基于連續差聯合陣列的非等距線陣無模糊波束形成方法

黃巖; 廖桂生; 李軍; 李婕

doi:10.11999/JEIT150321

基于連續差聯合陣列的非等距線陣無模糊波束形成方法

doi: 10.11999/JEIT150321 cstr: 32379.14.JEIT150321

計量
- 文章訪問數: 1418
- HTML全文瀏覽量: 123
- PDF下載量: 551
- 被引次數: 0
出版歷程
- 收稿日期: 2015-03-17
- 修回日期: 2015-08-21
- 刊出日期: 2015-12-19

Non-ambiguity Beamforming of Nonuniform Linear Array Based on Consecutive Difference Coarray

摘要

摘要: 該文針對非等距線陣波束形成產生柵瓣的問題，提出一種基于連續差聯合陣列的非等距線陣無模糊波束形成方法。該方法基于連續差聯合陣列對非等距線陣進行陣形優化分析，利用連續差聯合陣列與連續波程差一一對應的特性，擴展得到非等距線陣Toeplitz化的協方差矩陣。根據線性約束最小方差(LCMV)準則，可以直接利用該協方差矩陣得到穩健自適應波束形成。由于重構的協方差矩陣與相同孔徑等距線陣的協方差矩陣相似，不會產生相位模糊，避免了波束形成柵瓣的影響。大量的仿真實驗證明了該文方法的穩健性能。
- 信號處理 /
- 差聯合陣列 /
- 非等距線陣 /
- 無模糊波束形成
Abstract: As the beamforming of Nonuniform Linear Array (NLA) may occur grating lobes phenomenon, a beamforming method is proposed for working on the NLA with consecutive difference coarray. Firstly, this method analyzes the array optimization of the NLA based on consecutive difference coarray. Additionally, it can be concluded that the consecutive difference coarray is corresponding to the consecutive wavepath difference, which is applied to reconstruct the Toeplitz covariance matrix of the NLA. According to the Least Constraint Mean Variance (LCMV) rule, the reconstructed covariance matrix can directly be used for robust adaptive beamforming. Due to the similarity between the reconstructed covariance matrix and the covariance matrix of Uniform Linear Array (ULA) with the same aperture, the phase ambiguity will not happen and the grating lobes phenomenon will not occur. Extensive simulations show the robust effectiveness of the proposed method.
- Signal processing /
- Difference coarray /
- Nonuniform linear array /
- Non-ambiguity beamforming

HTML全文

參考文獻(19)

徐艷紅, 史小衛, 許京偉, 等. 基于響應矢量優化的共形陣列穩健波束形成[J]. 電子與信息學報, 2014, 36(9): 2220-2226.

Xu Yan-hong, Shi Xiao-wei, Xu Jing-wei, Li Ping, et al.. Robust Beamforming Based on Response Vector Optimization for Conformal Array[J]. Journal of Electronics Information Technology, 2014, 36(9): 2220-2226.

楊濤, 蘇濤, 何學輝. 基于波束域?qū)蚴噶抗烙?jì)的穩健自適應波束形成方法[J]. 電子與信息學報, 2013, 35(11): 2758-2763.

Yang Tao, Su Tao, He Xue-hui, et al.. Robust Adaptive Beamforming Based on Beamspace Steering Vector Estimation [J]. Journal of Electronics Information Technology, 2013, 35(11): 2758-2763.

楊志偉, 賀順, 廖桂生, 等. 子空間重構的一類自適應波束形成算法[J]. 電子與信息學報, 2012, 34(5): 1115-1119.

Yang Zhi-wei, He Shun, Liao Gui-sheng, et al.. Adaptive Beam-forming Algorithm with Subspace Reconstructing[J]. Journal of Electronics Information Technology, 2012, 34(5): 1115-1119.

Wang X, Aboutanios E, Trinkle M, et al.. Reconfigurable adaptive array beamforming by antenna selection[J]. IEEE Transactions on Signal Processing, 2014, 62(9): 2385-2396.

Wang X, Aboutanios E, and Amin M G. Thinned array beampattern synthesis by iterative soft-thresholding-based optimization algorithms[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(12): 6102-6113.

Friedlander B. On transmit beamforming for MIMO radar[J]. IEEE Transactions on Aerospace and Electronic Systems,

Hua G and Abeysekera S S. MIMO radar transmit beampattern design with ripple and transition band control [J]. IEEE Transactions on Signal Processing, 2013, 61(11): 2963-2974.

Tang Y, Ma X, Sheng W, et al.. Transmit beamforming for DOA estimation based on Cramer-Rao bound optimization in subarray MIMO radar[J]. Signal Processing, 2014, 101(2): 42-51.

Hoctor R T and Kassam S A. The unifying role of the coarray in aperture synthesis for coherent and incoherent and imaging[J]. Proceedings of the IEEE, 1990, 12(10): 735-752.

Pal P and Vaidyanathan P P. Nested arrays: a novel approach to array processing with enhanced degrees of freedom[J]. IEEE Transactions on Signal Processing, 2010, 58(8): 4167-4181.

Moffet A. Minimum-redundancy linear arrays[J]. IEEE Transactions on Antennas and Propagation, 1968, 16(8): 172-175.

Kischner A, Siart U, Guetlein J, et al.. A design-algorithm for MIMO radar antenna setups with minimum redundancy[C]. 2013 IEEE International Conference on Microwaves, Communications, Antennas and Electronics Systems (COMCAS 2013), Tel Aviv, Israel, 2013: 1-5.

Friedlander B and Weiss A J. Detection finding using spatial smoothing with interpolated arrays[J]. IEEE Transactions on Aerospace and Electronic Systems, 1992, 28(8): 574-587.

Ma W K, Hsieh T H, and Chi C Y. DOA estimation of quasi-stationary signals via Khatri-Rao subspace[C]. Proceedings of International Conference on Acoustics, Speech, and Signal Processing (ICASSP), Taipei, 2009: 2165-2168.

Capon J. High-resolution frequency-wavenumber spectrum analysis[J]. Proceedings of the IEEE, 1969, 57(8): 1408-1418.

, 48(10): 3376-3388.
