漸近波形估計技術加速的頻域有限差分法
A FAST 3D-FDFD METHOD IN CONJUCTION WITH ASYMPTOTIC WAVEFORM EVALUATION TECHNIQUE
-
摘要: 本文提出了一種基于三維頻域有限差分法(3D-FDFD)和漸近波形估計技術(AWE)計算三維微波結構S參數的快速算法。在分析中,將輸入和輸出端口的電場分別展開成某抽樣頻率點處的泰勒級數,通過Pad逼近及奇異值分解技術求出電場與頻率的有理函數解析表達式,從而獲得頻帶內的S參數。數值計算結果與已有結果吻臺良好,并且與傳統FDFD法相比,計算效率提高很多。
-
關鍵詞:
- 頻域有限差分法; 漸近波形估計; 波導不連續性; 散射參數
Abstract: A fast generalized algorithm for S parameter extraction of 3-D microwave structures is presented based on the 3-D FDFD (Frequency Domain Finite Difference) method in conjunction with the asymptotic waveform evaluation (AWE) technique.In the AWE technique,the electric field strength at the input and output ports are respectively expanded in a Taylors series around a frequency within the desired frequency band,and the coefficients of the Taylors series are matched via the Pad approximation to a rational function and the robust Singular Value Decomposition (SVD) technique is employed while solving the Pad equation.Using the rational function,the electric field strengths at the input and output are obtained at any frequency within the desired frequency band,which is used to calculated the S parameter.A good agreement between the numerical results and the reported data is observed.Compared with the traditional FDFD,the computational efficiency of the present method is considerably improved. -
劉凱，梁建，洪偉．一種用于求解雙周期結構電磁散射問題的吸收邊界條件．微波學報，1999，15(2)：93-98．[2]梁建，洪偉．多層微帶貼片天線的三維全波分析．電波科學學報，1999，14(1)：7-12．[3]Haifa S,et al.The Finite difference method for S-Parameter calculation of arbitrary three-dimensional structures.IEEE Trans.on MTT,1992,MTT-40(8):1602-1610.[4]Peter F,et al.Efficient linear circuit analysis by Pad approximation via the Lanczos process[J].IEEE Trans.on Computer-Aided Design.1995,14(5):639-649[5]Ramin S,et al.A fast method for frequency and time domain simulation of high-speed VLSI interconnects.IEEE Trans.on MTT,1994,MTT-42(12):2562-2571.[6]Reddy C J,et al.Fast RCS computation over a frequency band using method of moments in conjunction with asymptotic waveform evaluation technique.IEEE Trans.on AP,1998,AP-46(8):1229-1233.[7]Bracken J E,et al.S-domain methods for simultaneous time and frequency characterization of electromagnetic devices.IEEE Trans.on MTT,1998,MTT-46(9):1277-1290.[8]徐獻瑜，等．Pad逼近概論．上海：上?？萍汲霭嫔纾?1990，3-12．[9]Krupezevic D V,et al.The wave-equation FD-TD method for the efficient eigenvalue analysis and S-matrix computation of waveguide structures.IEEE Trans.on MTT,1993,MTT-41(12):2109-2115. -
