基于快速S變換時頻空間模型的電磁干擾復雜度評估方法

尹柏強,  王署東,  何怡剛,  佐磊,  李兵,  程珍

尹柏強, 王署東, 何怡剛, 佐磊, 李兵, 程珍. 基于快速S變換時頻空間模型的電磁干擾復雜度評估方法[J]. 電子與信息學報, 2019, 41(1): 195-201. doi: 10.11999/JEIT180256
引用本文: 尹柏強, 王署東, 何怡剛, 佐磊, 李兵, 程珍. 基于快速S變換時頻空間模型的電磁干擾復雜度評估方法[J]. 電子與信息學報, 2019, 41(1): 195-201. doi: 10.11999/JEIT180256
Baiqiang YIN, Shudong WANG, Yigang HE, Lei ZUO, Bing LI, Zhen CHENG. Electromagnetic Environment Complex Evaluation Algorithm Based on Fast S-transform and Time-frequency Space Model[J]. Journal of Electronics & Information Technology, 2019, 41(1): 195-201. doi: 10.11999/JEIT180256
Citation: Baiqiang YIN, Shudong WANG, Yigang HE, Lei ZUO, Bing LI, Zhen CHENG. Electromagnetic Environment Complex Evaluation Algorithm Based on Fast S-transform and Time-frequency Space Model[J]. Journal of Electronics & Information Technology, 2019, 41(1): 195-201. doi: 10.11999/JEIT180256

基于快速S變換時頻空間模型的電磁干擾復雜度評估方法

doi: 10.11999/JEIT180256 cstr: 32379.14.JEIT180256
  • 1.

    合肥工業大學電氣與自動化工程學院 ??合肥 ??230009

  • 2.

    武漢大學電氣工程學院 ??武漢 ??430072

基金項目: 國家自然科學基金(61501162, 51577046)，無損檢測技術教育部重點實驗室(南昌航空大學)開放基金(JZ2015SJSY0018)，國家自然科學基金重點項目(51637004)，國家重點研發計劃項目(2016YFF0102200)
詳細信息
    作者簡介:

    尹柏強：男，1983年生，副教授，碩士生導師，研究方向?yàn)閺?fù)雜電磁環境模擬、分析與評估

    王署東：男，1992年生，碩士生，研究方向?yàn)閺?fù)雜信號分析與處理

    何怡剛：男，1966年生，博士，教授，博士生導師，主要研究方向?yàn)閺?fù)雜電磁環境分析與評估、智能電網技術、射頻識別技術等

    佐磊：男，1982年生，博士，副研究員，碩士生導師，主要研究方向?yàn)樵O(shè)備狀態監測與評估、智能感知技術及應用等

    李兵：男，1973年生，博士，副研究員，碩士生導師，主要研究方向?yàn)榭煽啃灶A(yù)測、物聯網技術應用等

    程珍：女，1988年生，博士，講師，碩士生導師，主要研究方向?yàn)閺?fù)雜信號分析與處理

    通訊作者:

    尹柏強　yinbaiqiang123@163.com

  • 中圖分類號: TN97

Electromagnetic Environment Complex Evaluation Algorithm Based on Fast S-transform and Time-frequency Space Model

  • 1.

    School of Electrical and Automation Engineering, Hefei University of Technology, Hefei 230009, China

  • 2.

    School of Electrical Engineering, Wuhan University, Wuhan 430072, China

Funds: The National Natural Science Foundation of China (61501162, 51577046), The Key Laboratory of Nondestructive Testing (Nanchang Hang Kong University) Opening Foundation, Ministry of Education (JZ2015SJSY0018), The State Key Program of National Natural Science Foundation of China (51637004), The National Key Research and Development Plan (2016YFF0102200)
  • 摘要:

    針對復雜電磁環境電磁干擾復雜度定性與定量評估問題，該文提出一種基于快速S變換時頻空間模型的復雜度評估方法。利用快速S變換方法同步提取時域占用度、頻域占用度和能量占用度等評估指標，給出了具體計算方法。在此基礎上建立快速S變換時頻空間評估模型，將時域、頻域和能量域3維向量的F范數和均方根作為電磁環境主觀復雜度和客觀復雜度評估指標，克服了傳統電磁干擾復雜度評估獨立參數定級不能全面反映電磁干擾整體特性的局限性。仿真結果表明，采用該模型能有效同步提取時頻及能量評估特征參數，時頻空間評估模型能精確反映整體電磁干擾特征；實驗測試結果驗證了本文所提評估方法的正確性。

    Abstract:

    For qualitative and quantitative complex evaluation problem of electromagnetic environment. This paper proposes a novel electromagnetic environment complex evaluation algorithm based on fast S-transform and time-frequency space model, which can count time-complex, frequency-complex and energy-complex simultaneously. Meanwhile, the computation methods and concept of qualitative and quantitative evaluation degree are introduced. To overcome the limitations of the traditional methods, F-norm and root-mean-square are selected as two important evaluation indicators, which have the advantage in accurate evaluation. Simulation results show that the proposed method is accurate and effective to reflect the intensity degree of electromagnetic interference; Meanwhile, the interference experiment of bus card confirms the correctness of the time-frequency space model. The experimental test results verify the correctness of the mentioned evaluators.

