基于與非錐的新型FPGA邏輯簇互連結構研究
doi: 10.11999/JEIT150249 cstr: 32379.14.JEIT150249
-
2.
(中國科學院電子學研究所 北京 100190) ②(中國科學院大學 北京 100049)
基金項目:
國家自然科學基金(61271149)
Interconnect Architecture of a Novel And-inverter Cone Based FPGA Cluster
-
2.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)
Funds:
The National Natural Science Foundation of China (61271149)
-
摘要: 該文針對新型FPGA可編程邏輯單元與非錐(And-Inverter Cone, AIC)的結構特性，提出一系列方案以得到優化的邏輯簇互連結構，包括：移除輸出級交叉矩陣，單級反相交叉矩陣，低負載電路優化，將反饋和輸出選擇功能分開，限制AIC輸出級數的基礎上移除中間級交叉矩陣，與LUT架構進行混合等。通過大量的實驗，得出針對面積延時積最優的AIC簇互連結構，與Altera公司的FPGA芯片Stratix-IV結構相比，該結構邏輯功能簇本身面積減小9.06%, MCNC應用電路集在基于優化的AIC FPGA架構上實現的平均面積延時積減小40.82%, VTR應用電路集平均面積延時積減小17.38%；與原有的AIC結構相比，簇面積減小23.16%, MCNC應用電路集平均面積延時減小27.15%, VTR應用電路集平均面積延時積減小15.26%。
-
關鍵詞:
- 與非錐(AIC) /
- AIC簇 /
- 單級反相交叉矩陣 /
- 簇互連結構
Abstract: With deep understanding of the characteristics of And-Inverter Cone (AIC), an alternative logic element for FPGA, a series of improvements are proposed to get an optimized interconnect architecture inside the logic cluster. The enhancements include removing the output crossbar, adopting Inverter-Suffixed Crossbar (ISC), optimizing the low load circuit path, dividing the feedback and output function, restricting the output level of AIC and removing the middle crossbar, mixing with the LUT element. An optimized architecture is derived through amounts of experiments. Compared to Stratix IV, Altera, the area of cluster is reduced by 9.06%.Implemented on the new AIC architecture, the average area-delay product of MCNC benchmarks are reduced by 40.82%; the average area-delay product of VTR benchmarks is reduced by 17.38%. Compared to the original AIC-based FPGA architecture, the area of AIC cluster is reduced by 23.16%. Implemented on the new AIC architecture, the average area-delay product of MCNC benchmarks are reduced by 27.15%; the average area-delay product of VTR benchmarks are reduced by 15.26%. -
Kuon I and Rose J. Measuring the gap between FPGAs and ASICs[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2007, 26(2): 203-215. Mayer-Lindenberg F. Design and application of a scalable embedded systems architecture with an FPGA based operating infrastructure[C]. 9th Euromacro Conference on Digital System Design, Croatia, 2006: 189-196. Betz V, Rose J, and Marquardt A. Architecture and CAD for Deep-Submicron FPGAs[M]. Netherlands, Kluwer Academic Publishers, 1999: 15-20. Parandeh-Afshar H, Benbihi H, Novo D, et al.. Rethinking FPGAs: elude the flexibility excess of LUTs with and-inverter cones[C]. Proceedings of the ACM/SIGDA International Symposium on Field Programmable Gate Arrays, Monterey, 2012: 119-128. Parandeh-Afshar H, Zgheib G, Novo D, et al.. Shadow and-inverter cones[C]. IEEE International Conference on Field Programmable Logic and Applications (FPL), Porto, 2013: 1-4. Mishchenko A, Chatterjee S, and Brayton R. DAG-aware AIG rewriting: a fresh look at combinational logic synthesis [C]. Proceedings of the 43rd Design Automation Conference, San Francisco, 2006: 532-536. 埃伯哈德, 蔡德勒等, 編. 李文林, 等譯.《數學指南實用數學手冊》[M]. 北京: 科學出版社, 2012: 875. Zgheib G, Yang L, Huang Z, et al.. Revisiting and-inverter cones[C]. Proceedings of the 2014 ACM/SIGDA international symposium on Field-Programmable Gate Arrays. ACM, Monterey, 2014: 45-54. Altera Corporation. Stratix IV Device Handbook, vols.1 and 2.[OL] https://www.altera.com/content/dam/altera-www /global/en_US/pdfs/literature/hb/strastr-iv/stratix4_handbook.pdf, 2012. Murray K E, Whitty S, Liu S, et al.. Titan: enabling large and complex benchmarks in academic CAD[C]. Proceedings of the 23rd International Conference on Field-Programmable Logic and Applications, Porto, Portugal, 2013: 1-8. Lewis D, Ahmed E, Baeckler G, et al.. The stratix II logic and routing architecture[C]. Proceedings of the 2005 ACM/ SIGDA 13th ACM International Symposium on Field- Programmable Gate Arrays, Monterey, 2005: 14-20. Luu J, Goeders J, Wainberg M, et al.. VTR 7.0: Next generation architecture and CAD system for FPGAs[J]. ACM Transactions on Reconfigurable Technology and Systems (TRETS), 2014, 7(2): 6:1-6:30. Brayton R and Mishchenko A. ABC: an academic industrial- strength verification tool[C]. Computer Aided Verification, Edinburgh, 2010: 24-40. 江政泓, 林郁, 黃志洪, 等. 面向AIC結構的FPGA映射工具[J]. 電子與信息學報, 2015, 37(7): 1769-1773. Jiang Zheng-hong, Lin Yu, Huang Zhi-hong, et al.. Mapper for AIC-based FPGAs[J]. Journal of Electronics Information Technology, 2015, 37(7): 1769-1773. Lemieux G, Leventis P, and Lewis D. Generating highly- routable sparse crossbars for PLDs[C]. Proceedings of the 8th ACM/SIGDA International Symposium on FPGA, Monterey, California, 2000: 155-64. -
