有源C帶阻濾波器
AN ACTIVE C NOTCH FILTER
-
摘要: 本文提出了一種新的由兩個運放、五個電容組成的有源C帶阻濾波器,該濾波器能實現低通、低通帶阻、帶通、對稱帶阻網絡功能,其極點參數0和Q可以獨立調整。文中不但給出了實驗結果和計算實例,還分析了在0點衰減為有限值的原因。
-
關鍵詞:
- 濾波器; 有源濾波器; 有源C帶阻濾波器
Abstract: A new active C notch filter circuit with two operational amplifiers and five capacitors is presented. The circuit can fulfil the second-order lowpass, band-pass, band-stop and symmetrical band-stop functions. Its pole parameters Q and (0 can be adjusted independently. Design examples and experimental results are given. It is investigated why the attenuation is not infinite at notch frequency 0. -
R. Schaumann, J.R. Brand, Proc IEE. Part G; 128(1981), 19-24.[2]石田,村岡等,電子通信學會論文志,J68-A(11), 1985,1269-1270.[3]趙述江,電子學報,1984年,第1期,第64-70頁.[4]石田,副井等,電子通信學會論文志,J68-A(7), 1985,700-701. -
