FIR數字濾波器的簡化格型實現
SIMPLIFIED LATTICE REALIZATION OF FIR DIGITAL FILTERS
-
摘要: 格型濾波器在數值計算性能和結構的模塊化等方面都優于直接型,但實現起來較復雜。本文提出一種實現PIR數字濾波器的簡化格型結構,它所需的硬件設備量只有常規格型實現時的一半,與直接型實現時相當。文中給出了從直接型到簡化格型的綜合算法。并對線性相位FIR數字濾波器的格型綜合算法作了簡化。用實例演示了本文的主要結論。
-
關鍵詞:
- 濾波器; FIR數字濾波器; 格型濾波器
Abstract: Lattice fitter is superior to its counterpart of direct structure in numerical properties and modularity etc., but it is more complex to realize. This paper suggests a simplified lattice structure for the realization of FIR digital filters, so that the hard-ware requirement is only half as many as that of the conventional lattice filter, comparable to that of the direct structure. The synthesis algorithms that transform the direct structure into the simplified lattice structure are tfiven. Furthermore, the lattice synthesis algorithms for linear phase FIR digital filters are simplified. The main results are illustrated by a practical example. -
M. Bellanger.[J].Digital Processing of Eignals-Theory and Practice, Wiley Sons Ltd, New York.1984,:-[2]F. Itakura, S. Saito, Proc. 7th Int. Cong. Acoust., Budapest, 1971, Paper 25-c-1.[3]B. Friedlander, Proc. IEEE, 70((1982), 829-867.[4]P. L. Chu, D. G. Messerschmitt, IEEE Trans. on ASSP, ASSP-31(1983), 685-705.[5]A. H. Gray, J. D. Markel, IEEE Trans. on ASSP, ASSP-24(1976), 459-473.[6]R. E. Crochiere, IEEE Trans. on AU, AU-20(1972), 240-246.[7]J. D. Markel., A.H. Gray, IEEE Trans on ASSP, ASSP-23(1975), 473-486.[8]J. Makhoul, IEEE Trans. on ASSP, ASSP-26(1978), 304-314. -
