可約割集和可約回路及其在網絡分析中的應用
APPLICATION OF REDUCIBLE CUTSET AND REDUCIBLE LOOP TO THE ANALYSIS OF NETWORK
-
摘要: 本文以梯形網絡為討論對象,提出可約分的獨立割集和可約分的獨立回路的概念。從而導出結構分析法,解決了常規網絡分析法中某些研究得尚不透徹的問題。結構分析的結果與狀態空間分析法所得結果完全一致,而且使用簡便。最后給出了實例。Abstract: The new concepts of reducible fundamental cutset and reducible fundamental loop through an analysis of ladder network is developed. A new analytic method, named structural analysis method, is presented. It evaluates the controllability and measurablity of network based on its structure rather than on its state equation. Some problems in the conventional network analysis can be solved by this method. Results obtained by this method are in-good agreement with that obtained by state space analysis, but this method is much simpler for use. The practical examples are given.
-
W. K. Chen, Applied Graph Theory, Amsterdam North-Holland, 1976.[2]貝卡利著,陳大棓?shù)茸g,網絡分析與綜合基礎,人民教育出版社,1979年,p254.[3]陳樹柏等. 網絡圖論及其應用,科學出版社,1982年,p244-246.[4]邱關源,網絡理論分析,科學出版社,1982年,p92-94.[5]高橋進一,有本卓, 回路網とシステム理論, 昭和49年9月.[6]辻井重男,佐川雅彥著,黃如星譯,現代電路分析法,國防工業出版社,1983, p103.[7]戴國勝,自動化與儀器儀表,1984年,第4期,第1-9頁.[8]戴國勝,自動化學報,10(1984),338-344.[9]戴國勝,中國電子學會電路與系統學會第六屆年會論文集,上海,1986年,p81-86. -
