寬帶速調管濾波器型輸出回路設計方法的修正和間隙作用阻抗的計算
THE MODIFICATION OF THE METHOD FOR DESIGNING THE FILTER TYPE OUTPUT CIRCUIT OF BROADBAND KLYSTRONS AND THE CALCULATION OF GAP INTERACTION IMPEDANCE
-
摘要: 本文提出了設計寬帶速調管濾波器型輸出回路的新的設計標準和相應的設計方法,由此可以求得符合速調管設計要求,并具有最大阻抗頻帶特性的輸出段。本文還從等效電路出發,直接計算間隙作用阻抗,并求得輸出回路各參數對阻抗-頻帶特性的影響,根據計算曲線,調整輸出回路參數,可在實際研制工作中求得最佳結果。
-
關鍵詞:
Abstract: In this paper, we propose a new eriterion and a method for designing filter type output circuit of broadband klystrons. From this, we ean obtain an output section which satisfies the requirement of klystron designs, and have good impedance-band-width characteristies. From equivalent circuit, we can directly calculate the gap in-teraction impedance, and obtain the effect of parameters of the output circuit on which the impedance-bandwidth characteristies depends. According to caleulated curves, we can get optimum results through adjusting the parameters of output circuit in the actual manufacture. -
C. Romiguier, A Broad banding theory of the Klystron Amplifier Output Circuit, Wescon Technical Paper, 27/1,1961[2]電子管設計手冊編委會編,大功率速調管設計手冊,第五章,國防工業出版社,1979年9月.[3]丁耀根、陸孝厚,電子學通訊,4(1982), 168. -
