虛擬網絡切片中的在線異常檢測算法研究

王威麗; 陳前斌; 唐倫

doi:10.11999/JEIT190531

虛擬網絡切片中的在線異常檢測算法研究

doi: 10.11999/JEIT190531 cstr: 32379.14.JEIT190531

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶郵電大學移動通信重點實驗室重慶 400065

基金項目: 國家自然科學基金(61571073)，重慶市教委科學技術研究項目(KJZD-M201800601)

詳細信息

作者簡介:
王威麗：女，1994年生，博士生，研究方向?yàn)樘摂M化網絡切片、人工智能算法等

陳前斌：男，1967年生，教授，博士生導師，研究方向?yàn)閭€(gè)人通信、多媒體信息處理與傳輸、下一代移動通信網絡

唐倫：男，1973年生，教授，博士生導師，研究方向?yàn)樾乱淮鸁o(wú)線通信網絡、異構蜂窩網絡

通訊作者:
陳前斌　cqb@cqupt.edu.cn

中圖分類號: TN929.5
計量
- 文章訪問數: 2838
- HTML全文瀏覽量: 1034
- PDF下載量: 92
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-15
- 修回日期: 2020-02-12
- 網絡出版日期: 2020-03-03
- 刊出日期: 2020-06-22

Online Anomaly Detection for Virtualized Network Slicing

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Mobile Communications, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61571073), The Science and Technology Research Program of Chongqing Municipal Education Commission (KJZD-M201800601)

摘要

摘要:
在虛擬化網絡切片場景中，底層物理網絡中一個物理節點(PN)或一條物理鏈路(PL)的異常會造成多個網絡切片的性能退化。因網絡中每個時刻都會產生新的測量數據，該文設計了兩種在線異常檢測算法實時監督物理網絡的工作狀態。首先，該文提出了一種基于在線一類支持向量機(OCSVM)的PN異常檢測算法，該算法可根據每個時刻虛擬節點(VNs)的新測量數據進行模型參數的更新而不需要任何標簽數據；其次，基于虛擬鏈路兩端點間測量數據的自然相關性，該文提出基于在線典型相關分析(CCA)的PL異常檢測算法，該算法只需要少量標簽數據就可以準確分析出PL的異常情況。仿真結果驗證了該文所提在線異常檢測算法的有效性和魯棒性。
- 虛擬網絡切片 /
- 異常檢測 /
- 在線一類支持向量機 /
- 在線典型相關分析
Abstract:
In virtualized network slicing scenario, one anomaly Physical Node (PN) or Physical Link (PL) in substrate networks will cause performance degradation of multiple network slices. For new measurements are achieved in each period, two online anomaly detection algorithms to monitor the working states of substrate networks in real time are designed. An online One-Class Support Vector Machine (OCSVM) algorithm is first proposed in this paper to detect the working states of PNs. Without requiring any labeled data, the model parameters of OCSVM can be updated based on the new measurements of Virtual Nodes (VNs) in each iteration. Then, an online Canonical Correlation Analysis (CCA) based PL anomaly detection algorithm is proposed according to the natural correlation of measurements between neighboring VNs of virtual links. With a small amount of labeled data, the algorithm can accurately analyze the working states of PLs. The simulation results verify the effectiveness and robustness of the proposed online anomaly detection algorithms for the virtualized network slicing.
- Virtualized network slicing /
- Anomaly detection /
- Online One-Class Support Vector Machine (OCSVM) /
- Online Canonical Correlation Analysis (CCA)

