高速多芯片組件同步開關噪聲的二維特征法全波分析
FULL WAVE ANALYSIS OF SIMULTANEOUS SWITCHING NOISE IN HIGH SPEED MCM BY THE METHOD OF CHARACTERISTICS
-
摘要: 高速多芯片組件(MCM)廣泛用于高復雜度的系統中,而其中的同步開關噪聲(Simultaneous Switching Noise)是影響系統功能的重要因素.本文采用二維電磁模型模擬MCM電源、接地板同步開關噪聲;文中提出一種新的時域電磁問題的數值方法特征法,并用于求解上述問題,所得結果與FD-TD計算的結果和文獻報道一致.
-
關鍵詞:
- 多芯片組件; 同步開關噪聲; 特征法
Abstract: High speed Multi-Chip Module (MCM) has been widely adopted in the complex system, where Simultaneous Switching Noise is one of the key factors affecting the system function. In this paper, two dimensional electromagnetic model is used to simulate power/ground plane simultaneous switching noise in MCM. A novel numerical method for the time-domain electromagnetic problems, named Method of Characteristics, is presented and used to solve the above problem. The results obtained is in accordance with that by the method of FD-TD and that reported by literature. -
Chan P C. Design automation for multi-chip module-issues and status. International Journal of High[2]Speed Electronics. 1991,2(4): 263-285.[3]Rainal A. Computing inductive noise of chip packages, ATT Bell Lab Tech. J., 1984, 63(1): 177-191.[4]Fang J, et al. Modeling of power ground plane noise in high-speed digital electronics packaging. IEEE 2nd Topical Meeting on Electrical Performance of Electronic Packaging, Conference Proceedings, Monterey,CA:Oct.20-22,1993,206-208.[5]Djordjevic A R, Sarkar T K. An investigation of Delta-I noise on integrated circuits. IEEE Trans. on EMC,1993,EMC-35(2):134-147.[6]Chen Y,et al. Modeling of Delta-I noise in digital electronics packaging. 1994 IEEE Multi-Chip[7]Module Conference, Conference Proceedings, Santa Cruz,CA.,USA:Mar.,15-17,1994,126-131.[8]南京大學數學系.偏徽分方程數值解法.北京:科學出版社,1979,第二章第七節.[9]Djordjevic A R, Sarkar T K. Analysis of time domain response of lossy multiconductor transmission line networks. IEEE Trans. on MTT,1987,MTT-35(10): 898-908.[10]Buechler D N, et al.Modeling sources in the FD-TD formulation and their use in quantifying source and boundary condition errors. IEEE Trans. on MTT, 1995, MTT-43(4): 810-814. -
