北斗反射信號海風海浪反演系統與試驗

楊東凱; 王翔宇; 劉建華; 王峰

doi:10.11999/JEIT180397

北斗反射信號海風海浪反演系統與試驗

doi: 10.11999/JEIT180397 cstr: 32379.14.JEIT180397

1.
北京航空航天大學電子信息工程學院 ??北京 ??100083
2.
勝利油田安全環保督查中心 ??東營 ??257000

基金項目: 國家自然科學基金(41774028)，國家重點研發計劃(2017YFB050802)

詳細信息

作者簡介:
楊東凱：男，1971年生，教授，研究方向?yàn)樾l(wèi)星導航信號處理及應用技術、無線傳輸?shù)?/p>
王翔宇：男，1990年生，碩士生，研究方向?yàn)樾l(wèi)星導航信號及其在風浪遙感中的應用

劉建華：男，1975年生，高級工程師，研究方向?yàn)橛吞锇踩a(chǎn)管理

王峰：男，1989年生，博士生，研究方向?yàn)樾l(wèi)星導航信號及其在海洋遙感中的應用

通訊作者:
王峰　wangf.19@163.com

中圖分類號: TN967.1; P237
計量
- 文章訪問數: 1733
- HTML全文瀏覽量: 595
- PDF下載量: 75
- 被引次數: 0
出版歷程
- 收稿日期: 2018-04-27
- 修回日期: 2018-09-10
- 網絡出版日期: 2018-09-21
- 刊出日期: 2019-02-01

BeiDou-reflectometry Sea Wind and Wave Retrieval System and Experiment

1.
School of Electronic and Information Engineering, Beihang University, Beijing 100083, China
2.
Safety and Environmental Supervision Center, Shengli Oil Field, Dongying 257000, China

Funds: The National Natural Science Foundation of China (41774028), The National Key Research and Development Plan (2017YFB050802)

摘要

摘要:
該文設計并實現了一種小型低功耗的北斗反射信號海風海浪反演系統，針對反演精度受衛星高度角影響較大的問題，提出高度角正弦值冪指數修正方法，且為降低風速突變對風速反演的影響，對風速反演模型進行了延時修正，有效提高了有效波高和風速的反演精度。為了進一步提高反演精度，提出多星聯合觀測和單邊濾波的方法。北斗反射信號海風海浪探測試驗結果表明：設計和實現的反演系統具備長期穩定運行和觀測的性能；提出的反演模型和精度提升方法可以有效提高反演精度，有效波高和風速反演精度分別可達0.14 m和1.28 m/s，相比于Soulat等人提出的反演模型，分別提高了0.13 m和0.78 m/s。
- 北斗反射信號 /
- 海風海浪反演 /
- 高度角修正 /
- 多星觀測 /
- 單邊濾波
Abstract:
A low power and cost BeiDou-reflectometry used to retrieve Significiant Wave Height (SWH) and wind is designed and implemented. To improve the retrieval accuracy, a correction method based on the power function of the elevation angle sinusoidal and a delay correlation for the rapid change of wind speed is proposed. Moreover, combined observation of multi-satellite signals and single-side filtering for the observable are performed to improve further the retrieval accuracy. The experiment results of observating SWH and wind speed using reflected BeiDou signals show that designed and developed system could implement long-term and stable observation; the retrieval accuracies of SWH and wind speed retrieved by propsoed retrieval models and improvement methods of the retreival accuracy are 0.13 m and 1.28 m/s which are 0.13 m and 0.78 m/s higher than the methods proposed by Soulat et al.
- Reflected BeiDou signals /
- Wind speed and Significant Wave Height (SWH) retrieval /
- Correction of elevation angle /
- Multi-satellites observation /
- Single-side filtering

HTML全文

圖 1 系統整體框架

下載: 全尺寸圖片幻燈片

圖 2 基帶信號處理流程

下載: 全尺寸圖片幻燈片

圖 3 試驗期間天線架設情況

下載: 全尺寸圖片幻燈片

圖 4 冪指數模型海浪反演結果

下載: 全尺寸圖片幻燈片

圖 5 12月份東營港風浪歸一化數值及變化曲線

下載: 全尺寸圖片幻燈片

圖 6 延遲冪指數模型海風反演結果

下載: 全尺寸圖片幻燈片

圖 7 試驗期間北斗反射可見星分布

下載: 全尺寸圖片幻燈片

圖 8 鄰域?yàn)V波效果

下載: 全尺寸圖片幻燈片

表 1 接收機參數表

設備名稱	尺寸	功耗(W)	工作電壓(V)	反演模塊	輸出結果
GOLD-RTR^[14]	48×48×36	50	220	–	相關波形
GRrSv.2^[15]	48×48×18	50	220	–	相關波形
Oceanpal^[16]	48×48×18	100	100～240	PC機	相關波形、風浪值
本文反演系統	24×24×18	10	36, 220	ARM, PC機	相關波形、風浪值

下載: 導出CSV

表 2 不同反演方法對比

反演模型	優化算法	有效波高誤差 (m)	風速誤差 (m/s)
反比例模型	–	0.27	2.06
反比例模型	–	0.21	1.43
指數模型(對風速延時修正)	多星觀測	0.19	1.36
	平滑濾波	0.16	1.30
	多星&平滑	0.14	1.28

下載: 導出CSV

參考文獻(18)

MARTIN-NEIRA M. A pasive reflectometry and interferometry system (PARIS) application to ocean altimetry[J]. ESA Journal, 1993, 17(4): 331–355.