HTML全文

圖 1 網絡切片管理示意圖

下載: 全尺寸圖片幻燈片

圖 2 在線OCSVM算法和經典OCSVM算法的性能對比圖

下載: 全尺寸圖片幻燈片

圖 3 在線OCSVM算法中${{w}}$和$\rho $的收斂過程

下載: 全尺寸圖片幻燈片

圖 4 在線CCA算法和CCA算法的性能對比圖

下載: 全尺寸圖片幻燈片

圖 5 在線異常檢測算法在真實網絡數據集上的性能對比圖

下載: 全尺寸圖片幻燈片

表 1 基于在線OCSVM的PN異常檢測算法

初始化：總迭代次數$T$，特征空間維度$D$，隨機初始化PN $q(0 \le q \le Q)$的估計值${{{w}}_q}(0),{\rho _q}(0)$和${\xi _q}(0)$
(1) for $t = 0,1,2,···,T$ do
(2)　PN $q$產生新的訓練樣本${{{x}}_q}(t)$，使用隨機近似函數計算$\varphi ({{{x}}_q}(t))$的近似值${z_q}(t)$
(3)　根據式(8a)、式(8b)和式(8c)計算${{\text{?}} _{ { {{w} }_q} } }{f_q}(t),{{\text{?}}_{ {\rho _q} } }{f_q}(t)$和${{\text{?}} _{ {\xi _q} } }{f_q}(t)$
(4)　根據式(7a)、式(7b)和式(7c)計算${{{w}}_q}(t),{\rho _q}(t)$和${\xi _q}(t)$
(5)　計算$g({{{x}}_q}(t)) = {\rm{sgn}} ({{{w}}^{\rm{T}}}(t) \cdot {{{z}}_q}(t) - \rho (t))$
(6)　　if $g({{{x}}_q}(t)) = = 1$ then
(7)　　　判定當前時刻PN $q$為正常節點，更新參數${{{w}}_q}(t),{\rho _q}(t)$和${\xi _q}(t)$
(8)　　else
(9)　　判定當前時刻PN $q$為異常節點，保留$t - 1$時刻參數值，丟棄當前值
(10) end for

下載: 導出CSV

表 2 基于在線CCA的PL異常檢測算法

初始化：初始標簽采樣個數$t$，映射到物理路徑${\rm{P}}{{\rm{N}}_m}\mathop \to \limits^{{\rm{P}}{{\rm{L}}_{m,m + 1}}} {\rm{P}}{{\rm{N}}_{m + 1}}$兩端的${\rm{VN}}{{\rm{F}}_l}$和${\rm{VN}}{{\rm{F}}_{l + 1}}$測量數據${{U}}(t)$和${{Y}}(t)$，控制門限值$T_{r,{\rm{cl}}}^2$，迭　代次數$T$
(1)計算${{U}}(t)$和${{Y}}(t)$的協方差矩陣和均值向量：${{{\varSigma}} _{{{U}}(t)}},{{{\varSigma}} _{{{Y}}(t)}},{{{\varSigma}} _{{{U}}(t){{Y}}(t)}},[{c_1}(t)\;...\;{c_p}(t)]$和$[{d_1}(t)\;...\;{d_q}(t)]$
(2) for $t = t + 1:T$ do
(3)　根據式(16)、式(17)計算${{{\varSigma}} _{{{U}}(t)}}$, ${{{\varSigma}} _{{{Y}}(t)}}$和${{{\varSigma}} _{{{U}}(t){{Y}}(t)}}$
(4)　根據式(11)對矩陣${{K}}(t)$進行奇異值分解
(5)　根據式(12)計算典型相關變量${{J}}(t)$和${{L}}(t)$
(6)　根據式(13)生成最優異常檢測殘差${{r}}(t)$ 并建立${T^2}$檢驗：$T_{r(t)}^2 = {{{r}}^{\rm{T}}}(t){{\varSigma}} _{r(t)}^{ - 1}{{r}}(t)$
(7)　if $T_{r(t)}^2 \le T_{r,{\rm{cl} } }^2$ then
(8)　　　判定${\rm{P}}{{\rm{L}}_{m,m + 1}}$為正常鏈路，更新協方差矩陣和均值向量
(9)　　else
(10)　　　判定${\rm{P}}{{\rm{L}}_{m,m + 1}}$為異常鏈路，保留上一時刻協方差矩陣和均值向量，丟棄當前值
(11) end for

下載: 導出CSV

表 3 仿真參數

參數	數值
每條SFC包含的VNF數	4～6個
EMBB(到達率，數據包大小)	(10 packets/s,200 kbit/packets)
URLLC(到達率，數據包大小)	(100 packets/s,10 kbit/packets)
MMTC(到達率，數據包大小)	(500 packets/s,1 kbit/packets)
特征空間維度($D$)	100
初始標簽采樣個數($t$)	10

下載: 導出CSV

參考文獻(17)

ORDONEZ-LUCENA J, AMEIGEIRAS P, LOPEZ D, et al. Network Slicing for 5G with SDN/NFV: Concepts, architectures, and challenges[J]. IEEE Communications Magazine, 2017, 55(5): 80–87. doi: 10.1109/MCOM.2017.1600935

ELAYOUBI S E, JEMAA S B, ALTMAN Z, et al. 5G RAN slicing for verticals: Enablers and challenges[J]. IEEE Communications Magazine, 2019, 57(1): 28–34. doi: 10.1109/MCOM.2018.1701319

OI A, ENDOU D, MORIYA T, et al. Method for estimating locations of service problem causes in service function chaining[C]. 2015 IEEE Global Communications Conference, San Diego, USA, 2016. doi: 10.1109/GLOCOM.2015.7416993.

