多注速調管電子光學系統的研究
STUDY ON ELECTRON OPTICS SYSTEM OF MULTI-BEAM KLYSTRON
-
摘要: 本文比較系統地闡述了在多注速調管電子光學系統中開展的研究工作。給出了周期反轉永磁聚焦系統的設計方法和設計考慮,討論了控制極調制多注電子槍設計中遇到的特殊問題和解決方法,建立了計算電子光學系統的二維磁場和電子軌跡計算軟件,并應用這些軟件設計和研制了S波段200kW多注寬帶速調管的電子光學系統。該管輸出功率180kW,帶寬7.6％,效率44.4％,增益大于45dB,電子注通過率89％,高頻通過率69-83％。設計計算與實驗結果有較好的一致性。Abstract: Research Work on electron optics system of multi-beam klystron has been described systematically in this paper.Design consideration and design methods for periodic reversal permanent magnet focusing system are presented ,special technical problems met in design of multi-beam electron gun with controlling electrode are discussed.2D computer software or magnetic field and electron trajectory of electron optics system has been established,and applied to calculate the electron optics system of S-band 200 kW multi-beam klystron.This multi-beam klystron has output power of 180kW,bandwidth of 7.6％,efficiency of 44.4％,gain of ggreater than 45dB,DC beam transmission of 89%.RF beam ransmission of 69～83%.There is good consistence between experiment and calculation.
-
丁耀根，彭鈞．多注速調管一種新型大功率微波放大器件．電子科學學刊，1996，18(1)：64-71.[2]Drozdov S S，et al．Reversible Periodic Magnetic Focusing System.U．S．Patet 4，443，270，1984，F(xiàn)eb．21.[3]Molokovsky S I．多注速調管電子光學系統．訪華報告，北京：中國科學院電子學研究所，1994年11月.[4]丁耀根，趙京君，彭鈞，蔣振柏．多注速調管用周期反轉永磁聚焦系統的研制．中國電子學會真空電子學分會第十屆年會論文集，1995，69－72。[5]丁耀根，彭鈞，等．S波段多注速調管的研制．電子科學學刊，1996，18(2)：221-224. -