SOISUVARN S, JELENAK Z, SAID F, et al. The GNSS reflectometry response to the ocean surface winds and waves[J]. IEEE Journal of Selected Topics in Applied Earth Observations & Remote Sensing, 2016, 9(10): 4678–4699. doi: 10.1109/JSTARS.2016.2602703

XU Fei, SUN Xiechang, LIU Xinning, et al. The study on retrieval technique of significant wave height using airborne GNSS-R[C]. Conference of Spacecraft TT&C Technology in China, Singapore, 2016: 401–411.

ZHU Yongchao, YU Kegen, ZOU Jingui, et al. Sea ice detection based on differential delay-doppler maps from UK TechDemoSat-1[J]. Sensors, 2017, 17(7): 1–18. doi: 10.3390/s17071614

王峰, 楊東凱. 星載GNSS-R輔助海洋鹽度探測方法[J]. 北京航空航天大學學報, 2018, 44(1): 108–116. doi: 10.13700/j.bh.1001-5965.2017.0018

WANG Feng and YANG Dongkai. Sea surface salinity determination method assisted by spaceborne GNSS-R[J]. Journal of Beijing University of Aeronautics and Astronautics, 2018, 44(1): 108–116. doi: 10.13700/j.bh.1001-5965.2017.0018

DU Wenying, CHEN Nengcheng, and YAN Songhua. Online soil moisture retrieval and sharing using geospatial web-enabled BDS-R service[J]. Computers & Electronics in Agriculture, 2016, 121: 354–367. doi: 10.1016/j.asr.2016.11.028

GARRISON J L, KATZBERG S J, and HILL M I. Effect of sea roughness on bistatically scattered range coded signals from the Global Positioning System[J]. Geophysical Research Letters, 1998, 25(13): 2257–2260. doi: 10.1029/98GL51615

SOULAT F, CAPARRINI M, GERMAIN O, et al. Sea state monitoring using coastal GNSS‐R[J]. Geophysical Research Letters, 2004, 31(21): 133–147. doi: 10.1029/2004GL020680

ALONSO-ARROYO A, CAMPS A, PARK H, et al. Retrieval of significant wave height and mean sea surface level using the GNSS-R interference pattern technique: Results from a three-month field campaign[J]. IEEE Transactions on Geoscience & Remote Sensing, 2015, 53(6): 3198–3209. doi: 10.1109/TGRS.2014.2371540

WANG Feng, YANG Dongkai, LI Weiqiang, et al. A new retrieval method of significant wave height based on statistics of scattered BeiDou GEO signals[C]. Proceedings of the 28th International Technical Meeting of the Satellite Division of the Institute of Navigation (ION GNSS+2015), Tampa, America, 2015: 3953–3957.

VALENCIA E, CAMPS A, MARCHAN-HERNANDEZ J F, et al. Experimental determination of the sea correlation time using GNSS-R coherent data[J]. IEEE Geoscience & Remote Sensing Letters, 2010, 7(4): 675–679. doi: 10.1109/LGRS.2010.2046135

LI Weiqiang, FABRA F, YANG Dongkai, et al. Initial results of typhoon wind speed observation using coastal GNSS-R of BeiDou GEO satellite[J]. IEEE Journal of Selected Topics in Applied Earth Observations & Remote Sensing, 2016, 9(10): 4720–4729. doi: 10.1109/JSTARS.2016.2523126

公緒艷, 張鳳元, 楊東凱, 等. 基于北斗衛星反射信號的海面風速探測[J]. 現代電子技術, 2017, 40(5): 5–9. doi: 10.16652/j.issn.1004-373x.2017.05.002

GONG Xuyan, ZHANG Fengyuan, YANG Dongkai, et al. Ocean surface wind speed detection based on reflected signal of Beidou satellite[J]. Modern Electronics Technique, 2017, 40(5): 5–9. doi: 10.16652/j.issn.1004-373x.2017.05.002

NOGUES-CORREIG O, GALI E C, CAMPDERROS J S, et al. A GPS-reflections receiver that computes doppler/delay maps in real time[J]. IEEE Transactions on Geoscience & Remote Sensing, 2006, 45(1): 156–174. doi: 10.1109/TGRS.2006.882257

LI Weiqiang, YANG Dongkai, ZHANG Bo, et al. Real-time processing of reflected GNSS signals for remote sensing: System and experiments[J]. The Journal of Navigation, 2011, 64(S1): 127–140. doi: 10.1017/S0373463311000403

Oceanpal Datasheet[OL]. http://www.starlab.es/products/oceanpal. 2003.

周蔭清. 隨機過程理論[M]. 第3版, 北京: 北京航空航天大學出版社, 2013: 64–65.

WANG Xin, SUN Qiang, ZHANG Xunxie, et al. First China ocean reflection experiment using coastal GNSS-R[J]. Chinese Science Bulletin, 2008, 53(7): 1117–1120.
