復雜天氣及海風對天基被動干涉微波輻射無源探測系統性能的影響

宋廣南; 盧海梁; 李浩; 李一楠; 郎量; 董思喬; 李鵬飛; 呂容川

doi:10.11999/JEIT190534

復雜天氣及海風對天基被動干涉微波輻射無源探測系統性能的影響

doi: 10.11999/JEIT190534 cstr: 32379.14.JEIT190534

1.
中國空間技術研究院西安分院西安 710100
2.
華中科技大學電子信息與通信學院武漢 430074
3.
國家無線電監測中心北京 100037

詳細信息

作者簡介:
宋廣南：男，1988年生，工程師，研究方向?yàn)楸粍?dòng)微波遙感、綜合孔徑微波輻射計系統設計等

盧海梁：男，1986年生，高級工程師，研究方向?yàn)楸粍?dòng)微波輻射無源探測、被動微波遙感、射頻干擾檢測等

李浩：男，1980年生，研究員，研究方向?yàn)槿珮O化微波輻射計、綜合孔徑微波輻射計系統設計等

李一楠：男，1985年生，高級工程師，研究方向?yàn)楸粍?dòng)微波遙感、綜合孔徑微波輻射計系統設計等

郎量：男，1976年生，副教授，研究方向?yàn)槲⒉ㄟb感理論與微波遙感器等

董思喬：男，1984年生，工程師，研究方向?yàn)闊o(wú)線電管理與檢測等

李鵬飛：男，1989年生，工程師，研究方向?yàn)楸粍?dòng)微波遙感、綜合孔徑微波輻射計系統設計等

呂容川：女，1982年生，研究員，研究方向?yàn)槿珮O化微波輻射計、被動微波遙感、大氣探測等

通訊作者:
盧海梁　396689lhl@163.com

中圖分類號: TN24; TP79
計量
- 文章訪問數: 1737
- HTML全文瀏覽量: 716
- PDF下載量: 60
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-16
- 修回日期: 2020-06-08
- 網絡出版日期: 2020-07-11
- 刊出日期: 2020-11-16

The Effects of Complex Weather and Sea Wind on the Performance of Space-borne Passive Interferometric Microwave Detection System

1.
China Academy of Space Technology (Xi’an), Xi’an 710100, China
2.
School of Electronic Information and Communications, Huazhong University of Science and Technology, Wuhan 430074, China
3.
State Radio Monitoring Center, Beijing 100037, China

摘要

摘要: 基于微波輻射無源探測系統的目標探測方程，該文探討了云、霧和雨等復雜天氣以及海風對天基被動干涉微波輻射無源探測系統的影響，定量化仿真分析了這些因素對系統探測能力的影響，實驗驗證了被動干涉微波輻射無源探測系統對云層的穿透能力。研究結果表明：云、霧和雨等復雜天氣對被動干涉微波輻射無源探測系統對海面目標的探測有一定的影響，但在低頻段云霧影響較小，可忽略不計；而降雨會對系統的目標探測能力影響較大；海風對海面金屬目標的探測是有利的，而海風對隱身目標探測是不利的，會降低系統的探測能力。
- 無源探測 /
- 復雜天氣 /
- 海風
Abstract: Based on the target detection equation of the passive interferometric microwave system, the effects of complex weather on the detection ability of the passive interferometric microwave system are discussed for the sea surface target, such as clouds, fog and rain, and sea winds. Quantitative simulations are also performed to assess the effects of these previous mentioned factors. The experiments are also performed to demonstrate the passive interferometric microwave system penetrating the clouds. Both theoretical and simulation results show that complex weather has a negative impact on the passive interferometric microwave systems in the sea target detection, such as clouds, fog and rain. However, the impacts can be neglected in low frequency, since the impacts of clouds in low frequency is very small. On the other hand, rainfall will seriously degrade the system’s target detection capability. Sea winds have a positive impact in the metallic target detection. However, sea winds have a negative impact and reduce the system’s detection capability for the stealthy target detection.
- Passive detection /
- Complex weather /
- Sea wind

