High Frequency Channel Multipath Analysis Based on Ionosphere Dispersion

Yonghong WU^{1, 2
, ,},
Chenglin WANG^{1, 2},
Yuanbo REN^{1, 2},
Fuhou ZHOU³

1.
China Research Institute of Radio Wave Propagation, Qingdao 266071, China
2.
Pilot National Laboratory for Marine Science and Technology, Qingdao 266235, China
3.
Shandong Institute of Space Electronic Technology, Yantai 264003, China

Funds: The Marine S&T Fund of Shandong Province for Pilot National Laboratory for Marine Science and Technology (Qingdao) (2018SDKJ0210)

摘要

摘要:
短波鏈路不同傳播模式的多徑時延通常為0.5～2.0 ms，該文研究同一傳播模式的多徑時延，在考慮地磁場影響的情況下，將電離層短波傳播的折射指數和射線追蹤結合起來，給出了數值迭代算法，實現了用數值方法來描述電離層色散引起的多徑時延，并進行了數值仿真，得出短波寬帶通信的模擬帶寬應為48 kHz。
- 射線追蹤 /
- 電離層色散 /
- 多徑時延 /
- 折射指數 /
- 尋常波 /
- 非尋常波
Abstract:
The multipath delay for different propagation mode is 0.5～2.0 ms, and the multipath delay for the same propagation mode is analyzed. Taking into account the earth magnetic field effects, the refractive index of High frequency propagation in ionosphere is combined with ray tracing, and then a new numerical iteration algorithm is given. The multipath delay caused by ionosphere dispersion is analyzed by numerical method, and the simulation is realized. Thus the analogue bandwidth of wideband communication for high frequency should be 48 kHz.
- Ray tracing /
- Ionosphere dispersion /
- Multipath delay /
- Refractive index /
- Ordinary wave /
- Extraordinary wave

HTML全文

圖 1 北美大陸天波鏈路(8 km)實測數據得到的散射函數

下載: 全尺寸圖片幻燈片

表 1 青島-許昌鏈路多徑時延實測結果

序號	1	2	3	4	5	6	7	8	9	10	11	12	13	14
多徑時延(μs)	55	11	30	8	22	8	19	31	31	53	22	30	10	40

下載: 導出CSV

表 2 北美大陸天波鏈路(80 km)路徑時延和多徑時延仿真結果

頻率(MHz)	3.5	3.8	4.1	4.4	4.7	5.0
尋常波時延	1.228	1.312	1.875	1.916	2.000	2.144
非尋常波時延	1.544	1.540	1.624	1.868	2.180	2.308
多徑時延(μs)	316	228	251	48	180	164

下載: 導出CSV

表 3 青島-許昌鏈路路徑時延和多徑時延仿真結果

頻率(MHz)	6.5	7.0	7.5	8.0	8.5	9.0
尋常波時延	2.760	2.912	2.928	2.996	3.168	3.480
非尋常波時延	2.516	3.052	3.000	2.928	2.960	3.164
多徑時延(μs)	244	140	72	68	208	316

下載: 導出CSV

表 4 青島-北京鏈路5點時段路徑時延和多徑時延

頻率(MHz)	4.0	4.5	5.0	5.5	6.0
尋常波時延	2.292	2.280	2.372	2.560	2.764
非尋常波時延	2.264	2.304	2.352	2.408	2.488
多徑時延(μs)	28	24	20	152	276

下載: 導出CSV

表 5 青島-北京鏈路13點時段路徑時延和多徑時延

頻率(MHz)	6.0	6.5	7.0	7.5	8.0	8.5	9.0
尋常波時延	2.572	2.464	2.408	2.484	2.520	2.628	2.944
非尋常波時延	2.776	2.512	2.452	2.440	2.336	2.484	2.644
多徑時延(μs)	204	48	44	40	184	144	300

下載: 導出CSV

表 6 青島-北京鏈路21點時段路徑時延和多徑時延

頻率(MHz)	4.5	5.0	5.5	6.0	6.5	7.0	7.5	8.0
尋常波時延	2.308	2.304	2.356	2.408	2.448	2.764	2.688	2.900
非尋常波時延	2.276	2.308	2.340	2.320	2.396	2.472	2.552	2.720
多徑時延(μs)	32	4	16	88	52	292	136	18

