面向可靠性的5G網絡切片重構及映射算法

趙國繁; 唐倫; 胡彥娟; 趙培培; 陳前斌

doi:10.11999/JEIT190500

面向可靠性的5G網絡切片重構及映射算法

doi: 10.11999/JEIT190500 cstr: 32379.14.JEIT190500

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶郵電大學移動通信技術重點實驗室重慶 400065

基金項目: 國家自然科學基金(61571073)，重慶市教委科學技術研究項目(KJZD-M201800601)

詳細信息

作者簡介:
趙國繁：女，1993年生，碩士，研究方向為5G網絡切片中的資源分配，可靠性

唐倫：男，1973年生，教授，博士生導師，研究方向為新一代無線通信網絡、異構蜂窩網絡、軟件定義無線網絡等

胡彥娟：女，1993年生，碩士生，研究方向為網絡切片的映射與資源分配

趙培培：女，1993年生，碩士生，研究方向為5G網絡切片、網絡虛擬化

陳前斌：男，1967年生，教授，博士生導師，主要研究方向為個人通信、多媒體信息處理與傳輸、下一代移動通信網絡、異構蜂窩網絡等

通訊作者:
趙國繁　1349366355@qq.com

中圖分類號: TN929.5
計量
- 文章訪問數: 3870
- HTML全文瀏覽量: 1687
- PDF下載量: 118
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-04
- 修回日期: 2020-02-16
- 網絡出版日期: 2020-03-11
- 刊出日期: 2020-06-22

A Reliability-aware 5G Network Slice Reconfiguration and Embedding Algorithm

1.
School of Communication and Information Engineering, Chongqing University of Post and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Mobile Communication Technology, Chongqing University of Post and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61571073), The Science and Technology Research Program of Chongqing Municipal Education Commission (KJZD-M201800601)

摘要

摘要:
針對傳統網絡切片映射方法資源利用率低且可靠性差的問題，該文提出了可靠性感知的網絡切片(NS)重構及映射策略(RNSRE)。首先，建立了面向可靠性和資源的網絡切片可靠映射效用函數。其次，綜合考慮虛擬網絡功能(VNF)的資源需求和位置約束，提出了一種VNF可靠性需求的度量方法。在此基礎上，以最大化VNF可靠部署收益的同時最小化鏈路帶寬資源開銷為目標，建立了切片可靠映射整數線性規劃模型。最后，針對不同的網絡切片類型，提出了基于鄰域搜索的網絡切片映射算法和關鍵VNF備份的網絡切片重構映射算法。仿真結果表明，所提算法在滿足VNF可靠性需求的同時，提高了資源利用率，降低了映射的開銷。
- 5G網絡切片 /
- 可靠映射 /
- 資源利用率
Abstract:
Considering the problems of low resource utilization and poor reliability of traditional network slice embedding, a Reliability-aware Network Slice (NS) Reconfiguration and Embedding (RNSRE) strategy is proposed. Firstly, a utility function of reliable embedding oriented reliability and available resources is established. Then, considering the resource requirements and the location constraints of Virtual Network Function (VNF), a method is proposed to quantify the reliability requirement of VNF. Based on the above works, the reliable network slice embedding problem is formulated as an integer linear programming which maximizes the profits of reliable VNF deployment while minimizing the consumption of link bandwidth resource. Finally, according to different types of network slices, a network slice reliable embedding algorithm based on neighborhood search and a network slice reconfiguration embedding algorithm based on key VNF backup are proposed. Simulation results show that the proposed algorithms improve the resources utilization and reduce the embedding cost while meeting the reliability of VNF.
- 5G Network Slice (NS) /
- Reliable embedding /
- Resource utilization

