一種新型基站天線的非均勻網格FDTD分析
Analysis of a novel base stationi antenna with non-uniform FDTD
-
摘要: 板狀振子型基站天線是一種現代移動通信中廣泛使用的基站天線。為了比較準確地對其天線單元和槽形板進行建模,同時考慮到計算資源限制,該文應用一種非均勻網格FDTD方法對其輻射方向圖特性進行了分析。數值結果表明該文方法處理天線輻射問題的有效性。
-
關鍵詞:
- 基站天線; 非均勻網格FDTD; 方向圖
Abstract: The dipole antenna array with trough reflector is widely applied to base stations for mobile communications. In order to simulate the antenna units and the trough reflector accurately and take the limitation of computation resources into account, this paper employs a kind of non-uniform FDTD algorithm in analyzing the radiation pattern. The numerical results show the effectiveness of this algorithm for antenna problems. -
K.S. Yee , Numerical solution of initial boundary value problems involving Maxwells equations in isotropic media, IEEE Trans. on AP, 1966, 14(5), 302 307.[2]Jiang Huiling, Analysis of computation error in antennas simulation by using non-uniform mesh FDTD, IEICE Trans., E00-A, No.1 January 1998, 1-9.[3]R. Luebbers, L. Chen, T. Uno, S. Adachi, FDTD calculation of radiation patterns, impedance,and gain for monopole antenna on a conducting box, IEEE Trans. on AP, 1992, 40(11), 1577-1583.[4]汪茂光,幾何繞射理論,西安,西安電子科技大學出版社,1994,70-71.[5]Jian Peng, A. Balanis, NEC and ESP codes: Guidelines, limitations, and EMC applications,IEEE Trans. on EMC, 1993, 35(2), 124-133. -
