采用保角變換求解一類TEM模傳輸線的衰減常數
CONFORMAL TRANSFORMATION METHOD FOR ATTENUATION CONSTANT OF TEM MODE TRANSMISSION LINE
-
摘要: 本文提出采用保角變換法求解一類TEM模傳輸線的衰減常數。通過適當?shù)谋＝亲儞Q能夠映射成(包括數值保角變換)正規圓同軸線或平板電容的情況均可采用這種方法。文中給出了解析結果和數值實例。
-
關鍵詞:
- 傳輸線; 保角變換; 衰減常數; TEM模; 映射
Abstract: A conformal transformation method is presented to solve a, the attenuation constant of TEM mode transmission line. This method is suitable for all that can be mapped into conventional coaxial line or flat-plate capacitor through several conformal transformations (including numerical conformal transformations). Finally, some analytical and numerical re-sults are given. -
B. N. Das, K. V. Rao, A.K. Mallick, IEEE Trans. on MTT, MTT-31 (1983), 403-407.[2]W. Lin, IEEE Trans. on MTT, MTT-33 (1985), 1983-1988.[3]Pan Shenggen, IEEE Trans. on MTT, MTT-35 (1987),61-63.[4]M. A. R. Gunston, Microwave Transmission-Line Impedance Data, Van Nostrand Reinhold Comm pany,London, (1972).[5]W. Hilberg, IEEE Trans. on MTT, MTT-17 (1969), 259-265.[6]曾令儒,中國科學,A輯,1982年,第6期,第553頁.[7]梁昌洪,官伯然,電子學報,1984年,第5期,第1頁.[8]徐泰,復旦學報, 21(1982)4, 453.[9]H. A. Wheeler, Proc. IRE, 30 (1942) 9, 412-424.[10]林為干,科學通報,1989年,第4期,第309頁. -
