一種基于半定松弛技術的TDOA-FDOA無源定位算法

孫霆,  董春曦,  毛昱

孫霆, 董春曦, 毛昱. 一種基于半定松弛技術的TDOA-FDOA無源定位算法[J]. 電子與信息學報, 2020, 42(7): 1599-1605. doi: 10.11999/JEIT190435
引用本文: 孫霆, 董春曦, 毛昱. 一種基于半定松弛技術的TDOA-FDOA無源定位算法[J]. 電子與信息學報, 2020, 42(7): 1599-1605. doi: 10.11999/JEIT190435
Ting SUN, Chunxi DONG, Yu MAO. A TDOA-FDOA Passive Positioning Algorithm Based on the Semi-Definite Relaxation Technique[J]. Journal of Electronics & Information Technology, 2020, 42(7): 1599-1605. doi: 10.11999/JEIT190435
Citation: Ting SUN, Chunxi DONG, Yu MAO. A TDOA-FDOA Passive Positioning Algorithm Based on the Semi-Definite Relaxation Technique[J]. Journal of Electronics & Information Technology, 2020, 42(7): 1599-1605. doi: 10.11999/JEIT190435

一種基于半定松弛技術的TDOA-FDOA無源定位算法

doi: 10.11999/JEIT190435 cstr: 32379.14.JEIT190435

  • 西安電子科技大學電子工程學院 西安 710071

詳細信息
    作者簡介:

    孫霆：男，1994年生，博士生，研究方向?yàn)闊o源定位

    董春曦：男，1970年生，教授，博士生導師，研究方向?yàn)槔走_(dá)/通信輻射源無源定位技術、高分辨雷達干擾技術、雷達/雷達對抗系統仿真等

    毛昱：男，1994年生，博士生，研究方向?yàn)檩椛湓醋R(shí)別

    通訊作者:

    董春曦　chxdong@mail.xidian.edu.cn

  • 中圖分類號: TN97

A TDOA-FDOA Passive Positioning Algorithm Based on the Semi-Definite Relaxation Technique

  • School of Electronic Engineering, Xidian University, Xi’an 710071, China

  • 摘要:

    在運動目標的無源定位場景下，閉式算法在低噪聲情況下可以到達克拉美羅下界(CRLB)，但是這些算法往往不能適應較大的測量噪聲環境。針對目前閉式算法適應大噪聲能力較差這一問題，該文聯合到達時間差(TDOA)以及到達頻率差(FDOA)，提出一種基于半定松弛(SDR)技術的無源定位算法。該算法首先構建傳統閉式解的偽線性方程，其次利用隨機魯棒最小二乘(SRLS)的思想以及目標參數與額外變量之間的非線性關系，將無源定位問題轉化為了具有2次等式約束的最小二乘問題；隨后，將半定松弛技術應用到這一問題上，約束最小二乘問題松弛為半定規劃(SDP)問題，最后，借助優化工具箱可以有效地對目標參數進行求解。該文所提出的算法不需要初始值先驗條件，仿真實驗表明了所提算法的有效性。

    Abstract:

    In the passive location of moving target, the closed-form solution can reach Cramér-Rao Lower Bound (CRLB) under the low noise level, but these algorithms often can not adapt to the large measurement noise condition. For this problem, this paper proposes a passive positioning algorithm based on the Semi-Definite Relaxation (SDR) using Time Difference Of Arrival (TDOA) and Frequency Difference Of Arrival (FDOA). Firstly, this method constructs the pseudo-linear equation of the typical closed-form solution. Secondly, the idea of Stochastic Robust Least Squares (SRLS) and the nonlinear relationship between the target parameters and the additional variables are used to transform the localization problem into the least squares problem with quadratic equality. Using Semi-Definite Programming (SDP) technique, constrained least squares problem is then converted into the SDP problem, which is finally solved by the optimization toolbox. The proposed method does not require an initial priori information and simulations show the effectiveness of the proposed method.

    • HTML全文

  • 圖  1  近場目標估計均方根誤差對比

    圖  2  遠場目標估計均方根誤差對比

    圖  3  不同時刻目標估計均方根誤差對比

    表  1  觀測站的位置與速度

    序號位置速度(m/s)
    130010015030–2020
    2400150100–301020
    330050020010–2010
    4350200100102030
    5–100–100–100–202020
    下載: 導出CSV

    表  2  不同算法平均CPU運行時間

    算法平均CPU運行時間
    改進TSWLS[16]0.0016
    改進的非完全約束算法[17]0.0080
    SDR算法[18]0.1720
    本文方法0.1600
    下載: 導出CSV
  • 王鼎, 胡濤. 無源定位技術-二次等式約束最小二乘估計理論與方法[M]. 北京: 電子工業出版社, 2018: 3–9.

    WANG Ding and HU Tao. Least-Squares Estimation Theory and Method in Passive Location with Quadratic Equality Constraints[M]. Beijing: Publishing House of Electronics Industry, 2018: 3–9.
    朱國輝, 馮大政, 聶衛科. 傳感器位置誤差情況下基于多維標度分析的時差定位算法[J]. 電子學報, 2016, 44(1): 21–26. doi: 10.3969/j.issn.0372-2112.2016.01.004

    ZHU Guohui, FENG Dazheng, and NIE Weike. Multidimensional scaling based TDOA localization algorithm with sensor location errors[J]. Acta Electronica Sinica, 2016, 44(1): 21–26. doi: 10.3969/j.issn.0372-2112.2016.01.004
    WANG Yue and HO K C. An asymptotically efficient estimator in closed-form for 3-D AOA localization using a sensor network[J]. IEEE Transactions on Wireless Communications, 2015, 14(12): 6524–6535. doi: 10.1109/twc.2015.2456057
    趙勇勝, 趙擁軍, 趙闖. 基于雙基地距離的多站多外輻射源無源定位算法[J]. 電子學報, 2018, 46(12): 2840–2847. doi: 10.3969/j.issn.0372-2112.2018.12.004