下載: 導出CSV

表 7 青島-上海鏈路5點時段路徑時延和多徑時延

頻率(MHz)	4.0	4.5	5.0	5.5	6.0
尋常波時延	2.440	2.496	2.704	2.624	2.940
非尋常波時延	2.408	2.412	2.412	2.460	2.504
多徑時延(μs)	32	84	292	164	436

下載: 導出CSV

表 8 青島-上海鏈路13點時段路徑時延和多徑時延

頻率(MHz)	6.0	6.5	7.0	7.5	8.0	8.5	9.0	9.5	10.0	10.5
尋常波時延	2.388	2.600	2.536	2.516	2.548	2.580	2.676	2.812	2.716	2.792
非尋常波時延	2.463	2.532	2.420	2.464	2.452	2.540	2.528	2.504	2.608	2.768
多徑時延(μs)	85	68	116	52	96	40	148	308	108	24

下載: 導出CSV

表 9 青島-上海鏈路21點時段路徑時延和多徑時延

頻率(MHz)	5.0	5.5	6.0	6.5	7.0	7.5	8.0
尋常波時延	2.536	2.568	2.616	2.684	2.572	2.912	3.160
非尋常波時延	2.472	2.492	2.528	2.572	2.608	2.572	2.788
多徑時延(μs)	64	76	88	112	36	340	372

下載: 導出CSV

表 10 青島-重慶鏈路5點時段路徑時延和多徑時延

頻率(MHz)	6.0	6.5	7.0	7.5	8.0	8.5	9.0	9.5	10.0
尋常波時延	5.304	5.296	5.292	5.308	5.324	5.320	5.292	5.372	5.472
非尋常波時延	5.296	5.224	5.276	5.288	5.292	5.304	5.240	5.364	5.320
多徑時延(μs)	8	72	16	20	32	16	52	8	152

下載: 導出CSV

表 11 青島-重慶鏈路13點時段路徑時延和多徑時延

頻率(MHz)	11.5	12.0	12.5	13.0	13.5	14.0	14.5
尋常波時延	5.328	5.228	5.316	5.404	5.372	5.360	5.272
非尋常波時延	5.496	5.196	5.144	5.256	5.388	5.364	5.340
多徑時延(μs)	168	32	172	148	16	4	68
頻率(MHz)	15.0	15.5	16.0	16.5	17.0	17.5	18.0
尋常波時延	5.332	5.328	5.332	5.332	5.368	5.380	5.420
非尋常波時延	5.352	5.280	5.324	5.348	5.360	5.356	5.348
多徑時延(μs)	20	48	8	16	8	24	72

下載: 導出CSV

表 12 青島-重慶鏈路21點時段路徑時延和多徑時延

頻率(MHz)	7.0	7.5	8.0	8.5	9.0	9.5	10.0	10.5
尋常波時延	5.226	5.235	5.241	5.304	5.259	5.259	5.280	5.292
非尋常波時延	5.243	5.238	5.253	5.253	5.244	5.274	5.284	5.295
多徑時延(μs)	17	3	12	51	15	15	4	3
頻率(MHz)	11.0	11.5	12.0	12.5	13.0	13.5	14.0	14.5
尋常波時延	5.248	5.308	5.260	5.284	5.340	5.356	5.428	5.388
非尋常波時延	5.256	5.292	5.300	5.308	5.304	5.312	5.352	5.340
多徑時延(μs)	8	16	40	24	36	44	76	48

下載: 導出CSV

表 13 青島-北京鏈路多徑時延的期望和標準差

時段(點)	5	13	21
期望(μs)	100.0	137.7	79.8
標準差(μs)	101.0	99.4	90.1

下載: 導出CSV

表 14 青島-上海鏈路多徑時延的期望和標準差

時段(點)	5	13	21
期望(μs)	201.6	104.5	155.4
標準差(μs)	146.4	76.6	128.9

下載: 導出CSV

表 15 青島-重慶鏈路多徑時延的期望和標準差

時段(點)	5	13	21
期望(μs)	41.8	57.4	25.8
標準差(μs)	43.9	58.7	20.5

下載: 導出CSV