    • HTML全文

  • 圖  1  時頻空間模型

    圖  2  快速S變換時頻空間

    圖  3  仿真信號S變換2維時頻等高圖

    圖  4  仿真信號3維時頻等高圖

    圖  5  電磁干擾評估實驗場景

    圖  6  公交卡干擾實驗收發天線及卡測試實驗裝置

    圖  7  干擾信號1作用下的S變換時頻參數測試結果

    圖  8  干擾信號2作用下的S變換時頻參數測結果

    表  1  傳統電磁環境復雜度的定級標準(%)

    定性等級定量等級時間頻率空域
    一般復雜10～100～100～10
    210～2010～2010～20
    320～3020～3020～30
    輕度復雜430～4030～4030～40
    540～5040～5040～50
    中度復雜650～6050～6050～60
    760～7060～7060～70
    870～8070～8070～80
    重度復雜980～9080～9080～90
    1090～10090～10090～100
    下載: 導出CSV

    表  2  本文電磁環境復雜度的定級標準(%)

    定性等級定量等級客觀復雜度C主觀復雜度Cm
    一般復雜10 < C ≤ 0.1 Cm ≥ 2.7
    20.1 < C ≤ 0.82.7 > Cm ≥ 2.4
    30.8 < C ≤ 2.72.4 > Cm ≥ 2.1
    輕度復雜42.7 < C ≤ 6.42.1 > Cm ≥ 1.8
    56.4 < C ≤ 12.51.8 > Cm ≥ 1.5
    中度復雜612.5 < C ≤ 21.61.5 > Cm ≥ 1.2
    721.6 < C ≤ 34.31.2 > Cm ≥ 0.9
    834.3 < C ≤ 51.20.9 > Cm ≥ 0.6
    重度復雜951.2 < C ≤ 72.90.6 > Cm ≥ 0.3
    1072.9 < C ≤ 1000.3 > Cm
    下載: 導出CSV

    表  3  公交卡及電磁干擾信號參數表

    信號樣式信號時頻能量參數
    中心頻率(MHz)持續時間帶寬(MHz)接收功率(dB)
    公交卡信號13.56601.25–20
    干擾信號113.56600.70–30
    干擾信號2高斯噪聲(0～400)600～400–70
    下載: 導出CSV

    表  4  客觀復雜度評估參數及定量評價結果

    信號樣式信號時頻能量占用度(%)C (%)
    TPFPEP
    干擾1100 563016.8
    干擾2100100<0.01<0.01
    下載: 導出CSV

    表  5  主觀復雜度評估參數及定量評價結果

    信號樣式S變換時頻模型評估參數Cm
    tP1 (s)tP2 (s)fP1 (MHz)fP2 (MHz)SP1 (dBm)SP2 (dBm)
    干擾10～600～6013.5613.56–20–300.90
    干擾20～600～6013.560～400–20–700.01
    下載: 導出CSV
  • 陳琛, 黃學良, 譚林林, 等. 電動汽車無線充電時的電磁環境及安全評估[J]. 電工技術學報, 2015, 30(19): 61–67. doi: 10.3969/j.issn.1000-6753.2015.19.010

    CHEN Chen, HUANG Xueliang, TAN Linlin, et al. Electromagnetic environment and security evaluation for wireless charging of electric vehicles[J]. Transactions of China Electrotechnical Society, 2015, 30(19): 61–67. doi: 10.3969/j.issn.1000-6753.2015.19.010
    李偉, 魏光輝, 潘曉東, 等. 復雜電磁環境下通信裝備干擾預測方法[J]. 電子與信息學報, 2017, 39(11): 2782–2789. doi: 10.11999/JEIT170107

    LI Wei, WEI Guanghui, PAN Xiaodong, et al. Interference prediction method of communication equipment under complex electromagnetic environment[J]. Journal of Electronics &Information Technology, 2017, 39(11): 2782–2789. doi: 10.11999/JEIT170107
    TETLEY W. Analytical prediction of electromagnetic environments[J]. IRE Transactions on Communications Systems, 1961, 9(2): 175–185. doi: 10.1109/TCOM.1961.1097669
    JAEKEL B W. Description and classification of electromagnetic environments - revision of IEC 61000-2-5[C]. IEEE International Symposium on Electromagnetic Compatibility, Detroit, USA, 2008: 1–4.
    尹成友. 戰場電磁環境分類與復雜性評估研究[J]. 信息對抗學術, 2007, 25(4): 4–6.

    YIN Chengyou. The battlefield electromagnetic environment complexity of classification and evaluation research[J]. Information Against Academic, 2007, 25(4): 4–6.
    王志剛, 王芳, 趙志強. 戰場電磁環境客觀復雜性分析與評估[J]. 現代防御技術, 2010, 38(3): 19–25. doi: 10.3969/j.issn.1009-086x.2010.03.005

    WANG Zhigang, WANG Fang, and ZHAO Zhiqiang. The battlefield electromagnetic environment complexity of objective analysis and evaluation[J]. Modern Ddfence Technology, 2010, 38(3): 19–25. doi: 10.3969/j.issn.1009-086x.2010.03.005
    顧有林, 張志, 王偉, 等. 電磁環境復雜度評估算法研究與仿真實現[J]. 系統仿真學報, 2012, 24(2): 394–397.

