集成運算放大器同相和反相形式的En-In噪聲分析和比較
THE En-In NOISE ANALYSIS AND COMPARISON OF IN-PHASE AND INVERTING FORMS OF INTEGRATED OPERATIONAL AMPLIFIER
-
摘要: 本文通過分析和比較同相和反相放大器En-In噪聲的特點,給出了若干新結果。本文方法在低噪聲運放電路設計和運放噪聲參數提取中都具有十分重要的意義。
-
關鍵詞:
- En-In噪聲模型; 同相放大器; 反相放大器; 電壓負反饋
Abstract: In this paper, on the basis of analysing and comparing the characteristics of En-In noise of in-phase and inverting amplifiers,new results are presented. The methods in this paper are highly important for us to design a low-noise circuit consisting of an operational amplifier and to extract the noise parameters of the operational amplifier. -
