一個開關電容電路的模擬和優化程序
A SWITCHED CAPACITOR CIRCUIT SIMULATION AND OPTIMIZATION PROGRAM
-
摘要: 本文介紹了一個以分析開關電容(SC)電路為目的面向用戶的通用程序。該程序可以完成對SC電路的時域、頻域和靈敏度模擬,可以對SC電路進行多目標優化,并可以求得SC電路的傳輸極點,且對電路的輸入信號、開關序列、網絡拓?fù)錄]有限制,文中提出了在改進節點法基礎上求出電路傳輸極點的方法,以貢獻的方式建立求傳輸函數對電容比的靈敏度方程,通過線性變換求得對電容比的靈敏度的方法和SC電路的多目標優化方法。最后給出了用該程序?qū)C電路進行模擬和優化的兩個算例。
-
關鍵詞:
Abstract: A program developed for analyzing general N-phase SC circuits is described. The program can perform the time-domain, frequency-domain and sensitivity simulation, the multiple objective optimization, and the calculation of the transfer poles of SC circuits. No topological or duty-cycle constraints are imposed on the SC circuits. The methods of calculating the SC circuits poles using modified nodal method and the circuit sensitivity with respect to capacitor ratios are given, and the multiple objective optimization method for SC circuits is developed. Two examples are included to illustrate the capabilities of the program. -
J. Vandewall et al.,IEEE Trans.l on CAS, CAS-28(1981)3, 186.[2]M. L. Liou and Y. L. Kou, ibid., CAS-26(1979)4, 213.[3]陸躍,南京工學院校慶報告論文,1983, 10.[4]J. Vandewall et al., Int. J. Circuit Theory and Appl., 9(1981)1, 77.[5]R. K. Brayton and R. Spence, Sensitivity and Optimization, Elsevier, 1980.[6]W. K. Jenkins and C. F. Lee, Proc. 1981 European Conf. on Circuit Theory and Design, Netherlands, p.1082.[7]B. J. Hosticka et al., IEEE J. of SC, SC-12(1977)6, 600.[8]Y. L. Kuo et al., IEEE Trans. on CAS, CAS-26(1979)9, 708. -
