微帶傳輸線特性的數值分析
THE NUMERICAL ANALYSIS OF THE PROPERTIES OF MICROSTRIP TRANSMISSION LINES
-
摘要: 本文應用混合模有限元方法分析和計算了微帶傳輸線的各種特性,包括特性阻抗、速度比、色散特性以及帶厚的影響,并與有關文獻結果作了比較。結果表明,有限元法是對微帶傳輸線進行數值分析的有效方法。
-
關鍵詞:
- 微帶傳輸線; 有限元法; 色散特性
Abstract: A numerical analysis is presented in terms of finite element of hybrid-mode propagation characteristics in microstrip transmission lines, which include characteristics impedance, velocity ratio, dispersion characteristic and the effect of strip thickness. The results of calculation are compared with previous approximate calculations. It is shown that the finite-element method is an efficient numerical analysis for microstrip transmission lines. -
H. A. Wheeler, IEEE Trans. on MTT, MTT-13(1965)2, 172-185.[2]N. Alexopoulos, IEEE Trans. on MTT, MTT-33(1985)10, 847-881.[3]A-M. A. El-Sherbiny, IEEE Trans. on MTT, MTT-29(1981)12,1261-1266.[4]廖承愚,微波技術基礎,國防工業出版社,北京,1984年,第139-188頁.[5]P. Daly, IEEE Trans. on MTT, MTT-18(1971)1, 19-25.[6]H. E. Green, IEEE Trans. on MTT, MTT-13(1965)5,676-692.[7]Z. Pantic and R. Mittra, IEEE Trans. on MTT, MTT-34(1986) 11, 1096-1103.[8]N. Mabaya and P. E. Lagasse, IEEE Trans. on MTT, MTT-29(1981)6, 600-605.[9]P. Silvester, IEEE Trans. on MTT, MTT-17(1969)4, 204-210.[10]M. Kobayashi, F. Ando, IEEE Trans. on MTT, MTT-35(1987)2, 101-105. -
