基于線性調頻步進信號的ISAR成像技術研究
Research on ISAR Imagimg Based on Linearly Modulated Frequency Stepped Radar Signal
-
摘要: 分析了線性調頻步進雷達信號(LMFS)的形式及成像的特點,利用對雷達發射信號的設計,提出了此類信號切實可行的運動補償方案;提出了兩種形成延展目標ISAR像的拼接方法;最后通過實測數據驗證所提運動補償方法的有效性并通過仿真驗證了所提ISAR像拼接方法的正確性。Abstract: The features of the linearly modulated frequency stepped radar signal (LMFS) and imaging based on it are analyzed. A feasible scheme of target motion compensation is proposed by using designation of radar transmitting signal; ISAR image is achieved by two methods of ISAR image combination for LMFS. The effectiveness of the scheme of target motion compensation is shown by the theoretical analysis and processing of the practical data, and the effectiveness of these methods of ISAR image combination are shown by the theoretical analysis and computer simulation.
-
D.R. Wehner, High Resolution Radar, London: Artech House,1995, 197-236.[2]龍騰,毛二可,何佩琨,調頻步進雷達信號分析與處理,電子學報,1998,26(12),84-88.[3]鄭學合,高分辨力雷達導引頭多維信息提取技術研究,博士論文,航天部二院,1998,48-53.[4]F. Berizzi, G. Pinelli, Maximum-likelihood ISAR image autofocusing technique based on instantaneous frequency estimation, IEE proc.-F, 1997, 144(5), 284-291.[5]J. Sok, S. Tariq, B. C. Flores, Phase difference method for target motion compensation of steppedfrequency ISAR signature, SPIE Radar Processing, Technology, and Application, 1996, 2485,163-174.[6]葉煒,保錚,逆合成孔徑雷達子聚焦的新方法--局域特顯點綜合法,中國科學(E輯),1997,25(5),424-429.[7]T. Itoh, H. Sueda H, Y. Watanabe, Motion compensation for ISAR via centroid tracking, IEEE Trans. on AES, 1996, 32(3), 1191-1197. -