HTML全文

圖 1 5G網絡切片場景

下載: 全尺寸圖片幻燈片

圖 2 不同算法平均成本比較

下載: 全尺寸圖片幻燈片

圖 3 所提算法與3種算法的平均物理節點、鏈路資源利用率累計分布函數

下載: 全尺寸圖片幻燈片

圖 4 不同算法NSR平均接受率比較

下載: 全尺寸圖片幻燈片

圖 5 不同算法到達的可靠性比較

下載: 全尺寸圖片幻燈片

表 1 基于鄰域搜索的網絡切片映射算法

輸入：NSR $G_v^{\rm{g}} = (V_{\rm{g}},E_{\rm{g}},R_{{\rm{req}}}^{\rm{g}})$，物理網絡${G_{\rm{s}}} = \left( {{N_{\rm{s}}},{L_{\rm{s}}}} \right)$	(5)　　　　${P_i} = P_{{\rm{next}}}^{\rm{g}}$, ${R_{{\rm{gap}}}} = \displaystyle\prod\limits_{{n_i} \in P_{{\rm{next}}}^{\rm{g}}} {{R_i}} - R_{{\rm{req}}}^{\rm{g}}$
輸出：NSE方案${P^{\rm{g}}} = \left[ {P^{\rm{g}}\left( {{v_k}} \right),P^{\rm{g}}\left( {{e_k}} \right)} \right]$	(6)　　　　計算當前的帶寬消耗為${b_{\rm{g}}}$
(1) 搜索空間$S$, $P_{{\rm{opt}}}^{\rm{g}} = {P_{{\rm{init}}}}$; ${P_i} = P_{{\rm{init}}}^{\rm{g}}$	(7)　　　end if
(2) while($0.5 \le { { {R_{ {\rm{gap} } } }} / { {R_{ {\rm{req} } } } } } + { {\left( { {b^{\rm{g} } } - b_{ {\rm{req} } }^{\rm{g} } } \right)} / {b_{ {\rm{req} } }^{\rm{g} } } } \le 1$), do	(8)　　　if $\left( {{\rm Obj}\left( {P_{ {\rm{next} } }^{\rm{g} } } \right) < {\rm Obj}\left( {P_{ {\rm{opt} } }^{\rm{g} } } \right)} \right)$ then
(3)　　　在${P_i}$的鄰域解中搜索當前更優的個體$P_{{\rm{next}}}^{\rm{g}}$	(9)　　　　$P_{{\rm{opt}}}^{\rm{g}} = P_{{\rm{next}}}^{\rm{g}}$
(4)　　　if $\displaystyle\prod\limits_{ {n_i} \in P_{ {\rm{next} } }^{\rm{g} } } { {R_i} } \ge R_{ {\rm{req} } }^{\rm{g} }$ then	(10)　　　end if
	(11)　end while

下載: 導出CSV

表 2 關鍵VNF備份網絡切片重構算法

輸入：NSR $G_v^{\rm{g}} = (V_{\rm{g}},E_{\rm{g}})$，備份節點集${V_{{\rm{reconf}}}}$
輸出：${P^{\rm{g}}} = \left[ {P_{}^{\rm{g}}\left( {{v_k}} \right),P_{}^{\rm{g}}\left( {{e_k}} \right)} \right]$
(1) for each $v_i^{\rm{g}} \in {V_{{\rm{reconf}}}}$
(2)　專有備份節點$v_i^b$, $C_k^b = C_i^{\rm{g}}$，
(3)　備份鏈路
(4)　基于式(23)得到$R\left( {G_{{\rm{backup}}}^{\rm{g}}} \right)$
(5) end for
(6) while($R\left( {G_{ {\rm{backup} } }^{\rm{g} } } \right) \le R_{ {\rm{req} } }^{\rm{g} }$), do
(7)　　for all $v_k^{\rm{g}} \in {V_{\rm{g}}}$, do
(8)　　　按照VNF可靠性遞增，對節點進行排序

(9)　　　選擇相鄰VNF對提供共享備份節點$v_i^b$, $C_k^b = \max \left\{ {C_i^{\rm g} ,C_j^{\rm{g}}} \right\}$
(10)　　　選擇關鍵VNF對$v_i^{\rm{g}},v_j^{\rm{g}} = {\rm{arg}}\;{\rm{max}}\left\{ {{\theta _{ij}}|v_i^{\rm{g}},v_j^{\rm{g}} \in {V_{\rm{g}}}} \right\}$
(11)　　　根據$v_i^{\rm{g}},v_j^{\rm{g}} \in {V_{\rm{g}}}$的狀態，選擇共享備份可靠性估算模型得到
　　　　 $R\left( {G_{{\rm{backup}}}^{\rm{g}}} \right)$
(12)　　end for
(13)　　　鏈路備份
(14) end while
(15) return

下載: 導出CSV

表 3 仿真參數設置表

仿真參數	參數設置	仿真參數	參數設置
物理節點的數目	N=12, 25, 36	物理節點CPU資源容量	U[10, 20]
物理節點可靠性分布	U[0.95, 0.99]	物理鏈路帶寬資源容量	U[20, 50]
NSR的VNF個數	3	NSR生命周期	[4, 12, 24]
3種類型切片的可靠性需求	U[0.90, 0.98]	VNF節點CPU資源需求	U[2, 6]
VNF之間帶寬資源需求	U[8, 16]

下載: 導出CSV

參考文獻(17)

ZHANG Haijun, LIU Na, CHU Xiaoli, et al. Network slicing based 5G and future mobile networks: Mobility, resource management, and challenges[J]. IEEE Communications Magazine, 2017, 55(8): 138–145. doi: 10.1109/MCOM.2017.1600940

