摘要:
本文建立了線性有源網絡含理想電源支路時割集電壓和回路電流的直接表達式。此表達式在保持原網絡拓撲結構不變的情況下,用網絡的拓撲矩陣和參數矩陣的分塊矩陣表示,省去了大量的零元素,避免了網絡分析時各稀疏矩陣中零元素的計算,同時亦降低了各運算矩陣的階數。因此在電路的計算機輔助分析中利用本文導出的兩表達式,可使求解簡捷、明了,比用建立網絡方程,然后解方程的方法大大減少了內存空間和運算機時,從而可以提高計算機分析網絡的能力。
Abstract:
The network equations of the cut-set voltage and loop current of the linear active network are formulated, and their solutions are given in terms of the submatrices of the original matrix of the network. Doing so, the matrix order, the storage space, and the computing time are greatly reduced.