YOUSAF F Z, BREDEL M, SCHALLER S, et al. NFV and SDN - key technology enablers for 5G networks[J]. IEEE Journal on Selected Areas in Communications, 2017, 35(11): 2468–2478. doi: 10.1109/JSAC.2017.2760418

陳前斌, 楊友超, 周鈺, 等. 基于隨機學習的接入網服務功能鏈部署算法[J]. 電子與信息學報, 2019, 41(2): 417–423. doi: 10.11999/JEIT180310

CHEN Qianbin, YANG Youchao, ZHOU Yu, et al. Deployment algorithm of service function chain of access network based on stochastic learning[J]. Journal of Electronics &Information Technology, 2019, 41(2): 417–423. doi: 10.11999/JEIT180310

COTRONEO D, NATELLA R, and ROSIELLO S. A fault correlation approach to detect performance anomalies in virtual network function chains[C]. The 2017 IEEE 28th International Symposium on Software Reliability Engineering, Toulouse, France, 2017. doi: 10.1109/ISSRE.2017.12.

SCH?LKOPF B, PLATT J C, SHAWE-TAYLOR J, et al. Estimating the support of a high-dimensional distribution[J]. Neural Computation, 2001, 13(7): 1443–1471. doi: 10.1162/089976601750264965

JIANG Qingchao and YAN Xuefeng. Multimode process monitoring using variational bayesian inference and canonical correlation analysis[J]. IEEE Transactions on Automation Science and Engineering, 2019, 16(4): 1814–1824. doi: 10.1109/TASE.2019.2897477

LI Xiaocan, XIE Kun, WANG Xin, et al. Online internet anomaly detection with high accuracy: A fast tensor factorization solution[C]. IEEE INFOCOM 2019-IEEE Conference on Computer Communications, Paris, France, 2019: 1900–1908. doi: 10.1109/INFOCOM.2019.8737562.

DE LA OLIVA A, LI Xi, COSTA-PEREZ X, et al. 5G-TRANSFORMER: Slicing and orchestrating transport networks for industry verticals[J]. IEEE Communications Magazine, 2018, 56(8): 78–84. doi: 10.1109/MCOM.2018.1700990

MIAO Xuedan, LIU Ying, ZHAO Haiquan, et al. Distributed online one-class support vector machine for anomaly detection over networks[J]. IEEE Transactions on Cybernetics, 2019, 49(4): 1475–1488. doi: 10.1109/TCYB.2018.2804940

RAHIMI A and RECHT B. Random features for large-scale kernel machines[C]. The 20th International Conference on Neural Information Processing Systems, Charlotte, USA, 2007.

SHALEV-SHWARTZ S, SINGER Y, and SREBRO N. Pegasos: Primal estimated sub-GrAdient sOlver for SVM[C]. The 24th International Conference on Machine learning, Corvallis, USA, 2007. doi: 10.1145/1273496.1273598.

JIANG Qingchao, DING S X, WANG Yang, et al. Data-driven distributed local fault detection for large-scale processes based on the GA-regularized canonical correlation analysis[J]. IEEE Transactions on Industrial Electronics, 2017, 64(10): 8148–8157. doi: 10.1109/TIE.2017.2698422

任馳, 馬瑞濤. 網絡切片: 構建可定制化的5G網絡[J]. 中興通訊技術, 2018, 24(1): 26–30. doi: 10.3969/j.issn.1009-6868.2018.01.006

REN Chi and MA Ruitao. Network slicing: Building customizable 5G network[J]. ZTE Technology Journal, 2018, 24(1): 26–30. doi: 10.3969/j.issn.1009-6868.2018.01.006

XIE Kun, LI Xiaocan, WANG Xin, et al. On-line anomaly detection with high accuracy[J]. IEEE/ACM transactions on networking, 2018, 26(3): 1222–1235. doi: 10.1109/TNET.2018.2819507

FU Songwei and ZHANG Yan. The due/packet-delivery (v. 2015-04-01)[EB/OL]. https://doi.org/10.15783/C7NP4Z, 2015.
