對線性調頻脈沖壓縮雷達的多載波調制轉發干擾

王杰貴; 張鵬程

doi:10.11999/JEIT150193

對線性調頻脈沖壓縮雷達的多載波調制轉發干擾

doi: 10.11999/JEIT150193 cstr: 32379.14.JEIT150193

王杰貴¹,
張鵬程¹

基金項目:

國家自然科學基金(61171170)

計量
- 文章訪問數: 1781
- HTML全文瀏覽量: 234
- PDF下載量: 764
- 被引次數: 0
出版歷程
- 收稿日期: 2015-02-03
- 修回日期: 2015-04-01
- 刊出日期: 2015-11-19

Multi-carrier Modulation Repeater Jamming against LinearFrequency Modulated Pulse-compression Radar

Wang Jie-gui¹,
Zhang Peng-cheng¹

Funds:

The National Natural Science Foundation of China (61171170)

摘要

摘要: 目前對線性調頻(LFM)脈沖壓縮雷達轉發欺騙干擾主要通過移頻調制轉發和采樣直接轉發實現，常規轉發干擾樣式簡單，干擾信號規律性強、復雜度低。該文提出一種基于間歇采樣的多載波調制轉發新型干擾樣式。首先引用碼片的概念對間歇采樣過程重新建模，在此基礎上，通過對當前采樣碼片附加不同移頻量，結合多載波并行調制體制對其進行串并轉換，利用不同次轉發信號各子載波間的干擾累積，實現對LFM脈沖壓縮雷達的數量、幅度、空間分布可控的逼真假目標干擾。仿真表明該干擾樣式比移頻干擾和直接轉發干擾具有更好的干擾效果。
- 雷達 /
- 線性調頻信號 /
- 多載波調制 /
- 間歇采樣 /
- 數字射頻存儲器 /
- 轉發干擾
Abstract: Repeater deception jamming against Linear Frequency Modulated (LFM) pulse-compression radar is realized by frequency-shift repeater and direct repeater jamming so far. Conventional repeater jamming type is simple. Regularity of jamming signal is strong and complexity is low. A new repeater jamming type with multi-carrier modulation based on intermittent sampling is proposed. Firstly, the model of intermittent sampling is rebuilt with the code chip concept. Based on this, lifelike false targets with the quantity, amplitude and space distribution which can be controlled are produced by attaching different frequency-shift component to the present sampling code chip, deserializing signal used multi-carrier parallel modulation system and utilizing the accumulation of different times repeater signal jamming effect among sub-carriers. The simulation results show that the new jamming type has better performance than frequency-shift jamming and direct repeater jamming.
- Radar /
- Linear Frequency Modulated (LFM) signal /
- Multi-carrier modulation /
- Intermittent sampling /
- Digital Radio Frequency Memory (DRFM) /
- Repeater jamming

HTML全文

參考文獻(26)

Philip E P. Detecting and Classifying Low Probability of Intercept Radar (Second Edition)[M]. Norwood: Artech House, 2009: 81-122.

Lu G, Zeng D G, and Tang B. Anti-jamming filtering for DRFM repeat jamming based on stretch processing[C]. 2nd International Conference on Signal Processing Systems (ICSPS), Dalian, 2010: 78-82.

陳靖霖. 脈沖壓縮雷達干擾技術[D]. [碩士論文], 西安電子科技大學, 2011.

Chen J L. The jamming technology of pulse compression radar[D]. [Master dissertation], Xidian University, 2011.

Qi S B, Zhao X H, Jia Y X, et al.. Multiple false target jamming against wideband linear frequency modulated signal [C] 4th International Conference on Electronics Information and Emergency Communication (ICEIEC), Beijing, 2013: 252-255.

黃翀鵬, 王劍, 徐保國. 線性調頻脈沖雷達轉發干擾研究[J]. 電子與信息學報, 2013, 35(12): 2874-2881.

Huang Zhong-peng, Wang Jian, and Xu Bao-guo. Repeater jamming against LFM pulse radar[J]. Journal of Electronics Information Technology, 2013, 35(12): 2874-2881.

Berger S D. Digital radio frequency memory linear range gate stealer spectrum[J]. IEEE Transactions on Aerospace and Electronic Systems, 2003, 39(2): 725-735.

Feng D J, Tao H M, Yang Y, et al.. Jamming de-chirping radar using interrupted-sampling repeater[J]. SCIENCE CHINA Information Sciences, 2011, 54(10): 2138-2146.

Pan X Y, Wang W, Feng D J, et al.. Repeat jamming against LFM radars based on spectrum-divided[C]. IET International Radar Conference, Xian, 2013: 1-7.

劉忠, 王雪松, 劉建成, 等. 基于數字射頻存儲器的間歇采樣重復轉發干擾[J]. 兵工學報, 2008, 29(4): 405-410.

Liu Z, Wang X S, Liu J C, et al.. Jamming technique of interrupted-sampling and periodic repeater based on digital radio frequency memory[J]. Acta Armamentarii, 2008, 29(4): 405-410.

劉建成, 王雪松, 劉忠, 等. 對線性調頻脈壓雷達的導前假目標群干擾[J]. 電子與信息學報, 2008, 30(6): 1350-1353.

Liu Jian-cheng, Wang Xue-song, Liu Zhong, et al.. Preceded false target groups jamming against LFM pulse compression radars[J]. Journal of Electronics Information Technology, 2008, 30(6): 1350-1353.

劉忠. 基于DRFM的線性調頻脈沖壓縮雷達干擾新技術[D]. [博士論文], 國防科技大學, 2006.

Liu Zhong. Jamming technique for countering LFM pulse compression radar based on digital radio frequency memory [D]. [Ph.D. dissertation], National University of Defense Technology, 2006.

張克舟, 李青山, 張恒, 等. LFM脈沖壓縮雷達的隨機移頻多假目標干擾技術研究[J]. 電光與控制, 2014, 21(8): 106-109.

Zhang Ke-zhou, Li Qing-shan, Zhang Heng, et al.. Random frequency-shift for multi-false-target jamming of LFM pulse compression radar[J]. Electronics Optics Control, 2014, 21(8): 106-109.

熊張亮, 是湘全, 王志華, 等. 多載波雷達信號分析[J]. 現代雷達, 2007, 29(10): 35-39.

Xiong Zhang-liang, Shi Xiang-quan, Wang Zhi-hua, et al.. Analysis of multicarrier radar signal[J]. Modem Radar, 2007, 29(10): 35-39.

李曉柏, 楊瑞娟, 張尊泉, 等. 多載波雷達信號設計及其處理方法研究[J]. 信號處理, 2014, 30(1): 22-29.

Li Xiao-bai, Yang Rui-juan, Zhang Zun-quan, et al.. The waveform design and research on echo processing method of multicarrier radar[J]. Journal of Signal Processing, 2014, 30(1): 22-29.

趙樹杰. 雷達信號處理技術[M]. 北京: 清華大學出版社, 2010: 162-173.

Zhao Shu-jie. Radar Signal Processing[M]. Beijing: Tsinghua University Press, 2010: 162-173.

王雪松, 劉建成, 張文明, 等. 間歇采樣轉發干擾的數學原理[J]. 中國科學: E輯, 信息科學, 2006, 36(8): 891-901.

Wang Xue-song, Liu Jian-cheng, Zhang Wen-ming, et al.. Mathematical principles of intermittent sampling repeater jamming[J]. Science in China: Series E, Information Sciences, 2006, 36(8): 891-901.