    ZHAO Yongsheng, ZHAO Yongjun, and ZHAO Chuang. Multi-transmitter multi-receiver passive location using bistatic range measurements[J]. Acta Electronica Sinica, 2018, 46(12): 2840–2847. doi: 10.3969/j.issn.0372-2112.2018.12.004
    周龍健, 羅景青, 孔輝. 基于虛擬時差的運動陣列空間無源定位算法[J]. 電子與信息學報, 2017, 39(7): 1759–1763. doi: 10.11999/JEIT160860

    ZHOU Longjian, LUO Jingqing, and KONG Hui. A passive location algorithm based on the virtual TDOAs of moving array[J]. Journal of Electronics &Information Technology, 2017, 39(7): 1759–1763. doi: 10.11999/JEIT160860
    TAHAT A, KADDOUM G, YOUSEFI S, et al. A look at the recent wireless positioning techniques with a focus on algorithms for moving receivers[J]. IEEE Access, 2017, 4: 6652–6680. doi: 10.1109/ACCESS.2016.2606486
    INDELMAN V, GURFIL P, RIVLIN E, et al. Real-time vision-aided localization and navigation based on three -view geometry[J]. IEEE Transactions on Aerospace and Electronic Systems, 2012, 48(3): 2239–2259. doi: 10.1109/TAES.2012.6237590
    DEMPSTER A G and CETIN E. Interference localization for satellite navigation systems[J]. Proceedings of the IEEE, 2016, 104(6): 1318–1326. doi: 10.1109/jproc.2016.2530814
    FOY W H. Position-location solutions by taylor-series estimation[J]. IEEE Transactions on Aerospace and Electronic Systems, 1976, AES-12(2): 187–194. doi: 10.1109/TAES.1976.308294
    HO K C and XU Wenwei. An accurate algebraic solution for moving source location using TDOA and FDOA measurements[J]. IEEE Transactions on Signal Processing, 2004, 52(9): 2453–2463. doi: 10.1109/tsp.2004.831921
    KAY S M. Fundamentals of Statistical Signal Processing Volume I: Estimation Theory[M]. Upper Saddle River: Prentice Hall, 1993: 23–45.
    HO K C, LU Xiaoning, and KOVAVISARUCH L. Source localization using TDOA and FDOA measurements in the presence of receiver location errors: Analysis and solution[J]. IEEE Transactions on Signal Processing, 2007, 55(2): 684–696. doi: 10.1109/tsp.2006.885744
    SUM Ming and HO K C. An asymptotically efficient estimator for TDOA and FDOA positioning of multiple disjoint sources in the presence of sensor location uncertainties[J]. IEEE Transactions on Signal Processing, 2011, 59(7): 3434–3440. doi: 10.1109/TSP.2011.2131135
    WEI Hewen, PENG Rong, WAN Qun, et al. Multidimensional scaling analysis for passive moving target localization with TDOA and FDOA measurements[J]. IEEE Transactions on Signal Processing, 2010, 58(3): 1677–1688. doi: 10.1109/TSP.2009.2037666
    劉洋, 楊樂, 郭福成, 等. 基于定位誤差修正的運動目標TDOA/FDOA無源定位方法[J]. 航空學報, 2015, 36(5): 1617–1626. doi: 10.7527/S1000-6893.2015.0010

    LIU Yang, YANG Le, GUO Fucheng, et al. Moving targets TDOA/FDOA passive localization algorithm based on localization error refinement[J]. Acta Aeronautica et Astronautica Sinica, 2015, 36(5): 1617–1626. doi: 10.7527/S1000-6893.2015.0010
    NOROOZI A, OVEIS A H, HOSSEINI S M R, et al. Improved algebraic solution for source localization from TDOA and FDOA measurements[J]. IEEE Wireless Communications Letters, 2018, 7(3): 352–355. doi: 10.1109/LWC.2017.2777995
    周恭謙, 楊露菁, 劉忠. 改進的非完全約束加權最小二乘TDOA/FDOA無源定位方法[J]. 系統工程與電子技術, 2018, 40(8): 1686–1692. doi: 10.3969/j.issn.1001-506X.2018.08.03

    ZHOU Gongqian, YANG Luqing, and LIU Zhong. Improved incomplete constrained weighted least squares TDOA/FDOA passive location method[J]. Systems Engineering and Electronics, 2018, 40(8): 1686–1692. doi: 10.3969/j.issn.1001-506X.2018.08.03
    WANG Gang, LI Youming, and ANSARI N. A semidefinite relaxation method for source localization using TDOA and FDOA measurements[J]. IEEE Transactions on Vehicular Technology, 2013, 62(2): 853–862. doi: 10.1109/TVT.2012.2225074
    ZOU Yanbin, LIU Huaping, XIE Wei, et al. Semidefinite programming methods for alleviating sensor position error in TDOA localization[J]. IEEE Access, 2017, 5: 23111–23120. doi: 10.1109/ACCESS.2017.2752206
    ZOU Yanbin, LIU Huaping, and WAN Qun. An iterative method for moving target localization using TDOA and FDOA Measurements[J]. IEEE Access, 2017, 6: 2746–2754. doi: 10.1109/ACCESS.2017.2785182
    BOYD S and VANDENBERGHE L. Convex Optimization[M]. Cambridge: Cambridge University Press, 2004: 152–160.
    GRANT M, BOYD S, and YE Y. CVX: MATLAB software for disciplined convex programming[EB/OL]. http://cvxr.com/cvx/, 2018.
