–28.7	–30.1	–28.9
評估準確度R₂		4.4	–6.7	2.0	–4.1	–9.4	–7.6

下載: 導出CSV
