并行傳輸線共模泄漏的等效場-線耦合數值模型
doi: 10.11999/JEIT140210 cstr: 32379.14.JEIT140210
基金項目:
國家自然科學基金(61271104)和河南省重點科技攻關項目(132102210003)資助課題
Equivalent Field-to-line Coupling Numerical Model for Parallel Transmission Line Common-mode Electromagnetic Leakage
-
摘要: 針對并行傳輸線間感性和容性耦合計算問題，該文提出并行傳輸線等效場-線耦合亞網格時域有限差分(FDTD)數值模型，模型更適合非均勻介質等復雜情形的耦合串?dāng)_求解，且具有更為簡潔的數值計算形式。利用該等效場-線耦合數值模型，對并行傳輸線間共模電磁信息泄漏進行模擬仿真和實驗測試，時域模擬和頻域?qū)嶒?yàn)結果均表明，該模型可以有效刻畫并行傳輸線共模電磁信息泄漏發射特性。
-
關鍵詞:
- 并行傳輸線 /
- 場-線耦合 /
- 亞網格時域有限差分方法 /
- 共模電磁泄漏
Abstract: Based on the sub-cell Finite-Difference Time-Domain (FDTD) method, an equivalent field-to-line coupling numerical model for transmission line common-mode electromagnetic leakage is provided to calculate the inductive coupling and capacitive coupling between parallel transmission lines. The new model can solve the coupling crosstalk problem under inhomogeneous media and other complex situations. In addition, the presented work describes such method for numerical calculation, which has a more concise form. With the new model, simulation of common-mode electromagnetic information leakage for parallel transmission line is implemented. Furthermore, both simulation in time domain and experimental results in frequency domain show that the numerical model can effectively describe the emission characteristics of common-mode electromagnetic information leakage for parallel transmission lines. -