    GU Youlin, ZHANG Zhi, WANG Wei, et al. Research and simulation implementation of electromagnetic environment complex evaluation algorithm[J]. Journal of System Simulation, 2012, 24(2): 394–397.
    王倫文, 孫偉, 潘高峰. 一種電磁環境復雜度快速評估方法[J]. 電子與信息學報, 2010, 32(12): 2942–2947.

    WANG Lunwen, SUN Wei, and PAN Gaofeng. An evaluating quickly method for electromagnetic environment complexity[J]. Journal of Electronics &Information Technology, 2010, 32(12): 2942–2947.
    ZEDDAM A, AVRIL G, and TLICH M. Electromagnetic environment and telecommunications: Towards a cognitive electromagnetic compatibility[J]. Comptes Rendus Physique, 2009, 10(1): 4–12. doi: 10.1016/j.crhy.2009.02.001
    董志勇, 栗強. 基于層次分析法的人為電磁環境復雜程度評估[J]. 指揮控制與仿真, 2008, 30(5): 106–112. doi: 10.3969/j.issn.1673-3819.2008.05.030

    DONG Zhiyong and LI Qiang. Complexity evaluation of artificial electromagnetism environment based on AHP[J]. Command Control &Simulation, 2008, 30(5): 106–112. doi: 10.3969/j.issn.1673-3819.2008.05.030
    代合鵬, 蘇東林. 電磁環境復雜度定量分析方法研究[J]. 微波學報, 2009, 25(3): 25–27.

    DAI Hepeng and SU Donglin. Study of the complexity evaluationon electromagnetism environment[J]. Journal of Microwaves, 2009, 25(3): 25–27.
    王志剛, 何俊. 戰場電磁環境復雜性定量評估方法研究[J]. 電子信息對抗技術, 2008, 25(2): 50–53. doi: 10.3969/j.issn.1674-2230.2008.02.013

    WANG Zhigang and HE Jun. The research of battlefield electromagnetic environment complexity quantitative evaluation method[J]. Electronic Information Warfare Technology, 2008, 25(2): 50–53. doi: 10.3969/j.issn.1674-2230.2008.02.013
    YIN Baiqiang, HE Yigang, LI Bing, et al. An adaptive SVD method for solving the pass-region problem in S-transform time-frequency filters[J]. Chinese Journal of Electronics, 2015, 24(1): 115–123. doi: 10.1049/cje.2015.01.019
    YAO Wenxuan, TANG Qiu, TENG Zhaosheng, et al. Fast S-transform for time-varying voltage flicker analysis[J]. IEEE Transactions on Instrumentation & Measurement, 2014, 63(1): 72–79.
    尹柏強, 何怡剛, 朱彥卿. 一種廣義S變換及模糊SOM網絡的電能質量多擾動檢測和識別方法[J]. 中國電機工程學報, 2015, 35(4): 866–872.

    YIN Baiqiang, HE Yigang, and ZHU Yanqing. Detection and classification of power quality multi-disturbances based on generalized S-transform and fuzzy SOM neural network[J]. Proceedings of the Chinese Society of Electrical Engineering, 2015, 35(4): 866–872.
    朱明哲, 姬紅兵, 董青峰. 廣義S變換及其在復雜輻射源信號分析中的應用[J]. 電子與信息學報, 2013, 35(10): 2432–2436. doi: 10.3724/SP.J.1146.2012.01311

    ZHU Mingzhe, JI Hongbing, and DONG Qingfeng. Generalized S-transform and its application to analysis of complex emitter signals[J]. Journal of Electronics &Information Technology, 2013, 35(10): 2432–2436. doi: 10.3724/SP.J.1146.2012.01311
    李文臣, 張政超, 陸靜, 等. 電磁環境復雜度等級評估模型[J]. 中國電子科學研究院學報, 2012, 7(4): 427–430. doi: 10.3969/j.issn.1673-5692.2012.04.023

    LI Wenchen, ZHANG Zhengchao, LU Jing, et al. Evaluation model of electromagnetic environment complexity classification[J]. Journal of China Academy of Electronics and Information Technology, 2012, 7(4): 427–430. doi: 10.3969/j.issn.1673-5692.2012.04.023
    王健, 張江明, 王瑞, 等. 論電磁環境的相對性與" 接地氣”的復雜度評估[J]. 電子與信息學報, 2016, 38(5): 1249–1255. doi: 10.11999/JEIT150947

    WANG Jian, ZHANG Jiangming, WANG Rui, et al. Relativity of electromagnetic environment and down-to-earth complexity evaluation[J]. Journal of Electronics &Information Technology, 2016, 38(5): 1249–1255. doi: 10.11999/JEIT150947