HTML全文

圖 1 綜合孔徑微波輻射測量原理示意圖

下載: 全尺寸圖片幻燈片

圖 2 不同水汽含量的星下點目標探測距離與探測概率的關系曲線

下載: 全尺寸圖片幻燈片

圖 3 星下點目標探測距離與探測概率的關系曲線

下載: 全尺寸圖片幻燈片

圖 4 不同液水含量的星下點目標探測距離與探測概率的關系曲線

下載: 全尺寸圖片幻燈片

圖 5 星下點目標探測距離與探測概率的關系曲線

下載: 全尺寸圖片幻燈片

圖 6 不同風速的金屬目標星下點探測距離與探測概率的關系曲線

下載: 全尺寸圖片幻燈片

圖 7 不同風速的隱身目標星下點探測距離與探測概率的關系曲線

下載: 全尺寸圖片幻燈片

圖 8 濃云條件下海面目標探測

下載: 全尺寸圖片幻燈片

表 1 溫度10°、星下點，霧高100 m的衰減(dB)

霧型	能見度	霧含水量$({\rm{g}}/{{\rm{m}}}^{3})$	94 GHz	37 GHz	23.8 GHz	18.7 GHz	10.7 GHz
平流霧	重霧0.05	11.3135	4.8569	1.0016	0.4305	0.2686	0.0890
	濃霧0.20	1.5583	0.6690	0.1380	0.0593	0.0370	0.0123
	中霧0.50	0.4203	0.1805	0.0372	0.0160	0.0100	0.0033
	輕霧1.00	0.1560	0.0670	0.0138	0.0059	0.0037	0.0012

下載: 導出CSV

表 2 溫度10°、星下點、不同云型的衰減(dB)

云型	云底層	云底層	含水量$({\rm{g}}/{{\rm{m}}}^{3})$	94 GHz	37 GHz	23.8 GHz	18.7 GHz	10.7 GHz
晴空積云	0.5	1	0.50	1.0732	0.2213	0.0951	0.0594	0.0197
卷積云	5.0	7	0.10	0.8586	0.1771	0.0761	0.0475	0.0157
低層云	0.5	1	0.25	0.5366	0.1107	0.0476	0.0297	0.0098
濃積云	1.6	2	0.80	1.3738	0.2833	0.1238	0.0760	0.0252

下載: 導出CSV

表 3 溫度10°、星下點、不同雨型衰減(dB)

雨型	降雨率(mm/h)	94 GHz	37 GHz	23.8 GHz	18.7 GHz	10.7 GHz
微雨	0.25	12.9574	1.5068	0.4642	0.2235	0.0281
小雨	1.00	36.7631	5.1375	1.8805	1.0317	0.1604
中雨	4.00	96.5170	17.5168	7.6177	4.6378	0.9154
大雨	16.00	219.3243	59.7251	30.8595	20.5155	5.2244

下載: 導出CSV

表 4 X波段綜合孔徑微波輻射計系統相關參量

指標	參量
中心頻率	10.65 GHz
帶寬	100 MHz
積分時間	100 ms
天線類型	Y型
天線個數	19
單元間距	0.95倍波長

下載: 導出CSV

參考文獻(15)

HUANG Jian and GAN Tiguo. A novel millimeter wave synthetic aperture radiometer passive imaging system[C]. The 4th International Conference on, Proceedings Microwave and Millimeter Wave Technology, Beijing, China, 2004: 414–417. doi: 10.1109/ICMMT.2004.1411554.

LI Qingxia, CHEN Ke, GUO Wei, et al. An aperture synthesis radiometer at millimeter wave band[C]. 2008 International Conference on Microwave and Millimeter Wave Technology, Nanjing, China, 2008: 1699–1701. doi: 10.1109/ICMMT.2008.4540797.

倪煒, 胡飛, 陳柯. 綜合孔徑輻射計空中隱身目標探測性能分析[J]. 微波學報, 2012, 28(2): 28–31, 41. doi: 10.14183/j.cnki.1005-6122.2012.02.015

NI Wei, HU Fei, and CHEN Ke. Performance analysis of synthetic aperture radiometer in aerial stealthy targets detection[J]. Journal of Microwaves, 2012, 28(2): 28–31, 41. doi: 10.14183/j.cnki.1005-6122.2012.02.015

吳露露, 胡飛, 朱耀庭, 等. 毫米波熱輻射陣列的空間譜估計誤差模型研究[J]. 紅外與毫米波學報, 2010, 29(2): 123–127. doi: 10.3724/SP.J.1010.2010.00123

WU Lulu, HU Fei, ZHU Yaoting, et al. Error model for spatial spectrum estimation of millimeter-wave thermal radiation array[J]. Journal of Infrared and Millimeter Waves, 2010, 29(2): 123–127. doi: 10.3724/SP.J.1010.2010.00123

