基于小波圖像編碼的遠程監控系統的設計與實現
Remote surveillance system based on wavelet image coding
-
摘要: 小波變換由于其多分辨率特性而特別適合圖像編碼。該文設計了一種基于小波圖像編碼的遠程監控系統。整個系統由本地監控端和遠程主控端組成。本地監控端包括圖像采集、小波變換圖像編碼和發送3個模塊。小波變換圖像編碼由二維小波變換和零樹編碼組成。設計了監控端各個模塊的硬件結構,編寫了其硬件結構的Verilog HDL模型,進行了仿真和邏輯綜合,并用FPGA進行了驗證。編寫了主控端的遠程接收、控制軟件,成功實現了基于小波圖像編碼的遠程監控系統。Abstract: The wavelet transform is ideal for image coding due to its capability for multi-resolution representation. This paper presents a remote surveillance system based on the wavelet image coding. The system contains two subsystems, the local monitor and the remote control. The local monitor consists of the image capture module, the wavelet coding module which has two blocks of 2-D wavelet transform and the zerotree coding, and the transmit module. The hardware structure of each module is designed, and the Verilog HDL modules of the local monitor are programmed and simulated. The hardware is then synthesized to FPGA. The receiver program for the remote control is designed, and the remote surveillance system is implemented successfully.
-
陳默,王曉東,李維釗,等,基于PC機和公用電話網的遠程監控的設計和實現,計算機應用研究,2001,(8),111-114.[2]吳桂初,冉立新,陳抗生,基于PSTN的遠程圖像采集和傳輸系統,計算機工程,1999,25(4),32-34.[3]戴禮榮,李楓,王仁華,基于PSTN的遠程多媒體監控系統,中國圖象圖形學報,2001,6(6),594-598.[4]A.S. Lewis, G. Knowles, VLSI architecture for 2-D Daubechies wavelet transform without multipliers, Electronics Letters, 1991, 27(2), 171-173.[5]M. Vishwanath, R. M. Owens, M. J. Irwin, VLSI architecture for the discrete wavelet transforms,IEEE Trans. on CAS-II, 1995, CAS-Ⅱ-42(5), 305-316.[6]J.M. Shaprio, Embedded image coding using zerotrees of wavelet coefficients, IEEE Trans. on SP, 1993, SP-41(12), 3445-3462.[7]A. Said, W. A. Pearlman, A new fast and efficient image codec based on set partitioning in hierarchical trees, IEEE Trans. on CAS, Video Tech., 1996, 6(3), 243-249.[8]W.K. Lin.[J].B. W. -H Ng, N. Burgess, Reduced memory zerotree coding algorithm for hardware implementation, IEEE ICMCS99, Florence, Italy.1999,:-[9]Wang Guoyu, High integration CMOS vision chips, in Proc.[J]. SPIE.1996,Vol. 2894:123- -