ORDONEZ-LUCENA J, AMEIGEIRAS P, LOPEZ D, et al. Network slicing for 5G with SDN/NFV: Concepts, architectures, and challenges[J]. IEEE Communications Magazine, 2017, 55(5): 80–87. doi: 10.1109/MCOM.2017.1600935

FOUKAS X, PATOUNAS G, ELMOKASHFI A, et al. Network slicing in 5G: Survey and challenges[J]. IEEE Communications Magazine, 2017, 55(5): 94–100. doi: 10.1109/MCOM.2017.1600951

LI Xi, CASELLAS R, LANDI G, et al. 5G-crosshaul network slicing: Enabling multi-tenancy in mobile transport networks[J]. IEEE Communications Magazine, 2017, 55(8): 128–137. doi: 10.1109/MCOM.2017.1600921

VASSILARAS S, GKATZIKIS L, LIAKOPOULOS N, et al. The algorithmic aspects of network slicing[J]. IEEE Communications Magazine, 2017, 55(8): 112–119. doi: 10.1109/MCOM.2017.1600939

ZHANG Nan, LIU Yafeng, FARMANBAR H, et al. Network slicing for service-oriented networks under resource constraints[J]. IEEE Journal on Selected Areas in Communications, 2017, 35(11): 2512–2521. doi: 10.1109/JSAC.2017.2760147

GUAN Wanqing, WEN Xiangming, WANG Luhan, et al. A service-oriented deployment policy of end-to-end network slicing based on complex network theory[J]. IEEE Access, 2018, 6: 19691–19701. doi: 10.1109/ACCESS.2018.2822398

劉光遠, 蘇森. 面向底層單節點失效的輕量級可靠虛擬網絡映射算法[J]. 電子與信息學報, 2013, 35(11): 2644–2649. doi: 10.3724/SP.J.1146.2013.00254

LIU Guangyuan and SU Sen. Less stringent reliable virtual network mapping algorithm for substrate single node failure[J]. Journal of Electronics &Information Technology, 2013, 35(11): 2644–2649. doi: 10.3724/SP.J.1146.2013.00254

LIU Jiajia, JIANG Zhongyuan, KATO N, et al. Reliability evaluation for NFV deployment of future mobile broadband networks[J]. IEEE Wireless Communications, 2016, 23(3): 90–96. doi: 10.1109/MWC.2016.749807

KONG Jian, KIM I, WANG Xi, et al. Guaranteed-availability network function virtualization with network protection and VNF replication[C]. 2017 IEEE Global Communications Conference, Singapore, 2017: 1–6. doi: 10.1109/GLOCOM.2017.8254730.

CHEN Yiheng, AYOUBI S, and ASSI C. CORNER: COst-efficient and reliability-aware virtual NEtwork redesign and embedding[C]. The 3rd IEEE International Conference on Cloud Networking, Luxembourg, 2014: 356–361. doi: 10.1109/CloudNet.2014.6969021.

SUN Jian, ZHU Guangyang, SUN Gang, et al. A reliability-aware approach for resource efficient virtual network function deployment[J]. IEEE Access, 2018, 6: 18238–18250. doi: 10.1109/ACCESS.2018.2815614

BIJWE S, MACHIDA F, ISHIDA S, et al. End-to-end reliability assurance of service chain embedding for network function virtualization[C]. 2017 IEEE Conference on Network Function Virtualization and Software Defined Networks (NFV-SDN), Berlin, Germany, 2017: 1–4. doi: 10.1109/NFV-SDN.2017.8169853.

QU L, ASSI C, SHABAN K, et al. A reliability-aware network service chain provisioning with delay guarantees in NFV-enabled enterprise datacenter networks[J]. IEEE Transactions on Network and Service Management, 2017, 14(3): 554–568. doi: 10.1109/TNSM.2017.2723090

CATELANI M, CIANI L, PATRIZI G, et al. Reliability allocation procedures in complex redundant systems[J]. IEEE Systems Journal, 2018, 12(2): 1182–1192. doi: 10.1109/JSYST.2017.2651161

FAN Jingyuan, YE Zilong, GUAN Chaowen, et al. GREP: Guaranteeing reliability with enhanced protection in NFV[C]. 2015 ACM SIGCOMM Workshop on Hot Topics in Middleboxes and Network Function Virtualization, London, UK, 2015: 13–18.

MIZIULA P and NAVARRO J. Birnbaum importance measure for reliability systems with dependent components[J]. IEEE Transactions on Reliability, 2019, 68(2): 439–450. doi: 10.1109/TR.2019.2895400