CHENG Yayun, HU Fei, WU Hongfei, et al. Multi-polarization passive millimeter-wave imager and outdoor scene imaging analysis for remote sensing applications[J]. Optics Express, 2018, 26(16): 20145–20159. doi: 10.1364/OE.26.020145

蘇興華, 賀平. THz隱身目標無源遙感建模及仿真分析[J]. 太赫茲科學與電子信息學報, 2017, 15(6): 898–902. doi: 10.11805/TKYDA201706.0898

SU Xinghua and HE Ping. Modeling and simulation of stealth target with THz passive sensing[J]. Journal of Terahertz Science and Electronic Information Technology, 2017, 15(6): 898–902. doi: 10.11805/TKYDA201706.0898

高遠, 張光鋒, 于暢暢, 等. 典型金屬立體目標的毫米波輻射特性研究[J]. 計算機測量與控制, 2019, 27(1): 233–236. doi: 10.16526/j.cnki.11-4762/tp.2019.01.048

GAO Yuan, ZHANG Guangfeng, YU Changchang, et al. Research on MMW radiation characteristic of typical mental targets[J]. Computer Measurement &Control, 2019, 27(1): 233–236. doi: 10.16526/j.cnki.11-4762/tp.2019.01.048

李曙光, 于守江, 姜偉, 等. 綜合孔徑輻射計空中隱身目標探測技術[J]. 無線電工程, 2015, 45(3): 50–53, 61. doi: 10.3969/j.issn.1003-3106.2015.03.14

LI Shuguang, YU Shoujiang, JIANG Wei, et al. Detection of aerial stealthy targets by synthetic aperture microwave radiometer[J]. Radio Engineering, 2015, 45(3): 50–53, 61. doi: 10.3969/j.issn.1003-3106.2015.03.14

盧海梁, 李一楠, 宋廣南, 等. 海面目標星載微波輻射無源探測技術研究[J]. 紅外與毫米波學報, 2019, 38(5): 674–681. doi: 10.11972/j.issn.1001-9014.2019.05.020

LU Hailiang, LI Yinan, SONG Guangnan, et al. Research on the passive detection technology using space-borne synthesis aperture microwave radiometers for the sea surface target[J]. Journal of Infrared and Millimeter Waves, 2019, 38(5): 674–681. doi: 10.11972/j.issn.1001-9014.2019.05.020

盧海梁, 王志強, 高超, 等. 基于被動干涉微波亮溫圖像的海面目標探測算法研究[J]. 電子與信息學報, 2020, 42(3): 563–572. doi: 10.11999/JEIT190256

LU Hailiang, WANG Zhiqiang, GAO Chao, et al. Research on the detection algorithm for sea surface targets based on passive interferometric microwave images[J]. Journal of Electronics &Information Technology, 2020, 42(3): 563–572. doi: 10.11999/JEIT190256

LU Hailiang, LI Yinan, LI Hao, et al. Ship detection by an airborne Passive Interferometric Microwave Sensor (PIMS)[J]. IEEE Transactions on Geoscience and Remote Sensing, 2020, 58(4): 2682–2694. doi: 10.1109/TGRS.2019.2953355

WENTZ F J and MEISSNER T. Atmospheric absorption model for dry air and water vapor at microwave frequencies below 100?GHz derived from spaceborne radiometer observations[J]. Radio Science, 2016, 51(5): 381–391. doi: 10.1002/2015RS005858

MEISSNER T and WENTZ F J. The emissivity of the ocean surface between 6 and 90 GHz over a large range of wind speeds and earth incidence angles[J]. IEEE Transactions on Geoscience and Remote Sensing, 2012, 50(8): 3004–3026. doi: 10.1109/TGRS.2011.2179662

劉西川, 宋堃, 高太長, 等. 復雜大氣條件對微波傳播衰減的影響研究[J]. 電子與信息學報, 2018, 40(1): 181–188. doi: 10.11999/JEIT170253

LIU Xichuan, SONG Kun, GAO Taichang, et al. Research on the effect of complex atmospheric condition on microwave propagation attenuation[J]. Journal of Electronics &Information Technology, 2018, 40(1): 181–188. doi: 10.11999/JEIT170253

倪煒. 空中目標微波輻射特性及檢測方法研究[D]. [博士論文], 華中科技大學, 2012.

NI Wei. Microwave radiation characteristics and detection method research in aerial target detection[D]. [Ph. D. dissertation], Huazhong University of Science and Technology, 2012.
